Technical Specifications; Parts Included - Bosch NWC?0495 Specifications

Installation/Configuration Notes
Dimensions in mm (in)
1 Lens connector
2 Control buttons
3 BNC video output
4 Alarm in, relay out

Parts Included

Quantity Components
1
XF
Dinion Day/Night IP Camera
1 Spare lens connector
1 C/CS mount conversion ring
1 Quick Installation Guide
1 CD-ROM with manual
5 Power supply input
6 10/100 Base-T Fast Ethernet
7 LED (power, link, traffic)
NWC‑0495 DinionXF Day/Night IP Cameras | 3

Technical Specifications

Electrical
Power
Input Voltage +11 to +36 VDC (700 mA)
12 to 28 VAC (700 mA)
Power over Ethernet
Power Consumption 8 VA (max)
Connector 2-pole push in
Video
Video Compression MPEG-4/H.264; M-JPEG
GOP Structure I, IP
Data Rate 9.6 Kbps to 6 Mbps (const. and variable)
Sensor 1/3 in. interline CCD
Sensor Matrix
PAL 752x582
NTSC 768x494
Resolutions and Frame PAL
Rates
4CIF: 25/30 IPS 704 x 576
2CIF: 25/30 IPS 704 x 288
half D1: 25/30 IPS 352 x 576
CIF: 25/30 IPS 352 x 288
QCIF: 25/30 IPS 176 x 144
Video out 1 x
Signal Analog composite (NTSC or PAL)
Connector BNC, 75 Ohm
Video S/N 50 dB
Sensitivity (F1.2, 50% signal, scene reflect. 89%)
Night Mode 0.08 lx (0.008 fc)
Color 0.59 lx (0.059 fc)
Minimum Illumination
Night Mode 0.0038 lx (0.00038 fc)
Color 0.024 lx (0.0024 fc)
BLC Off/area/level selectable
Gain Auto, selectable to 28 dB (max)
White Balance ATW (2500 to 10000 K)/AWB hold/man.
WB selectable
Auto Black On/off selectable
Sensitivity Up (SensUp) Off/auto continuous up to 10 x
Dynamic Range Up to 32 x
Dynamic Noise Reduction Off/auto selectable
Contour Sharpness enhancement, level selectable
Electronic shutter Fixed, flickerless, default
PAL (auto) 1/50 s to 1/500000 s (auto)
NTSC (auto) 1/60 s to 1/500000 s (auto)
NTSC
704 x 480
704 x 240
352 x 480
352 x 240
176 x 120
