Wiring
Speakon connector
C H1 OUT
CH2 +
2+
2- 1-
CH2 - CH1 -
1+
CH1 +
Max power 4Ω
Max power 8Ω
Max power - bridged 8Ω
Connectors
Speakon 1 wiring
Speakon 2 wiring
Slew Rate 8Ω
S/N Ratio
Distortion
(THD, DIM,SMPTE)
Input impedance
Output
Bandwidth
Damping Factor 8Ω (100Hz)
Thermal protection
Short circuit / over-load
Clip limit,
Analog signal limit
Connectors
Wiring
Connectors
Protocol
Connectors
Operating range
I. nom / P.nom (KA40)
Minimum operation voltage
Maximum operation voltage
Max continuous and
burst current
Dimensions
Weight
USER'S MANUAL
Speakon connector
CH2 OUT
2+
2- 1-
CH2 -
1+
C H2 +
KA10
2 x 500 w
(EIAJ)
2 x 260 w
(EIAJ)
1000 w
(EIAJ)
2 x 4-pin Speakon
pin 1+,1- = CH1
pin 2+, 2- = CH2
pin 1+,1- = CH2
pin 2+,2- = N.C.
50V/µS
>105 dB/A
<0.5%
20K bal. 10K unbal.
Gain 32 dB
Unbalanced to ground
10 Hz - 30 KHz
>500
Yes
Yes
Yes
2 x M + 2 x F bal. 3-pin XLR
1=gnd 2=hot 3 = cold
2 x female 8-pin RJ45
RS485 - V2 software
2 x PowerCon IN/OUT
EU 210-240 Vac 50Hz
USA 100-120 Vac 60Hz
2.6 A / 115 Vac - 1.6 A / 230 Vac
95 Vac - 195 Vac
125 Vac - 205 Vac
EU 5A(>10s) - 10A (<1s)
USA 10A(>10s)-20A(<1s)
20 (1/2 U rack) x 8.8 (2U rack) x 44.5 cm - (7.87"x 3.46"x 17.52")
3.5 Kg (7.72 lbs)
Notes for data
New materials and design are introduced into existing products without previous notice. Present systems may differ in some respects from those presented in
this brochure
KA40

Output power

2 x 2000 w
(EIAJ)
2 x 1200 w
(EIAJ)
4000 w
(EIAJ)
2 x 4-pin Speakon
pin 1+,1- = CH1
pin 2+, 2- = CH2
pin 1+,1- = CH2
pin 2+ 2- = N.C.

Audio specs

30V/µS
>108 dB/A
<0.5%
20K bal. 10K unbal.
38 dB
Unbalanced to ground
5 Hz - 25 KHz
>300
Protection
Yes
Yes
Yes

Audio Input

2 x M + 2 x F bal. 3-pin XLR
1=gnd 2=hot 3 = cold
Remote control Input
2 x female 8-pin RJ45

Remote control

RS485 - V2 software

Power Input

2 x PowerCon IN/OUT
AC power
85 - 270 Vac 50/60Hz
Universal up to 400 Vac
900 Vac
70 Vac
400 Vac
12A(>10s) - 24A(<1s)
Physical
6 Kg (13.23 lbs)
KA10-10
4 x 500 w
(EIAJ)
4 x 260 w
(EIAJ)
2 x 4-pin Speakon
pin 1+,1- = CH1
pin 2+, 2- = CH3
pin 1+,1- = CH2
pin 2+ 2- = CH4
50V/µS
>105 dB/A
<0.5%
20K bal. 10K unbal.
32 dB
Unbalanced to ground
10 Hz - 30 KHz
>500
Yes
Yes
Yes
2 x M + 2 x F bal. 3-pin XLR
1=gnd 2=hot 3 = cold
2 x female 8-pin RJ45
RS485 - V2 software
2 x PowerCon IN/OUT
EU 210-240 Vac 50Hz
USA 100-120 Vac 60Hz
3.6 A / 115 Vac - 2.2 A 230 Vac
95 Vac - 195 Vac
125 Vac - 205 Vac
EU 6.3A(>10s) - 12A (<1s)
USA 12A(>10s) - 24A(<1s)
4.8 Kg (10.58 lbs)
