VHF/UHF DUAL BAND DIGITAL TRANSCEIVER

SPECIFICATIONS

Frequency coverage
Version
USA
EXP
Type of emission
Mode
Operating temperature range
Frequency stability
Digital TX speed
Voice coding speed
Antenna impedance
Number of memory channels
Power supply requirements
Current drain
RX Stand-by
Max. audio
TX
Dimensions
Main unit
× ×
(W H D, projections not included)
Controller
Weight ( approx. )
Main unit
Controller
Output power
Modulation system FM, FM-N
DV
Max. frequency deviation
Spurious emissions
Microphone impedance
Intermediate frequencies
A band
B band
Sensitivity FM/FM - N ( 12dB SINAD )
DV ( 1% BER )
Receiver sensitivity
FM/FM - N
( 12dB SINAD )
(Not guaranteed, for your
reference only. Except
amateur bands.)
AM ( 10dB S/N )
Squelch sensitivity
Selectivity FM
FM - N
DV
Spurious and image rejections
A band
B band
Audio output power
External speaker connector
All stated specifications are subject to change without notice or obligation.
Supplied accessories ( * May differ, depending on version )
• Hand microphone, HM-207
• Controller cable, OPC-837 ( 3.5 m; 11.4 ft )
• CD ( CS-5100 and instruction handbook PDF )
D-STAR (Digital Smart Technology for Amateur Radio) is a digital radio protocol developed by JARL (Japan Amateur Radio League).
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Russia, Japan and/or other countries.
Android and Google Play are registered trademarks or trademarks of Google Inc. The Bluetooth word mark and logos are registered trademark owned by Bluetooth SIG, Inc. and any use of such marks
by Icom Inc. is under license. All other trademarks are the properties of their respective holders.
NEVER operate the transceiver while driving a vehicle. Safe driving requires your full attention—anything less may result in an accident.
1-1-32, Kami-minami, Hirano-ku, Osaka 547-0003, Japan Phone: +81 (06) 6793 5302
12421 Willows Road NE, Communication Equipment
Kirkland, WA 98034, U.S.A. Auf der Krautweide 24
Phone : +1 (425) 454-8155 65812 Bad Soden am Taunus, Germany
Fax : +1 (425) 454-1509 Phone : +49 (6196) 76685-0
E-mail : sales@icomamerica.com Fax
URL : http://www.icomamerica.com E-mail : info@icomeurope.com
URL
Glenwood Centre #150-6165 Highway 17A,
Delta, B.C., V4K 5B8, Canada
Ctra. Rubi, No. 88 "Edificio Can Castanyer"
Phone : +1 ( 604 ) 952-4266
Bajos A 08174, Sant Cugat del Valles,
: +1 ( 604 ) 952-0090
Fax Barcelona, Spain
Phone : +34 ( 93 ) 590 26 70
E-mail : info@icomcanada.com
URL : http://www.icomcanada.com Fax
E-mail : icom@icomspain.com
URL
Rua Itororó, 444 Padre Eustáquio
Belo Horizonte MG, 80-286 Gdansk, Jaskowa Dolina St. 75, Poland
CEP: 30130-150, Brazil Phone : +48 ( 58 ) 551 0484
Phone : +55 (31) 3582 8847
Fax
Fax : +55 (31) 3582 8987
E-mail : icompolska@icompolska.com.pl
E-mail : sales@icombrazil.com
URL
G E N E R A L
(unit:MHz)
Transmit Receiver
144 - 148, 430 - 450 118 - 174, 375 - 550
*1
137 - 174, 400 - 470 118 - 174, 375 - 550
*2
*1 *2
Guaranteed range: 144-148, 440-450MHz.
F2D, F3E, F7W
DV, FM, FM-N
AM ( RX only ) , AM-N ( RX only ) * *
Depending on version
- 10°C to +60°C ; +14°F to +140°F
±2.5ppm (- 10°C to +60°C on the basis of 25°C )
4.8kbps
2.4kbps
50Ω ( SO - 239 )
1000 regular channels, 4 call channels, 50 program
scan edges and 1200 repeater memories
13.8C DC ±15%
1.2A
1.8A ( Dualwatch, with Ext. SP 8Ω load )
13.0A
150×40×172.6 mm; 5.91 × 1.57 × 6.8 in
182.2×81.5×24.7 mm; 7.17 × 3.21 × 0.97 in
1.3kg; 2.87 lb
260g; 9.17 oz
TRANSMITTER
50W, 15W, 5W
FM reactance modulation
GMSK reactance modulation
±5.0kHz/±2.5kHz ( FM/FM-N )
Less than - 60dBc
600Ω ( 8 - pin modular jack )
RECEIVER
38.85MHz/450kHz ( 1st /2nd )
46.35MHz/450kHz ( 1st/2nd )
Less than 0.18μV ( amateur bands only )
Less than 0.28μV
137 - 159.995MHz Less than 0.32μV
160 - 174.000MHz Less than 0.56μV
375 - 399.995MHz Less than 0.56μV
400 - 499.995MHz Less than 0.32μV
500 - 550.000MHz Less than 0.56μV
118 - 136.9916MHz Less than 1μV
Less than 0.13μV ( at threshold )
More than 60dB
More than 55dB
More than 50dB
More than 60/55dB ( VHF/UHF )
More than 60/60dB ( VHF/UHF )
More than 2.0W ( with 8Ω load, 10% distortion )
2 - condcutor 3.5 ( d ) mm ( " ) /8Ω
1 /
8
• DC power cable, OPC-1132
• Microphone hanger
• Spare fuse
