User's Manual
CPS600E
CyberPower Europe
CyberPower Systems B.V.
Flight Forum 3545, 5657DW Eindhoven, The Netherlands
Tel: +31 (0)40 2348170
Fax: +31 (0)40 2340314
Website: http://eu.cyberpowersystems.com/
E-mail: sales@cyberpower-eu.com
K01-0000186-00

Advertisement

Table of Contents
loading

Related Manuals for CyberPower CPS600E

Summary of Contents for CyberPower CPS600E

  • Page 1 User’s Manual CPS600E CyberPower Europe CyberPower Systems B.V. Flight Forum 3545, 5657DW Eindhoven, The Netherlands Tel: +31 (0)40 2348170 Fax: +31 (0)40 2340314 Website: http://eu.cyberpowersystems.com/ E-mail: sales@cyberpower-eu.com K01-0000186-00...

  • Page 2: Table Of Contents

    DEFINITIONS FOR ILLUMINATED LCD ......7 EPS STATUS INQUIRY AND FUNCTIONS SETUP ..... 8 GENERAL MODE ................. 8 SET-UP MODE ..................8 FAULT WARNING DISPLAY AND ALARM ......10 TROUBLESHOOTING ............11 TECHNICAL SPECIFICATIONS ......... 12 Copyright © 2010 CyberPower Systems, Inc.

  • Page 3: Safety And Emc Instructions

    Condensation from the aquarium can cause the unit to short out. DO NOT INSTALL THE EPS WHERE IT WOULD BE EXPOSED TO DIRECT SUNLIGHT OR NEAR HEAT! DO NOT BLOCK OFF VENTILATION OPENINGS IN THE EPS’S HOUSING! Copyright © 2010 CyberPower Systems, Inc.
  • Page 4 CPS600E SAFETY: EN62040-1-1 EMI: Conducted Emission: IEC/EN 62040-2…Category C2 Radiated Emission: IEC/EN 62040-2……Category C2 Harmonic Current: IEC/EN61000-3-2 Voltage Fluctuations and Flicker: IEC/EN61000-3-3 EMS: IEC/EN61000-4-2(ESD) IEC/EN61000-4-3(RS) IEC/EN61000-4-4(EFT) IEC/EN61000-4-5(lightning surge) IEC/EN61000-2-2 (Immunity to low frequency signals) Copyright © 2010 CyberPower Systems, Inc.

  • Page 5: Installing Your Eps

    EPS off and unplug the equipment from the AC outlet. Ensure that the equipment plugged into the outlet does not exceed the UPS unit’s rated capacity (600VA/420W for CPS600E). If the rated capacities of the unit are exceeded, an overload condition may occur and cause the UPS unit to shut down or the input fuse to blow.

  • Page 6: Basic Operation

    Connect red (positive (+)) battery cable to the red (positive (+)) connector on the external battery. Note: The Battery cable is 10AWG / 4 feet. 9. DC Fuse The fuse provides optimal overload protection for battery mode operation. Copyright © 2010 CyberPower Systems, Inc.

  • Page 7: Replacing The Battery

    Do not lay tools or metal parts on top of battery or any terminals. Wear rubber gloves and boots. Determine if the external battery is inadvertently grounded. If grounded, remove the source of ground. CONTACT WITH GROUNDED BATTERY CAN RESULT IN ELECTRICAL SHOCK! Copyright © 2010 CyberPower Systems, Inc.

  • Page 8: Definitions For Illuminated Lcd

    EPS outlets until the icon disappears and the alarm stops being activated. 7. LOAD CAPACITY: Load CAPACITY is also shown on the bar chart; equal 25% load capacity for each segment. 8. BATTERY VOLTAGE: BATT. VOLTAGE indicates the voltage of battery. Copyright © 2010 CyberPower Systems, Inc.

  • Page 9: Eps Status Inquiry And Functions Setup

    EPS will be used. 220V and 230V may be selected. The system default setting is 220V. Function description: AVR Dynamic Voltage Compensation works automatically based on the system voltage settings. Static Frequency Tolerance: There are 6 settings (1,2,4,6,8,10%), and the default setting is +/-10%. Copyright © 2010 CyberPower Systems, Inc.
  • Page 10 Note: If user wants to return to general mode without saving changes, there are two methods: 1. Wait for the backlight to turn off 2. Press and hold the “Display” toggle for 10 seconds Copyright © 2010 CyberPower Systems, Inc.

  • Page 11: Fault Warning Display And Alarm

    Input/ Output Output-Off -- incorrect Input/ connection. Output connection Can Not Start Up None Cold Start Battery High Voltage Output-Off Check the reason for battery voltage is too high battery over-voltage. during cold start. Copyright © 2010 CyberPower Systems, Inc.

  • Page 12: Troubleshooting

    220/230V outlet. The EPS will not turn on. Contact CyberPower Systems about The battery is worn out. replacement batteries at service@cyberpower-eu.com Contact CyberPower Systems via Mechanical problem. phone or visit our website at eu.cyberpowersystems.com Copyright © 2010 CyberPower Systems, Inc.

  • Page 13: Technical Specifications

    Environmental Operating Temperature 32°F to 104°F ( 0°C to 40°C ) Operating Relative Humidity 0 to 90% Non-Condensing Physical Dimensions (L*W*H)( mm ) 240 * 162 * 90 Weight (Kg) Agency Certificated CE, SONCAP Copyright © 2010 CyberPower Systems, Inc.
  • Page 14 CPS600E Copyright © 2010 CyberPower Systems, Inc.
  • Page 15 CPS600E Copyright © 2010 CyberPower Systems, Inc.
  • Page 16 Flight Forum 3545, 5657DW Eindhoven, The Netherlands Tel: +31 (0)40 2348170 Fax: +31 (0)40 2340314 Website: http://eu.cyberpowersystems.com/ E-mail: sales@cyberpower-eu.com Entire contents copyright © 2010 CyberPower Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. Copyright © 2010 CyberPower Systems, Inc.
