Transformer Settings

I/O5T and I/O8T Models

IMPORTANT NOTE:

DO NOT USE TAP IN POSITION ONE (8 ohm) on
70V/100V SYSTEMS. DAMAGE WILL OCCUR.
Please refer to the tap setting label before making a tap selection. This label can be
removed after setting. Tap setting diagrams are also included on the back of the speaker.
I/O5T Tap Label
Back of Speaker
I/O8T Tap Label
Back of Speaker
I/O Series Owner's Manual
Tap Label
Bottom of Speaker
