USB 3.0 to SATA or IDE Hard Drive Adapter Converter
USB3SSATAIDE
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 04/16/2013
Advertisement
Table of Contents
Related Manuals for StarTech.com USB3SSATAIDE
Summary of Contents for StarTech.com USB3SSATAIDE
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 04/16/2013...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Hard Drive Adapter ........................... 2 Power Adapter ............................2 Installation ....................3 Hardware Installation ..........................3 Driver Installation ............................6 Specifications ..................7 Technical Support ..................8 Warranty Information ................8 Instruction Manual... -
Page 4: Introduction
Introduction Packaging Contents • 1x USB 3.0 to SATA/IDE converter • 1x SATA Cable • 3x AC Power Cord (NA/UK/EU) • 1x Power Supply • 1x Driver CD • 1x Instruction Manual System Requirements • Available USB 3.0 port • Available AC electrical outlet •... -
Page 5: Hard Drive Adapter
Hard Drive Adapter Power Adapter Instruction Manual... -
Page 6: Installation
Installation WARNING: • Do not disconnect any cables or power sources while the connected hard drive(s) is/are active. This can result in data loss and possible damage to the hard drive. To avoid this, please follow the steps outlined in the section entitled Removing Connected Drives. - Page 7 SATA Drive 1. Insert one connector provided by a SATA data cable, into the SATA port on the Hard Drive Adapter. 2. Insert the remaining connector provided by the SATA data cable, into the SATA data port on the SATA hard drive. 40/44-pin IDE Drive 1.
- Page 8 Connect the Drive(s) to the Power Adapter WARNING! When connecting the hard drive to the Power Adapter, please ensure that the mini-switches (located on the main power switch) are set to the OFF position, prior to establishing a connection. Failure to do so could result in damage to the drive, or an electrical shock to the user.
-
Page 9: Driver Installation
Removing Connected Drives WARNING! Do not remove a connected hard drive while the drive is in use. To prevent data loss or damage to the drive(s), please follow the instructions below. Removing a connected drive safely requires that the drive not be in use. To ensure that this is the case, you can remove the drive in one of the two following ways: 1. -
Page 10: Specifications
Specifications Host Interface USB 3.0 1 x 15 pin SATA Power female 1 x 4 pin Power (LP4) Female 1 x 40 pin IDE Female External Connectors 1 x 44 pin IDE Female 1 x 7 pin SATA Data male 1 x USB type A male 1 x USB Link LEDs... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
