Ultra Go Par7X
The ADJ RFC remote (sold seperately) has many different functions and al-
lows you to control your Ultra Go Par7X from long distance. The ADJ RFC
remote can control your system up to 150 ft. To use the RFC you must first
activate the fixtures receiver, to activate the receiver please see the instruc-
tions on page 10.
BLACKOUT - Pressing this button will blackout the fixture. Press this but-
ton for more then 3 seconds to activate default running mode. All modes will
return to their default settings.
AUTO RUN - This button will run 1 of 3 auto run programs. Each press
of the button will scroll through Color Fade, Color Change, and Random.
When you activate Color Fade, you can use the "+" and "-" buttons to scroll
through the 8 different color fade modes. When you activate Color Change,
you can use the "+" and "-" buttons to scroll through the 8 different color
change modes. You can control the fade speed and color change speed of
the Auto Run by pressing the speed button and then adjust the speed using
the "+" and "-" buttons.
PROGRAM SELECTION - This button will activate Static Color mode.
Press this button to activate Static Color mode. Use the "+" or "-" to scroll
through the 35 colors. Once you have found your color, you can press the
Flash Button to activate strobing and use the "+" or "-" to adjust the Flash
rate.
FLASH - This button will activate the flash (strobe) effect. You can control
the flash speed by pressing the "+" and "-" buttons.
SPEED - Press this button and use the "+" & "-" buttons to adjust the speed
of the Built-In Programs.
SOUND ACTIVE - This button activates sound active mode. Use the "+" &
"-" buttons to scroll through the 8 sound active modes. Press this button
againg to switch to sound sensitivity adjustment and then use the "+" & "-"
buttons to adjust the sound sensitivity level.
R G B - Press either one of these buttons and the press the "+" or "-" to ad-
just the brightness.
"+" and "-" - Use these buttons to adjust the flash rate, speed of the Auto
Run, fade speed, sound sensitivity, and output intensity. Use these buttons
to scroll through the static colors.
ADJ Products, LLC - www.adj.com - Ultra Go Par7X User Manual Page 16
©
ADJ RFC Operation Ultra Go Par7X 1 Channel - DMX Values & Functions
Channel Value
1
0 - 10
11
- 17
18 - 24
25 - 31
32 - 38
39 - 45
46 - 52
53 - 59
60 - 66
67 - 73
74 - 80
81 - 87
88 - 94
95 - 101
102 - 108
109 - 115
116 - 122
123 - 129
130 - 136
137 - 143
144 - 150
151 - 157
158 - 164
165 - 171
172 - 178
179 - 185
186 - 192
193 - 199
200 - 206
207 - 213
214 - 220
221 - 227
228 - 234
235 - 241
242 - 248
249 - 255
ADJ Products, LLC - www.adj.com - Ultra Go Par7X User Manual Page 17
©
Function
COLOR MACROS
OFF
BASTARD AMBER
MEDIUM AMBER
PALE AMBER GOLD
GALLO GOLD
GOLDEN AMBER
LIGHT RED
MEDIUM RED
MEDIUM PINK
BROADWAY PINK
FOLLIES PINK
LIGHT LAVENDER
SPECIAL LAVENDER
LAVENDER
INDIGO
HEMSLEY BLUE
TIPTON BLUE
LIGHT STEEL BLUE
LIGHT SKY BLUE
SKY BLUE
BRILLIANT BLUE
LIGHT GREEN BLUE
BRIGHT BLUE
PRIMARY BLUE
CONGO BLUE
PALE YELLOW GREEN
MOSS GREEN
PRIMARY GREEN
DOUBLE CTB
FULL CTB
HALF CTB
DARK BLUE
WHITE
FULL RED
FULL GREEN
FULL BLUE
