GT Racer
Kar
t
™
GT Racer
™
Kar
t
™
Owner's Manual
with Assembly Instructions
For Model C0532
Please read this manual and save
it with your original sales receipt.
Tools needed for assembly: Phillips
Screwdriver and Adjustable Wrench
(tools not included).
Use only with a Power Wheels
®
12 Volt Lead-Acid Rechargeable
Battery and Power Wheels
®
12 Volt Charger with Type "12V"
Connector (included).
Product features and decoration
may vary from the picture above.
Helmet not included.
www.powerwheels.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Power Wheels GT Racer Kart
Summary of Contents for Power Wheels GT Racer Kart
- Page 1 Please read this manual and save it with your original sales receipt. Tools needed for assembly: Phillips Screwdriver and Adjustable Wrench (tools not included). Use only with a Power Wheels ® 12 Volt Lead-Acid Rechargeable Battery and Power Wheels ®...
-
Page 2: Table Of Contents
Please see Battery Charging the maximum weight capacity of 120 lb. (54.4 kg). beginning on page 7 for detailed instructions. • If you have any questions about your Power Wheels ® • Read this manual carefully for important safety... -
Page 3: Warnings And Cautions
- Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - Use of Power Wheels ® components in products other than Power Wheels ® vehicles could cause overheating, fire or explosion. -
Page 4: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts Rear Bumper Wing 2 Struts (Left and Right) P b P b 12 Volt Battery 2 Flaps 12 Volt Charger 4 Caps (Left and Right) Parts not shown: Label Sheet, Hot Wheels Racing Guide, Collapsible Pylons, Stencil, and Chalk. ®...
-
Page 6: Parts Diagram
Parts Diagram No. Part Quantity No. Part Quantity Parts Not Shown Frame Pretend Motor " - 20 x 3" Screw Steering Linkage Seat " Washer Rear Bumper Wing " Washer Steering Column Flap (Left and Right) " - 20 Lock Nut Cowling Strut (Left and Right) "... -
Page 7: Battery Charging
12V connector (120 VAC 60 Hz 28W with an output of have replaced the worn or damaged part. 12 VDC 1200mA) to charge your Power Wheels ® rechargeable 12 volt battery. -
Page 8: Assembly
Battery Charging Assembly WARNING Battery Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. - Page 9 Assembly Cowling Assembly Frame Bottom View • Turn the frame on its side. • Insert four #8 x " screws into the holes in the bottom of the frame and into the cowling assembly. Tighten the screws. • Fit the cowling assembly into the front end of the frame. Steering Tube Hint: Squeeze the cowling assembly slightly (on each Curve Faces...
- Page 10 Assembly Steering Wheel Closed End Faces Rear of Frame Steering Linkage Side View Hand-tighten Bottom View • Turn the frame on it’s side. Fit a " - 16 lock nut onto each end of the steering tube. Make sure the rounded side is facing out.
- Page 11 Assembly Rear Bumper Top View • From the top side of the frame, attach a " washer and " - 20 lock nut to each screw. • Fit the rear bumper onto the rear end of the frame. • While holding the 3" screws steady with a Phillips screw- driver, tighten the lock nuts with an adjustable wrench.
- Page 12 Assembly Left Flap Right Flap Wing • Fit a cap over each retainer. Hint:There is a left and right flap. Locate the L on the left • Insert a #8 x " screw through each cap and tighten. flap and an R on the right flap. •...
- Page 13 Assembly Seat Assembly • Slide a " washer onto two #8 x " screws. • Insert the #8 x " screws with washers through the seat and into the wing. Tighten the screws. Hint: The wing is designed to be adjustable. Please refer to the Hot Wheels ™...
- Page 14 Assembly Stopwatch Battery Compartment Door Shown Actual Size Hint: The stopwatch comes with an alkaline button cell battery. Use the following instructions only to replace the button cell battery. • Loosen the screws in the stopwatch battery • Slide the stopwatch into the groove in the steering wheel. compartment door.
-
Page 15: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... -
Page 16: Battery Installation
Battery Installation IMPORTANT! Use only a Power Wheels ® 12 volt battery. Use of any other battery will damage your vehicle. Make Tabs sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ®... -
Page 17: Battery Care And Disposal
• Do not store the battery in temperatures above 75° F or below -10° F. • Use only a Power Wheels 12 volt battery. Remember ® to charge the new battery at least 18 hours before first time use. -
Page 18: Rules For Safe Driving
Rules for Safe Driving RIDING HAZARD 8. Do not allow any child to drive the vehicle in the dark. WARNING A child could encounter unexpected obstacles and have an accident. Operate the vehicle only in the daytime or a well-lit area. Prevent Injuries and Deaths 9. -
Page 19: Ready
• To ensure that your vehicle stays in good operating order, we recommend that you periodically have your vehicle checked by a Power Wheels authorized service center. ® For the location of the authorized service center nearest to you, visit us on-line at www.powerwheels.com. -
Page 20: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center. -
Page 21: Problems And Solutions Guide
Do not drive up hills or run into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors. If a thermal fuse continually trips, contact your local Power Wheels ® authorized service center. -
Page 22: Problem Possible Cause
Replace the LR44 button cell battery in the stopwatch. stopwatch does not function at all. If, after reviewing the Problems and Solutions Guide, the vehicle still fails to operate, please contact your nearest authorized service center or contact Power Wheels ® Consumer Relations toll-free at 1-800-348-0751. -
Page 23: Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ®... - Page 24 Mattel, Inc. in the U.S. and/or other countries. Fisher-Price, Power Wheels, and Power Wheels by Fisher-Price, Power Lock and Power Stick are U.S. trademarks of Mattel, Inc. ©2003 Mattel, Inc. All Rights Reserved. ® and ™ are registered trademarks of Mattel Inc.
