USB 3.0 SATA III (6 Gbps) Adapter
Cable for 2.5in or 3.5in Hard Drives
USB3S2SATA3
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 02/15/2013
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com USB3S2SATA3
Summary of Contents for StarTech.com USB3S2SATA3
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 02/15/2013...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................3 Hardware Installation ..........................3 Driver Installation ............................3 Verifying Installation ................4 Windows ............................... 4 Software Installation ..........................4 How to Use ..............................5 Software ............................... 6 Specifications ..................7 Technical Support ..................8 Warranty Information ................8... -
Page 4: Introduction
Introduction The USB3S2SATA3 USB 3.0 to SATA Adapter connects any standard 2.5in or 3.5in SATA (6Gbps) hard drive (HDD), solid state drive (SSD), or optical drive to a computer through SuperSpeed USB 3.0. The USB 3.0 to SATA III adapter lets you externally connect a bare drive with no drive enclosure or HDD dock required, saving time, hassle and added cost. - Page 5 Front View Power/Actvity LED Backup Button 22-Pin SATA DATA/ Power Connector Rear View Power Jack Instruction Manual...
-
Page 6: Installation
Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation 1. Connect a 2.5” or 3.5” SATA HDD/SSD or Optical drive to the 22-pin SATA connector on the adapter. -
Page 7: Verifying Installation
Verifying Installation Windows From the main desktop, right-click on “My Computer” (“Computer” in Vista/7/8), then select Manage. In the new Computer Management window, select Device Manager from the left window panel. Double-click on the “Disk Drives” option. A new disk drive should be listed under this category. -
Page 8: How To Use
How to Use Windows If you are using a brand new hard drive that does not contain any data, then you will first need to prepare the hard drive for use. From the main desktop, right-click on “My Computer” (“Computer” in Vista/7/8), then select Manage. In the new Computer Management window, select Disk Management from the left window panel. -
Page 9: Software
If you are installing a hard drive that already has data on it, then after plugging it in, the drive should automatically show up with a drive letter assigned within “My Computer”. Software To run the software, press the “Backup” button on the adapter or double-click the PC Clone icon on your desktop. -
Page 10: Specifications
Specifications Bus Interface SuperSpeed USB 3.0 Chipset ID ASMedia ASM1051E 1x 22-Pin SATA Receptacle Connectors 1x USB 3.0 Type B Female LEDs 1x Amber Power/Activity LED Maximum Data Transfer Rate USB 3.0: 5Gbps Compatible Drives 2.5”/3.5” SATA HDD/SSD/Optical Color Black Power Adapter 12VDC, 1.5A, center positive, plug type M Operating Temperature... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
