Analog way OFX803 Specification

Octo FX²
Octo FX²
> HD Seamless Switcher for Conference Rooms, Houses of Worship
and Large Screen Projections
> 8 Universal Inputs with Audio:
- PAL / NTSC / Secam, S.Video, RGB, YUV, HDTV
- Computer up to UXGA
> Analog and digital inputs/outputs up to 1080p
> Animated or Still Logo, Fade, Titling, Cut and Frame Stores
Transition effect
selection
Convenient input access
Function
Optional LAN control
RS232 Com Port
Standard IEC international
power connector
Direct input selection
with LED
Freeze
Universal inputs on BNC, HD15 female
and DVI connectors (Computer,
Video, HDTV, DVI)
Main outputs: 1 DVI-I
and 1 RGB
TM
Easy to read LCD screen
Menu controls
Main audio inputs and output on
MCO and 3.5mm jack connectors.
Stereo inputs with individual line
control, output volume and
balance control
Model OFX803
Inputs
- 8 universal inputs with 1 DVI
- Computer and DVI up to
UXGA / 1080p
- Video : NTSC/PAL/SECAM,
S. Video, YUV, RGB, HDTV
- 8 + 1 Stereo Audio with level
adjustment for each input
Outputs
- Main: 1 DVI + 2 RGB
up to UXGA / 1080p
- Audio Stereo Main with level
adjustment
Effects
- Fade, Titling, Seamless Cut
- Ultra fast and smooth or
colored switching
- Logo insertion : 1 still or 8
animated logos
- 4 frame stores in non volatile
memory
www.analogway.com
P/N: OVP831-B1206-VA
