g.
Press
until the weekend schedule is displayed (Fig.
23).
h.
Set the Saturday and Sunday WAKE time by pressing
or
until the desired time is displayed.
i.
Set the Saturday and Sunday WAKE temperature by pressing
or
(Fig. 24).
j.
Press
again to display a blank schedule for the SLEEP
program period and repeat steps h. through j. to set the
program.
Step 4. Program the cooling schedule
a.
Write in the times and temperatures that you want to program for your cooling schedule.
Cooling
Program
Schedule
period
Suggested
Time
Settings
Temp
Weekday
Time
(Mon–Fri)
Temp
Weekend
Time
(Sat–Sun)
Temp
69-0654-5
until the desired temperature is displayed
WAKE
6:00
AM
78°F (25.5°C)
LEAVE
RETURN
8:00
AM
85°F (29.5°C)
78°F (25.5°C)
SLEEP
6:00
10:00
PM
82°F (28°C)
PROGRAMMING
Fig. 23
Fig. 24
PM
15
