Specifications; Inputs; Outputs; Switching - Ocean Matrix OMX-PSW6AB Instruction Manual

OMX-PSW6AB
The OMX-PSW6AB is a passive 6 x 1 balanced stereo audio switcher. Featuring high quality 1/4" inch
Tip-Ring-Sleeve connectors, the OMX-PSW6AB offers a quick and solution to the requirement for fast
audio selection from multiple sources into one source. As an audio port expander the product elimi-
nates the need for patching and performs as a simple 6 x 1 router. As an assignment switcher the
OMX-PSW6AB can be used to feed a single balanced audio output to 6 selectable destinations by
simply pushing a button. The OMX-PSW6AB is a workhorse unit designed for today's demanding
multi-format production facilities where a transparent audio switcher is in demand. In conjunction with
our OMX-PSW6RS 422 switcher, this combination is a powerful answer to the single port configura-
tions of Non-linear edit systems.

SPECIFICATIONS

INPUTS:

6 Stereo 1/4" Phone Balanced TRS

OUTPUTS:

1 Stereo 1/4" Phone Balanced TRS

SWITCHING:

6 Positions interlock-lockout

DIMENSIONS:

1.625"H x 8.25"W x 6"D, Steel Housing

OPTIONS:

RK-1 rackmount kit
800 Kings Highway • Saugerties, NY 12477
A Division of Tower Products, Inc.
6x1 Balanced Stereo Audio
Passive Switcher
