Kemper Profiling Amplifier Manual page 46

46 KEMPER PROFILING AMPLIFIER
It's a good idea to make the KPA the central hub for all your guitar recordings and use it as your main
switching device. That way you can use all of your favorite amps alongside the internal effects of the KPA.
Once you've finished recording, it will only take a few button pushes to preserve the exact sound for future
use.
Connections for profiling a combination of amp and stomp box
Guitar In
Stomp
• Connect your guitar to the INPUT of the KPA.
• Connect the DIRECT OUTPUT/SEND from the KPA to the input of your stomp box.
• Connect the output of the stomp box to the input of your reference amplifier.
• Connect the microphone or microphone preamp to the RETURN INPUT of the KPA.
Reference Amp
Cabinet
Direct Out / Send
KEMPER PROFILING AMPLIFIER
Input Main Outs
Return
Main Outs
