Lorex SG7213P Specifications

WEATHER RESISTANT
CCD OBSERVATION CAMERA
MODEL: SG7213P
F E A T U R E S
• Weather resistant * housing ideal for indoor/outdoor use
• Built-in speaker and microphone to allow for two way audio
communication
• Optional PIR motion sensor automatically brings trouble
location to full-screen display
• 6 LED's for viewing up to 2M in low light conditions
• Metal mounting bracket ideal for wall or table mounting
applications
• 20 m cable included
* Weather resistant against dust and light rain
SPE CIFI C ATI O N S
Image Sensor: 1/3" B&W CCD
Video Format: CCIR
Effective Pixels: 500H x 582V
Resolution: 380 TV Lines
Sync System: Internal
AES: 1/50 ~ 1/80000 Sec
Min. Illumination: 0.5 Lux
Lens: 3.6mm F2.0
Viewing Angle: Diagonal 90º
Operating Voltage: 12V DC
Operating Temperature: -10 ~ 45 degree C
Dimension (WxDxH): 57 x 114 x 50 mm
Environmental Rating: IP44
StrAtegic ViStA internAtionAl inc.
3700 Koppers Street, Suite 100
Baltimore, Maryland 21227,
USA.
B U S I N E S S A N D H O M E S E C U R I T Y
* B&W 1/3"
Approvals:
INTERNATIONAL
INTERNATIONA L
www.lorexcctv.com
As our product is subject to continuous improvement, SVII & subsidiaries reserve the right to modify product design,
specifications & prices without notice and without incurring any obligation. E&OE
©2005 Strategic Vista International Inc.
