- Page 1 User Manual for CPS1100AVR with USB / Serial Interface and PowerPanel Plus™ Software ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT www.cyberpowersystems.com/faqs.htm...
-
Page 2: Table Of Contents
Software User Manual------------------4 Warranty------------------------------------9 Thank you for purchasing a CyberPower Systems Product. To enjoy all the features and benefits of this Uninterruptible Power System (UPS), please read and follow all installation and operation instructions completely. This UPS is designed to provide guaranteed power protection for connected electronic equipment. -
Page 3: Description
Insure that the equipment plugged into the three battery power-supplied outlets does not exceed the UPS unit’s rated capacity (1100VA/660W for CPS1100AVR). If rated unit capacities are exceeded, an overload condition may occur and cause the UPS unit to shut down or the circuit breaker to trip. -
Page 4: Hardware Installation Guide
CPS1100AVR Guaranteed Uninterruptible Power System HARDWARE INSTALLATION GUIDE Your new UPS may be used immediately upon receipt. However, recharging the battery for at least four hours is recommended to insure that the battery’s maximum charge capacity is achieved. Charge loss may occur during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC outlet. - Page 5 CPS1100AVR Guaranteed Uninterruptible Power System PowerPanel Plus™ is equipped with a Scheduled Shutdown feature that can automatically save and close open files and then shutdown the computer and UPS at a user specified date and time as well as start the computer at a user specified date and time.
- Page 6 Minimize Button: Click this button to minimize the software. Setup: Click the setup button to open the Setup Window. Model: This shows the model of the CyberPower UPS that is being used. Version: This shows the hardware version. PowerPanel Plus™ Main Window Description (See Figure 2 ) 1.
- Page 7 CPS1100AVR Guaranteed Uninterruptible Power System 8. About: This button will display information about the software, as well as contact information. 9. Advance: This button opens the Advanced Setup Window. 10. Default: Click this button to return the software to original factory settings.
- Page 8 Contact your dealer or call the number in this manual for information on battery replacement. The order numbers for the battery are as follows: BA-CPS1100AVR for CPS1100AVR CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery. Service the battery under the supervision of personnel knowledgeable of batteries and their precautions.
- Page 9 CPS1100AVR Guaranteed Uninterruptible Power System TO REPLACE THE BATTERY Turn off and unplug all connected equipment. Turn the UPS off and unplug it from the AC power source. Turn the UPS upside down. Remove the 6 retaining screws. Turn the UPS right side up and remove the outlet cover.
- Page 10 Weak Battery- Recharge the battery for at On/Fla On/Off None least 8 hours. If Check Battery is illuminated sh/Off contact CyberPower Systems for battery replacement information. Surge Protection Malfunction- Lightning induced power line surge has damaged the surge-protect function. Please contact CyberPower Systems...
-
Page 11: Led Indicators
UPS on. Battery not fully charged. Recharge the battery by leaving the UPS plugged in. The UPS does not perform Contact CyberPower Systems about replacement batteries at expected runtime. Battery is slightly worn out. tech@cyberpowersystems.com The on/off switch is designed Turn the UPS off. -
Page 12: Warranty
CyberPower will inspect and examine the Product within ten (10) days of receipt. If the Product is not as warranted, CyberPower will repair or replace the Product and return it to you at CyberPower’s expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required). - Page 13 Implied Warranty; (b) the Limited Warranty requirements have been met, and; (c) none of the limitations or exclusions on warranty coverage apply, CyberPower will (as CyberPower elects, as permitted by law), repair, replace, or pay the Agreed Damage Amount (defined below) for, the item(s) of your electronic equipment directly and properly connected to the product (the “Connected Equipment”) if that Connected Equipment is (x)
- Page 14 (collectively, “High Risk Activities”). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities. CyberPower does not authorize use of any of its products use in any High Risk Activities.
- Page 15 Toll-Free: (877)-297-6937 Tel: (952)-403-9500 Fax: (952)-403-0009 Email: information@cyberpowersystems.com Web: www.cyberpowersystems.com Entire content copyright ©2003 CyberPower Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. PowerPanel Plus™ is a trademark of CyberPower Systems (USA), Inc. K01-1100A0A...
