Vertical Position; Horizontal Position - Community I/05 Owner's Manual

I/O8 Infin-A-Ball Mounting Bracket

Vertical Position

PICTURE HANGER
M10 SET SCREW
M6 FLAT HD BOLT
WALL MOUNT BRACKET
AND BALL ASSEMBLY

Horizontal Position

M10 SET SCREW
M6 FLAT HD BOLT
WALL MOUNT BRACKET
AND BALL ASSEMBLY
I/O Series Owner's Manual
I/O8 CABINET
M10
I/O8 BLACK ZINC
HEX NUT
BALL SOCKET
I/O8 CABINET
M10
HEX NUT I/O8 BLACK ZINC
BALL SOCKET
