4. Camera Specifications
Specifications:
Image Sensor
1/4" Color CCD Image
Effective Pixels
H: 512, V: 492
Scanning System
2:1 Interlace NTSC
Resolution
420 TV Lines
Video Output
1.0 Vpp @ 75 OHM
Lens
3.6mm Fixed F 2.0
White Balance
AWB
AES
On 1/60~1/ 15,000Sec
Sync. System
2:1 Interlace NTSC
Min. Illumination
3.0 LUX
Viewing Angle
70 Degree
180mA
Power Consumption
Power Supply
12 V DC
Less than 90%
Operating Humidity
°
Operating Temp
14
F ~ 122
°
(-10
~ 50
Dimensions:
It's all on the web
Product Information
User Manuals
Quick Start Guides
°
F
°
)
C
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
BUSINESS AND HOME
INDOOR/OUTDOOR
DAY/NIGHT
COLOR CAMERA
Model: SG7221 Series
English Version 1.0
Quick Set-up Guide
Advertisement
Table of Contents
Related Manuals for Lorex SG7221 Series
Summary of Contents for Lorex SG7221 Series
-
Page 1: Color Camera
LOREX Technology Inc. Copyright © 2008 LOREX Technology Inc. As our products are subject to continuous improvement, LOREX and its subsidiaries reserve the right to mod- ify product design, specifications and prices, without notice and without incurring any obligation. E&OE... - Page 2 • SG7221R connects to any TV or Lorex PCI cards (QLR Series) with RCA connector. A coupler: RCA (female) to BNC (male) is required in order to connect to DVRs and Observations Systems with BNC connectors (BNCA sold separately).
