6. Cut the plastic tie in the Left Handrail (88) and
the Right Handrail (not shown). If necessary,
press the 5/16" Cage Nuts (31) back into place.
Identify the Left Handrail (88) and hold it near
the Left Upright (89). Insert the Upright Wire
(81) through the bracket on the bottom of the
Left Handrail. Pull the Upright Wire out of the
end of the Left Handrail.
7. Attach the Left Handrail (88) to the Left Upright
(89) with two 5/16" x 1" Bolts (5), two 5/16" Star
Washers (11), and a 5/16" x 1 1/4" Bolt (4). Do
not fully tighten the Bolts yet.
Attach the Right Handrail (87) in the same
way.
6
81
31
Tie
89
7
5
11
4
88
89
9
88
4
11
87
5
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the Performance 600 and is the answer not in the manual?
Questions and answers
Belt on proform performance 600c has slid too far to the left and the lefdt side of the belt is turned over by a q1/2 inch. belt is tight and I tried to turn hex screw and that isn't helping.
To fix a misaligned belt on a ProForm Performance 600 treadmill:
1. Remove the key and unplug the power cord.
2. If the belt has shifted to the left, use a hex key to turn the left idler roller bolt clockwise 1/2 turn.
3. If the belt has shifted to the right, turn the left idler roller bolt counterclockwise 1/2 turn.
4. Be careful not to overtighten the belt.
5. Plug in the power cord, insert the key, and run the treadmill for a few minutes.
6. Repeat the adjustment if necessary until the belt is centered.
This answer is automatically generated
