Telnet Users
SNMP Management
For Modem Connection
(Remote AccessBuilder Management Only). Connect the modem
(a DCE device) to a null modem cable conforming to the VT-100
specification to the AccessBuilder's console port (also DCE) on the rear
panel. The modem should be set to power up with default settings of:
9600 Baudrate, 8 bits, 1 stop bit and no parity.
It may be necessary to first connect the modem to a terminal in order
to reconfigure the modems' default settings to autoanswer, etc. (refer
to your modem documentation for this procedure). Once this is
accomplished, the modem connection can be moved to the
AccessBuilder 4000's console port.
(IP Only) If you wish to use Telnet to perform configuration, the \must
first have an IP address. This can be accomplished two ways:
1 Using TABMTOOL to detect the AccessBuilder's BootP request, then
assigning the IP address through TABM's AccessBuilder Configuration
Parameters dialog box. Note the TABM management station and the
AccessBuilder must on the same subnet.
2 Using the AccessBuilder's command line user interface via a modem or
local console. Refer to the section "Setting the AccessBuilder's IP
Address" in the Procedures section of TABM's on-line help or Chapter 2
of the AccessBuilder Configuration Guide.
The Telnet default port in TABM and the AccessBuilder is 3000. If you
need to change the default, use the System dialog box in TABM to
change the selected AccessBuilder. To change the default on your
workstation, refer to your Telnet third-party documentation for
procedures.
If you wish to manage or obtain operational statistics for the
AccessBuilder via an SNMP based network management station, such
as HP OpenView® or SunNet™ Manager, an AccessBuilder Enterprise
MIB is included on the backup diskette for this purpose. Refer to the
documentation provided with your network management MIB
compiler/parser software for instructions on how to integrate the
AccessBuilder MIB.
Note that in the case of an IP network, you must have previously
assigned an IP address to the AccessBuilder(s) you wish to manage.
Console/Modem Configuration (Optional)
2-11
