Cybex Total Access 14130 Lat Pulldown Owner's Manual
C
A
C
NOTE: See exploded-view diagram for location of N (serial number decal).
DESCRIPTION
A. Placard Decal .................... 14130-598-4
B. Placard Decal .................... 14130-599-4
C. Caution Decal .................... 4000Y316-4
D. Caution Decal .................... 4520-362-4
E. Warning Label ................... 4605-381-4
F. Caution Decal .................... 8500-025-4
G. Warning Decal .................... 8500-311-4
H. Weight Stack Belt 224.55"..GB000202
LAT PULL
PRODUCT NO. 14130
E
F
G
DESCRIPTION
PART NO.
I. Water Bottle Holder.............13000-400
J. Thigh Pad w/Wear Cover ... 4800-196
K. Wear Cover ....................... 4800-199
L. Seat Pad ........................... 5207S043-0
M. Pulldown Bar ........................4005-105
N. Serial Number Decal
O. Weight Selector Pin............ BH030207
P. Increment Weight Decal..... 14000-407-4
H
M
B
P
O
L
I
J, K
F
D
PART NO.
Service
Page 6-3
