System - Sound Devices 664 User Manual And Technical Information

# Parameter Name
5 Max File Size
6 Scene Increment Mode
7 Take Reset Mode
8 File Playback Mode
Default Playback Card
9
10 Erase/Format CF
11 Erase/Format SD

System

# Parameter Name
1 Tone Level
2 Tone Frequency
3 Tone Mode
4 Warning Bell Level
5 Record/Stop Bell
6 Meter Ballistics
7 Meter Peak Hold Time
8 LED Brightness
9 LCD Brightness
10 Time Format
Description
Selects the file size when the 664 will close, then
start a new file. The 664 will not record a file
larger than the selected size.
The largest file permissible with the 664's FAT32
file system is 4 GB
Selects which format the scene increments will
use. To quickly increment a scene name press
and hold the Headphone Encoder then slide the
Transport Control right (Fast Forward)
Defines when take numbers are reset. Reset
brings take number to <1>
Determines what (If any) playback action the 664
will perform upon reaching the end of a file during
playback.
The source media that files will be played from
when playback is initiated.
Formats CF card to FAT32 file system.
Formats SD card to FAT32 file system.
Description
The level of the 664's internal tone generator.
The audio frequency of the 664's internal tone
generator.
Continuous tone generates tone a the set tone level
to all bus tracks. L Ident mode pulses the amplitude of
tone to the Left channel of the Master Bus by -20dB.
The level of warning bell signals in the Headphones.
Alerts the user with one beep at the start of recording
and two beeps when the recording is stopped
Selects among the two different meter ballistics set-
tings.
Adjusts the duration for which the peak indicator stays
illuminated.
Adjust the brightness of all LED's.
Adjusts the brightness of the LCD backlight.
Select 12 hour clock or 24 hour clock.
664 User Guide and Technical Information
Options
» 4GB
• 2GB
• 1GB
• 640MB
• 512MB
• Disabled
• Character
• Numeric
• Never
• Scene Change
• Daily Folder Change
» Either Scene or Daily
» Disabled
• Play All
• Repeat One
• Repeat All
» CF
• SD
Options
• 0-20 dBu (1 dBu increment)
» 0 dBu
• 100-10000 Hz (10 Hz increment)
» 1000 Hz
» Continuous
• L Ident
• Off, -60 to -12 dBFS
(1dB increment)
» -30 dBFS
• Off
» On
• VU Only
» Peak + VU
» 1 sec
• 2 sec
• 3 sec
• 4 sec
• 5 sec
• Infinity
• 5-100%
(5% increment)
» 60%
• 5-100%
(5% increment)
» 100%
» 12hr
• 24hr
41
