- Page 1 Cybex Total Access Leg Press Owner’s and Service Manual Strength Systems Part Number 14040-999-4 C www.cybexinternational.com...
- Page 3 Cybex International,Inc. DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
-
Page 5: Table Of Contents
Table of Contents Front Pages Table of Contents ....i Declaration of Conformity ..ii 1 Safety Safety . - Page 7 Page ii...
- Page 8 This page intentionally left blank.
-
Page 9: Safety
• Securely anchor each machine to the fl oor using the anchor holes provided in each machine. NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor. NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8” grade 2 bolts or better). -
Page 10: Safety Guidlines And Practices
SECURING EQUIPMENT: The machine has holes in the feet, which allow for ease in anchoring to the fl oor. Cybex strongly recommends that, to eliminate rocking, tipping or falling over due to incorrect usage and misuse, equipment be secured to a solid, level surface. -
Page 11: Warning/Caution Decals
Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance requirements as specifi ed in the manual. STANDARD COMPLIANCE: Cybex products meet or exceed applicable ASTM and EN Standards. Warning/Caution Decals Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury. - Page 12 Cybex Total Access 14040 Leg Press Owner’s Manual CAUTION Keep away from moving parts. Failure to do so could result in personal injury. 8500-026-4 4605-381-4 A Safety Page 1-4...
- Page 13 Cybex Total Access 14040 Leg Press Owner’s Manual Leg Press - 14040 (both sides) (both sides) (both sides) Description Part No. A. Warning Label....4605-381-4 B. Caution Decal.....8500-025-4 C. Caution Decal.....8500-026-4 Safety Page 1-5...
-
Page 14: Regular Maintenance Activities
Cybex Total Access 14040 Leg Press Owner’s Manual Regular Maintenance Activities Preventative maintenance activities must be performed to maintain normal operation of your equipment. Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative maintenance activities. -
Page 15: Exercises
Cybex Total Access Owner’s Manual 2 - Exercise MUSCLES USED Intended Use The intended use of this equipment is to aid or improve general physical fi tness and exercise. For commercial use. Instruction Read and understand all instructions and warnings prior to using this machine. - Page 16 Cybex Total Access Owner’s Manual Set Up - Consult fl oor staff if assistance is required. 1. Adjust seat to comfortable start position for knees and hips. 2. Position feet comfortably on foot plates with toes pointed slightly outward. Movement 1.
-
Page 17: Customer Service
USA) or 508-533-4300 (for customers outside the USA). You may also contact us through e-mail at techhelp@cybexintl.com. Having the following information ready when calling will assist our Cybex representatives in serving you. • Unit Serial Number •... -
Page 18: Return Material Authorization (Rma)
3. Provide the model and serial number of your Cybex equipment. 4. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label. -
Page 19: Damaged Parts
Cybex Total Access Owner’s Manual Damaged Parts Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.) Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent. - Page 20 Cybex Total Access Owner’s Manual This page intentionally left blank Customer Service Page 3-4...
-
Page 21: Assembly
Cybex Total Access Owner’s Manual 4 - Assembly TOOLS REQUIRED • 7/32” Allen wrench • 1/8” Allen wrench • Medium weight automotive engine oil • Torque wrench • 3/4” Wrench NOTE: Two people will be required for this procedure. NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate clearance around each machine to allow for safe use and passage. - Page 22 Cybex Total Access Owner’s Manual Slide spring loaded top guide rod cap down guide rod until guide rod cap is clear of frame. NOTE: Top guide rod cap is spring loaded. Slowly release grasp of guide rod cap. NOTE: Guide rod cap contains a compression spring that will fl...
- Page 23 Cybex Total Access Owner’s Manual 6. Belt Routing. Correct belt routing Wrong belt routing Verify belt is routed through top of pulley bracket and Insert Insert then route end of belt down to the top weight. Belt Belt Carefully lift top weight and verify that the position of the...
- Page 24 NOTE: It is important that you perform regular inspection and maintenance activities on your equipment. See the CYBEX Owner’s Manual for inspection and maintenance activities. If you do not have a CYBEX Owner’s Manual or if you have any questions or concerns, call CYBEX Customer Relations at 888-462-9239.
-
Page 25: Maintenance
Cybex Total Access Owner’s Manual Chapter 5 - Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines. - Page 26 Protect surrounding area/clothing from exposure. Use in a well ven- tilated area. Follow all product manufacturer’s warnings. CYBEX and its vendors cannot be held responsible for damage or injuries resulting from the use or misuse of cleaning products.
- Page 27 Cybex Total Access Owner’s Manual 4. Guidelines for cleaning front panel: • Use clean soft cloths or sponges for application of cleaners and again for washing and rinsing. • Follow up the application with warm water rinse. • Don’t use abrasives or high alkaline cleaners.
-
Page 28: Weekly Procedures
Cybex Total Access Owner’s Manual Weekly Procedures 1. Check all nuts and bolts for looseness. Tighten as required. 2. Inspect all belts (entire length) for any non-uniformity and wear. Immediately replace belt if any of the following conditions are present:... - Page 29 Cybex Total Access Owner’s Manual 3. Some machines use cables in addition to belts. Inspect all cables for wear or damage and proper tension. When inspecting cables, run your fingers on the cable, paying particular attention to bends in the cable and attachment points.
-
Page 30: Yearly Procedures
Cybex Total Access Owner’s Manual 4. Inspect bars and handles for wear, paying particular attention to tab area connecting points. Replace all worn handles immediately. 5. Inspect snap links for proper latching (indicates wear). Replace all worn snap links immediately. -
Page 31: Environment
Cybex Total Access Owner’s Manual Environment Static Electricity - Depending upon where you live, you may experience dry air, causing a common experience of static electricity. This may be especially true in the winter time. You may notice a static build-up just by walking across a carpet and then touching a metal object. - Page 32 Cybex Total Access Owner’s Manual This page intentionally left blank Maintenance Page 5-8...
-
Page 33: Service
Cybex Total Access Owner’s Manual 6 - Service Please refer to the next several pages for parts lists, exploded-view diagrams and cable and belt routing diagrams. NOTE: All inspections and repairs must be performed by trained service personnel only. Cybex will void warranty if non-Cybex replacement parts are used. - Page 34 Cybex Total Access Owner’s Manual This page intentionally left blank Service Page 6-2...
-
Page 35: Leg Press
Cybex Total Access 14040 Leg Press Owner’s Manual LEG PRESS E (Both Sides) L (Both Sides) E (Both Sides) NOTE: See exploded-view diagram for location of M (serial number decal). DESCRIPTION PART NO. I. Back Pad w/Wear Cover ..4800-184 A. - Page 36 Cybex Total Access 14040 Leg Press Owner’s Manual Service Page 6-4...
- Page 37 Cybex Total Access 14040 Leg Press Owner’s Manual Service Page 6-5...
- Page 38 Cybex Total Access 14040 Leg Press Owner’s Manual LEG PRESS SEAT ASSEMBLY 63 62 Service Page 6-6...
- Page 39 Cybex Total Access 14040 Leg Press Owner’s Manual LEG PRESS PANEL ASSEMBLY Service Page 6-7...
- Page 40 Cybex Total Access 14040 Leg Press Owner’s Manual Top Weight Assembly (Light Stack and Heavy Stack Configurations) ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 11040-366 Top Weight Assembly, Molded HT562715 Tap SC NO 10 x .750 F Phil 11040-367...
- Page 41 Cybex Total Access 14040 Leg Press Owner’s Manual Belt Routing Assembly Detail Torque Set Screws 300-350 In/Lbs Service Page 6-9...
- Page 44 10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX 508-533-5183 www.cybexinternational.com • Techhelp@cybexintl.com...
