2 Port RS232 PCI Express Serial Card
with Power Output
PEX2S952PW
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 09/22/2011
Advertisement
Table of Contents
Related Manuals for StarTech.com PEX2S952PW
Summary of Contents for StarTech.com PEX2S952PW
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 09/22/2011...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................2 Jumper Configuration ..........................2 Hardware Installation ..........................3 Driver Installation ............................4 Verifying Installation ..........................5 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Introduction
Introduction The PEX2S952PW 2 Port PCI Express RS232 Serial Adapter Card with Power Output turns a PCI Express slot into 2 RS-232 (DB9) serial connections and the ports provide power output to your devices. Suitable for many RS232 powered serial applications, and including both low and full... -
Page 5: Installation
WARNING! PCI Express cards, like all computer equipment, can be severely damaged by static electricity. Be sure that you are properly grounded before opening your computer case or touching your PCI Express card. StarTech.com recommends that you wear an anti-static strap when installing any computer component. -
Page 6: Hardware Installation
Serial Port 2 Normal Hardware Installation 1. Turn your computer off and any peripherals connected to the computer (i.e. Printers, external hard drives, etc.). Unplug the power cable from the rear of the power supply on the back of the computer and disconnect all peripheral devices. 2. -
Page 7: Driver Installation
5. Connect an LP4 Molex power connector from the computer power supply, to the power connector on the card. 6. Place the cover back onto the computer case. 7. Connect the DB9 breakout cable to the external 44-pin connector on the card. 8. -
Page 8: Verifying Installation
Verifying Installation Windows 2000/XP/Server 2003/Vista/Server 2008 R2/7 From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then select Manage. In the new Computer Management window, select Device Manager from the left window panel. *screenshots are for reference only Double-click on the “Ports (COM &... -
Page 9: Specifications
Specifications PCI Express v1.1 Host Interface (x1 slot connector) Form Factor Standard Profile Chipset ID PLX OXPCIe952 2 x 9-pin DB9 male Connectors 1 x LP4 Molex male Serial Protocol RS-232 Output Voltage 5V / 12V Surge Protection ±15KV ESD on all signal pins Maximum Data Transfer Rate 920 Kbps Data Bits... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
