Setting Up

How To Connect

Laptop or desktop computer
MOUSE
Before starting, make sure that the projector and computer are both turned off.
Connect the computer cable.
Connect either end of the computer cable to the projector's RGB IN.
Connect the computer cable from the computer to the projector.
If needed, connect the MONITOR OUT to a monitor to view input from RGB IN.
Tighten the screw on all connectors.
RS-232 AUDIO OUT VGA OUT DVI OUT AUDIO OUT
S-VIDEO OUT
AUDIO IN
VIDEO OUT AUDIO OUT (L)&(R)
14
(Please click here if your projector is
with high efficiency filter.)
VGA OUT RGB IN
Y Pb/Cb Pr/Cr
