Specifications

22
Audio
Frequency Response
CMRR
(at 1 kHz with 0 dBu input level/unity gain )
THD&N
(0 dBu input level/unity gain)
Noise
(A-weighted)
Dynamic Range
Input
XLR connector, electronically balanced,
optionally transformer balanced
Impedance
Max. Input Level
Outputs
XLR connectors, electronically balanced,
Output 1 optionally transformer balanced
Output 1
Impedance
Max. Output Level
Output 2
Impedance
Max. Output Level
Dimensions & Weight
Height x Width x Depth
Weight
Weight with Transformers
10 Hz - 70 kHz
-80 dBu
0,019%
-89 dBu
111,0 dB
ca. 20 kOhm
+21 dBu
ca. 150 Ohm
+22 dBu
ca. 150 Ohm
+22 dBu
132 mm x 46,9 mm x 315 mm/
5.17 x 1.85 x 12.40 inches
0,45 kg/0.99 lbs
0,65 kg/1.43 lbs
RackPack: Transient Designer
