- Page 1 Internal USB to PS2 Adapter Card USBPS2PLATE...
- Page 2 StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowl- edgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all...
-
Page 3: Table Of Contents
System Requirements ..............1 Hardware Guide ................2 Connectors ..................2 USB Pin Header Pin Assignment ..........2 USB Header Cable (supplied): Pin Assignment ......2 Installation ..................3 Specifications ................4 Accessory Products from StarTech.com ........4 Technical Support ................. 5 Warranty Information ..............5... -
Page 4: Introduction
Instruction Manual Introduction Thank you for purchasing a StarTech.com USB to PS2 Keyboard and Mouse Adapter. This innovative product allows you to connect two PS/2 devices, such as a keyboard and mouse to an internal USB port on your desktop PC, enabling the use of a PS/2 keyboard and mouse as USB plug-and-play human interface devices (HID). -
Page 5: Hardware Guide
Instruction Manual Hardware Guide Connectors PS/2 Mouse Connector PS/2 Keyboard Connector USB 4-pin header USB Female Port USB Pin Header Pin Assignment D+ (USB DP) D- (USB DM) +5V (USB VCC) USB Header Cable (supplied): Pin Assignment Red wire Please note: For USB boot-up support, the USB connector must be plugged in to a built-in type A or header connector on the motherboard... -
Page 6: Installation
(Pin 1) If no 4-pin USB Header connection is available on the motherboard, connect the USB Female port provided by USBPS2PLATE (shown as #4 on pg.2) to an available USB port on the rear panel of the computer. -
Page 7: Specifications
Power Mode USB Bus Powered Accessory Products from StarTech.com Contact your local StarTech.com dealer or visit www.startech.com for cables or other accessories that will help you get the best performance out of your new product. KXT102 6 ft. PS/2 Keyboard/Mouse Extension Cable KXT102_10 10 ft. -
Page 8: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or... - Page 9 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of computer parts, cables, A/V products, KVM and Serv-...
