- Page 1 User Manual for CPS700AVR and PowerPanel Plus™ Software User Manual ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT: www.cyberpowersystems.com/faqs.htm...
-
Page 2: Table Of Contents
AUTOMATIC VOLTAGE REGULATOR The CPS700AVR controls utility power voltage levels that can be inconsistent. The incoming utility power may be at a damaging level to important data files, but with the Automatic Voltage Regulation of the CPS700AVR the computer will only experience a consistent voltage level. An Automatic Voltage Regulator automatically increases low or decreases high voltage to a consistent, computer safe 110v/120v. -
Page 3: Description
Insure that the equipment plugged into the three battery power-supplied outlets does not exceed the UPS unit’s rated capacity (700VA/350W for CPS700AVR). If rated unit capacities are exceeded, an overload condition may occur and cause the UPS unit to shut down or the circuit breaker to trip. -
Page 4: Hardware Installation Guide
HARDWARE INSTALLATION GUIDE Your new UPS may be used immediately upon receipt. However, recharging the battery for at least four hours is recommended to insure that the battery’s maximum charge capacity is achieved. Charge loss may occur during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC outlet. -
Page 5: Software Installation Guide
CPS700AVR Guaranteed Uninterruptible Power System POWERPANEL PLUS™ SOFTWARE INSTALLATION GUIDE (Note: Use of the software is optional. The UPS will provide surge suppression and battery backup without the software. You must use the software if you wish to have the automatic shutdown feature). -
Page 6: Software User Manual
Minimize Button: Click this button to minimize the software. Setup Button: Click the setup button to open the Setup Window. Model: This shows the model of the CyberPower UPS that is being used. Version: This shows the hardware version. Status Bar: The area display messages about the status of the software. - Page 7 10. Output Voltage: This indicator shows the output voltage of the UPS. POWERPANEL™ PLUS SETUP WINDOW Sensitive to Variation on Line Voltage: This feature is for other CyberPower Products. Since the 700AVR has Automatic Voltage Regulation, this feature is not necessary.
- Page 8 POWERPANEL PLUS™ SCHEDULE MENU Special Setting: This setting allows you to schedule a one-time startup/shutdown. Schedule Display: This area displays the days/dates and times of any scheduled startups and shutdowns. Turn On: Select the day/date and time that you want the computer system to restart. Can only be used in conjunction with a scheduled shutdown.
- Page 9 On/Off Flash None Weak Battery- Recharge the battery for at least 8 hours. If Check Battery is illuminated contact CyberPower Systems for battery replacement information. Scheduled Turn-on- If the two battery indicators are flashing in rotation, the Flash On/Off Flash Set/Up UPS is waiting to turn on as configured in the schedule.
-
Page 10: Led Indicators
Battery not fully charged. Recharge the battery by leaving the UPS plugged in. expected runtime. Battery is slightly worn out. Contact CyberPower Systems about replacement batteries at tech@cyberpowersystems.com The UPS will not turn on. The on/off switch is designed to Turn the UPS off. - Page 11 CPS700AVR Guaranteed Uninterruptible Power System EXPECTED RUNTIME IN MINUTES Example Systems Load (Watts) CPS 700AVR™ Model Runtime Desktop PC with 15” Monitor 38 - 45 Desktop PC with 17” Monitor 28 - 36 Desktop PC with 21” Monitor 24 - 28 Tower PC with 21”...
- Page 12 CyberPower will inspect and examine the Product within ten (10) days of receipt. If the Product is not as warranted, CyberPower will repair or replace the Product and return it to you at CyberPower’s expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).
-
Page 13: Warranty
CyberPower will (in addition to Limited Warranty remedies for the CyberPower Product itself) repair (or pay the costs of repair) or replace the Connected Equipment or, at the option of CyberPower, as permitted by law, pay to the Initial Customer the “Agreed Damage Amount” (up to the aggregate limits stated below) for all item(s) of Initial Customer’s Connected Equipment. - Page 14 (collectively, “High Risk Activities”). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities. CyberPower does not authorize use of any of its products use in any High Risk Activities. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF CYBERPOWER PRODUCTS.
- Page 15 Shakopee, MN 55379 Tel: (952) 403-9500 Fax: (952) 403-9500 Email: sales@cyberpowersystems.com Web: www.cyberpowersystems.com Entire contents copyright ©2001 CyberPower Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. PowerPanel™ is a trademark of CyberPower Systems (USA), Inc.
