Frequency range
Mic Out @ 18 dB Gain: 10 Hz-180 kHz (+/-3 dB, Phase –2°)
CMRR 100 Hz
18 dB Gain: -79 dB
34 dB Gain: -66 dB
60 dB Gain: -45 dB
w. Pad -16 dB @ 18 dB Gain: -90 dB
THD & N 1 kHz
60 dB Gain: 0,22 %
50 dB Gain: 0,07 %
40 dB Gain: 0,022 %
30 dB Gain: 0,007 %
18 dB Gain: 0,002 %
1 kHz 10 kHz
-79 dB -60 dB
-66 dB -52 dB
-45 dB -32 dB
-90 dB -79 dB
10 kHz
0,24 %
0,07 %
0,023 %
0,007 %
0,0023 %
S/N ratio (A-weighted)
150 Ohm generator, 22 Hz-22 kHz fi lter, 60 dB Gain@150 Ohm
Mic Out:
50 dB Gain@all:
40 dB Gain@all:
30 dB Gain@all:
18 dB Gain@all:
w. PAD -16 dB @ 18 dB Gain:
Overload resistance
Specifi cations
-66,8 dB
-77,2 dB
-85,8 dB
-93,6 dB
-96,4 dB
-97,5 dB
+22 dB
