DO NOT
use or place the transceiver in areas with tem-
peratures below -25°C or above +55°C, or in areas subject to
direct sunlight, such as the dashboard.
AVOID
operating the transceiver without running the vehi-
cle's engine. The vehicle's battery will quickly run out if the
transceiver transmits while the vehicle's engine OFF.
AVOID
placing the transceiver in excessively dusty envi-
ronments.
AVOID
placing the transceiver against walls. This will
obstruct heat dissipation.
AVOID
the use of chemical agents such as benzine or
alcohol when cleaning, as they damage the transceiver sur-
faces.
BE CAREFUL!
The transceiver will become hot when
operating continuously for long periods.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not ex-
pressly approved by Icom Inc., could void your authority to operate
this transceiver under FCC regulations.

TABLE OF CONTENTS

IMPORTANT .................................................................................... i
EXPLICIT DEFINITIONS ................................................................. i
PRECAUTION .................................................................................. i
TABLE OF CONTENTS .................................................................. ii
1 PANEL DESCRIPTION ........................................................... 1-6
I Front panel ............................................................................... 1
I Function display ....................................................................... 2
I Programmable function keys .................................................... 3
2 OPERATION .......................................................................... 7-10
I Turning power ON .................................................................... 7
I Channel selection ..................................................................... 7
I Receiving and transmitting ....................................................... 8
D Transmitting notes ................................................................. 8
D TX code channel selection .................................................... 9
D TX code number selection .................................................... 9
D DTMF transmission ............................................................... 9
D Scrambler function ................................................................ 9
D User set mode ..................................................................... 10
TM
3 OPTIONAL SmarTrunk II OPERATION .......................... 11-12
I SmarTrunk II
TM
and conventional modes ............................... 11
I SmarTrunk II
TM
operation ....................................................... 11
4 CONNECTION AND MAINTENANCE ................................ 13-17
I Rear panel and connection .................................................... 13
I Supplied Accessories ............................................................. 14
I Mounting the transceiver......................................................... 15
I Optional UT-105, UT-108 or UT-111 installation ..................... 15
I Optional UT-109 or UT-110 installation .................................. 16
I Optional OPC-617 installation................................................. 16
I Antenna ................................................................................... 17
I Fuse replacement .................................................................. 17
I Cleaning ................................................................................. 17
5 OPTIONS ................................................................................... 18
6 CE ........................................................................................ 19-20
ii
