- Page 1 CheetahSwitch Workgroup-3726M Quick Installation Guide...
- Page 3 Quick Installation Guide CheetahSwitch Workgroup-3726M Intelligent/Stackable Fast Ethernet Switch with 24 10BASE-T / 100BASE-TX (RJ-45) Ports, and Optional Media Expansion and Stack Modules...
- Page 4 +65 238 6466 Support: +888-398-4101 or +949-707-4847 Internet: www.acctontech.com RMA: +800-762-4968 Fax: +949-707-2460 Accton is a trademark of Accton Technology Corporation. Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respective companies. AC-ES3726M E012002-R01 F2.476 150200008100A...
- Page 5 Limited Warranty Accton Technology Corporation Limited Warranty: Accton warrants all is products to be free of manufacturing defects in workmanship and materials, under normal use and service, for the applicable warranty term. All Accton products carry a standard 90-day limited warranty from the date of purchase from Accton or its Authorized Reseller.
- Page 6 Limited Warranty LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.
-
Page 7: Table Of Contents
Contents Introduction Installing the Switch Package Contents Description of Hardware Mounting the Switch Stacking Switches on a Flat Surface Mounting Switches in a Rack Installing a Management Module Installing Optional Media and Stacking Modules Connecting to the Stack’s Backplane Connecting the Switch System Making a Connection to an RJ-45 Port Connecting to a 100BASE-FX Port Connecting to a Gigabit Fiber Optic Port... - Page 8 Contents Canada Department of Communications - Class A BSMI Class A (Taiwan) VCCI Class A Compliance (Japan) CE Mark Declaration of Conformance for EMI and Safety (EEC) Safety Compliance Warning: Fiber Optic Port Safety Avertissment: Ports pour fibres optiques - sécurité sur le plan optique Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit Underwriters Laboratories Inc.
-
Page 9: Introduction
Introduction The CheetahSwitch Workgroup-3726M is perfect for moving workgroups from conventional 10 Mbps Ethernet to multiple-segment 100 Mbps Fast Ethernet, and for consolidating your network equipment into a single, clean, efficient, and super-fast switch stack. This switch system delivers dedicated 100 Mbps links to each attached LAN segment (independent collision domain) or to any PC attached directly to the stack –... -
Page 10: Installing The Switch
Management Guide to set up its more advanced features, such as Spanning Tree Protocol or VLAN port groups. Package Contents This package includes: • CheetahSwitch Workgroup-3726M (Model No. AC-ES3726M) • Four rubber foot pads • This Quick Installation Guide • Rack mount bracket kit •... -
Page 11: Mounting The Switch
Installing the Switch The following figure shows the components of this switch system: Module System 10/100 Mbps Port Status Mode Indicators Indicators RJ-45 Ports Indicators Selection 100-240V~ 50-60Hz 2A DC INPUT Media or Stacking Media Management Power Connector Module Slot Module Slot Module Slot Socket... -
Page 12: Mounting Switches In A Rack
Quick Installation Guide Mounting Switches in a Rack Please comply with the following instructions to ensure that your switch is securely mounted in the rack. Use a standard EIA 19-inch rack. Use the brackets and screws supplied in the rack mounting kit. Use a cross-head screwdriver to attach the brackets to the side of the switch. -
Page 13: Connecting To The Stack's Backplane
Installing the Switch You can install a module as described below: Disconnect power to the switch (the modules are not hot-swappable). Remove the face plate on the appropriate slot by removing the two screws with a flat-head screwdriver. Before opening the package that contains the module, touch the bag to the switch casing to discharge any potential static electricity. -
Page 14: Connecting The Switch System
Quick Installation Guide Connecting the Switch System The CheetahSwitch Workgroup-3726M provides 24 RJ-45 ports on the base unit. Each of these ports supports a connection to 10 Mbps Ethernet or 100 Mbps Fast Ethernet, and supports full or half-duplex operation. The transmission speed for each port is automatically set by the switch to match the highest speed supported by the connected device. -
Page 15: Connecting To A 100Base-Fx Port
Installing the Switch switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices. Connecting to a 100BASE-FX Port If you connect fiber cable to the 100BASE-FX module, be sure you use an SC-type connector. -
Page 16: Powering On The Switch
Quick Installation Guide 1000BASE-SX and 1000BASE-LX fiber optic cable depends on the core size and the rating of the cable, as shown in the following tables. Maximum 1000BASE-SX Gigabit Ethernet Cable Length Fiber Size Fiber Bandwidth Maximum Cable Length 62.5/125 micron 160 MHz/km 2-220 m (7-722 ft) multimode fiber... -
Page 17: Verifying Port Status
Installing the Switch Verifying Port Status Check each connection by viewing the port indicators on the base unit front panel. Their staus is shown in the following table. S tate Indication System Power Switch is receiving power. Redundant power unit on. Mgmt Management agent operational. -
Page 18: Applications
Quick Installation Guide • See if your cable is functioning properly by using it for another port and attached device that displays valid indications when connected to the network. • Be sure no twisted-pair cable exceeds 100 meters (328 feet). 100 Mbps fiber cable should be under 2 kilometers (1.24 miles). -
Page 19: Product Specifications
Product Specifications Printers Switch at remote site (via fiber link) Servers CheetahSwitch Stack 100M Hub Stack Collapsed Backbone Hub Stack (via Gigabit link) Product Specifications Base Unit Physical Characteristics Access Method CSMA/CD Standards Conformance IEEE 802.3, IEEE 802.3u Communication Rate 10/100 Mbps Communication Mode Full or half duplex... -
Page 20: Switching Criteria
Quick Installation Guide Temperature Operating: 0~50 °C / 32~122 °F Storage: -40~70 °C / -40~158 °F Humidity 5% to 95% (noncondensing) Certification CE Mark Emissions FCC Class A, VCCI Class A, CISPR Class A, EN 61000-3-2/3 Immunity IEC 61000-4-2/3/4/5/6/11 Safety CSA/NRTL, TÜV/GS Switching Criteria Network Bridging Function Filtering, forwarding and learning... -
Page 21: 1000Base-Sx Module (Em4582-Sx-Sc)
Troubleshooting 1000BASE-SX Module (EM4582-SX-SC) Access Method CSMA/CD Standards Conformance IEEE 802.3z Communication Rate 1000 Mbps Communication Mode Full or half duplex Media Supported 50/125 micron or 62.5/125 micron multimode fiber Output Power Minimum: -9.5 dBm, Maximum: -4 dBm Receiver Sensitivity Minimum: -20 dBm, Saturation: -3 dBm Power Budget 16 dBm... -
Page 22: Power And Cooling Problems
Quick Installation Guide Symptom Cause Solution Power indicator Power outlet, power Check the power outlet by plugging in another device does not light up cord, or internal power that is functioning properly. Check the power cord with after power on. supply may be another device. -
Page 23: Port And Cable Assignments
Port and Cable Assignments Port and Cable Assignments RJ-45 Port Description RJ-45 station ports (MDI-X) can be attached to any devices that use a standard network interface (e.g., a workstation, server, bridge or router). RJ-45 daisy-chain ports (MDI) can be cascaded to a station port on similar networking devices (e.g., another switch or hub). -
Page 24: Emi Certification
Quick Installation Guide EMI Certification FCC Class A Certification (USA) Warning: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A digital device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 25: Ce Mark Declaration Of Conformance For Emi And Safety (Eec)
EMI Certification CE Mark Declaration of Conformance for EMI and Safety (EEC) This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC. -
Page 26: Safety Compliance
Quick Installation Guide Safety Compliance Warning: Fiber Optic Port Safety When using a fiber optic media expansion module, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber cable ends when they are powered on. Avertissment: Ports pour fibres optiques - sécurité... -
Page 27: Wichtige Sicherheitshinweise (Germany)
Safety Compliance Wichtige Sicherheitshinweise (Germany) Bitte lesen Sie diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein. -
Page 28: Optional Hardware Modules
Quick Installation Guide Optional Hardware Modules AC-ES3726M-AGENT: SNMP/RMON Management Module with RS-232 Port EM3582-FX-SC: Media Module with 2 100BASE-FX (SC-type) Ports EM4582-SX-SC: Media Module with 1 1000BASE-SX (SC-type) Port EM4582-LX-SC: Media Module with 1 1000BASE-LX (SC-type) Port EM3580-STACK: Stacking Module kit including 30 cm stacking cable RPU150W: Redundant Power Supply ST5002:... - Page 30 AC-ES3726M E012002-R01 F2.476 150200008100A...
