single-phase UPS
Comet EXtreme
4.5/6/9/12 kVA
Enhanced protection for service sector
environments
High availability
UPS and battery fully interchangeable
on-line: thanks to the manual bypass,
there is no interruption of the power
supply to the protected position
during replacement of the UPS or the
battery.
In addition to the manual bypass, the
Comet EXtreme is equipped as
standard with an automatic bypass
which transfers the load to the mains
supply in the event of an overload or a
fault.
No demand on the batteries over a wide
range of input voltages (85 to 265 Volts).
Manual bypass
Choice of battery capacities
Standard battery capacity ranging from
20 minutes (at 70 % load) up to several
hours with battery extension modules.
Very long endurance (up to 8 hours
at full power) with the CLA charger
module.
Protection for equipment which
is sensitive to electromagnetic
interference:
Comet EXtreme conforms to the most
stringent EMC standards (Level B):
standard version: rack format,
optional tower format.
Entreprise Networks
Perfect integration
into service sector
environments
Rack format
8 U (1 x 4 U battery module +
1 x UPS 4 U module) for the
4.5 and 6 kVA versions.
13 U (2 x 4 U battery modules +
1 x UPS 5 U module) for the 9
and 12 kVA versions.
Compatible with racks from
600 to 900 mm deep.
Optional Comet PDU: IEC 10 A
and 16 A terminal block to
facilitate electrical distribution
in the rack (electrical panel not
required).
Tower format
Less than 450 mm high, the
Comet Extreme can easily be
installed beneath a console table, a
reception desk or in a power room.
Visual and audible check
LEDs and an audible alarm on the
front panel of the Comet EXtreme
provide instant identification
of the alarms and rapid
verification of the status
of the UPS.
www.mgeups.com
Telecom
Protection for 20 to 55 servers,
ideal for:
sets of PCs, servers and workstations
departmentalised IT systems
With its 2 rack or tower formats,
the Comet Extreme is particularly
easy to integrate into service sector
environments.
Comet Extreme conforms to the most stringent EMC
standards (Level B).
