Gefen 1x4 HDMI Splitter User Manual
Hide thumbs Also See for 1x4 HDMI Splitter:

Advertisement

1x4 HDMI
Splitter
U S E R
M A N U A L
www.gefen.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1x4 HDMI Splitter and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gefen 1x4 HDMI Splitter

  • Page 1 1x4 HDMI Splitter U S E R M A N U A L www.gefen.com...
  • Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 1x4 HDMI Splitter is a trademark of Gefen Inc. HDMI is a trademark of hdmi.org...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction Features Panel Descriptions Connecting and Operating the 1x4 HDMI Splitter Specifi cations Warranty...
  • Page 4: Introduction

    HDTV HDMI compatible monitors or projectors. Simply connect your HDTV displays to the DA's display outputs. The 1x4 HDMI Splitter can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.
  • Page 5: Features

    • HDMI or DVI to HDMI cables are used to connect to the inputs or outputs • HDCP compliant • Fully HDMI 1.2 compliant • Installs in seconds Includes: (1) 1x4 HDMI Splitter (1) 6 foot HDMI cable (M-M) (1) 5VDC Power Supply (1) Users Manual...
  • Page 6: Panel Descriptions

    PANEL DESCRIPTIONS...
  • Page 7: Connecting And Operating The 1X4 Hdmi Splitter

    How to Connect the 1x4 HDMI Splitter to your devices 1 Connect the supplied cable from the HDTV HDMI sources into the 1x4 HDMI Splitter input. HDMI to HDMI cable for HDMI source or HDMI to DVI cable for DVI source.
  • Page 8 DIP SWITCH GUIDELINES Inside the 1x4 HDMI Splitter is a bank of Dip Switches. Below is a table describing their functions. By default, all switches are set to the Off position. Dip Switch # Name Description Switching Delay Adds a 3 second delay to switching...
  • Page 9: Specifi Cations

    SPECIFICATIONS Video Amplifi er Bandwidth ................1.65 Gbps Input Video Signal ..................1.2 volts p-p Input DDC Signal ..................5 volts p-p (TTL) Single Link Range ................1080p / 1920 x 1200 Input Connector Type ............HDMI Type A 19 pin female Output Connector Type ............HDMI Type A 19 pin female Power Consumption ................
  • Page 10: Warranty

    If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
