Outlet State
On/Error
Off/Error
Off/Fuse
No Comm
* Control State will be applied when communication is re-established

Environmental Monitoring

The Environmental Monitoring section offers access to the Input Load page. This
section is available to administrative level users and users with Environmental
Monitoring view rights.
Input Load
The Input Load page displays the absolute and descriptive name and the cumulative
input load in amperes of all devices attached to the unit at the time the page was
loaded. This page will refresh automatically every 10 seconds.
Sensors
The Sensors page displays the temperature/humidity sensor's absolute and
descriptive names. The sensor page also displays temperature/humidity sensor
readings in degrees Celsius and percent relative humidity. This page will refresh
automatically every 10 seconds.
Configuration
The Configuration section offers access to all unit configuration options including
System, Network, Telnet/SSH, HTTP/SSL, Serial Port, Outlets, Groups, Users, FTP,
SNTP/Syslog,SNMP, LDAP, TACACS+ and Email. This section is available to
administrative level users only.
System
The System configuration page is used for reference of system information such as
Ethernet NIC Serial Number, Ethernet MAC address and system firmware and
hardware revisions as well as assignment and maintenance of the system location
and unit descriptive names.
For description names, up to 24 alphanumeric and other characters (ASCII 33 to 126
decimal – spaces and colon characters are not allowed) are allowed.
Note: Spaces may be used for the location description only.
Creating a descriptive system location name:
1. Enter a descriptive name and press Apply.
Configuring the Input Current LED display orientation:
SecureLinx SLP Remote Power Manager
Control State Description
of outlet status required
varies Error State – Outlet should be off but
current is sensed at the outlet
varies Error State – Outlet should be on but
no current is sensed at the outlet
On Outlet should be on but a blown fuse
has been detected.
varies Communication to the outlet has
been lost*
3: Operations
17
