Portuguese, Dutch, Swedish, Russian, Chinese, Korean, and Japanese (p.53). ✔ Note: •The On-Screen Menu and figures in this manual may differ slightly from the product. •The contents of this manual are subject to change without notice. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Input Selection ....32 Direct Operation Computer Input Source Selection Trademarks Each name of corporations or products in this book is either a registered trademark or a trademark of its respective corporation. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Please, dispose of them correctly at your Processing Equipment, ANSI/NFPA 75. local community waste collection/recycling centre. Please, help us to conserve the environment READ AND KEEP THIS USER’S MANUAL FOR LATER we live in! USE. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
TO LOCAL, STATE OR FEDERAL LAWS. Never spill liquid of any kind on the projector. Do not install the projector near the ventilation duct of air- conditioning equipment. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Damages to the projector caused by using an uncleaned filter or improper maintenance will void the warranty on the projector. Top Panel Fig.1 Filter replacement icon Fig.2 Filter cartridge replacement AIR INTAKE VENT icon EXHAUST VENT WARNING FILTER indicator L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Cautious use of equipment with laser technology Do not radiate strong light such as laser light on the projection lens directly, as this may degrade the functionality of the projector. Failure to so such will void any applicable warranties. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
– Do not put the projector in a case before it is cooled enough. – Do not transport the projector with a replacement lens installed L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Do not try to defeat this safety feature. GROUND Should you be unable to insert the plug into the outlet, contact your electrician. THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILy ACCESSIBLE. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Do not put heat-sensitive objects near this side. A Kensington* Security Slot This slot is for a Kensington lock used to deter theft of the projector. * Kensington is a registered trademark of ACCO Brands Corporation. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Connecting the Ethernet cable See the user’s HD (HDCP Compatible) signal can be also manual of “Network Set-up and Operation” for connected (p.21). details. S-VIDEO jACK Connects the S-VIDEO output signal from video equipment to this jack (p.21). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
- Select an item or adjust the value in the On- mode and smaller in DIGITAL ZOOM - mode. (p.44) Screen MENU. (p.26) !2 INFORMATION button - Pan the image in DIGITAL ZOOM + mode. (p.44) Displays the input source information (p.28). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
LAMP 2 REPLACE indicator Lights orange when the projection lamp 2 reaches its end of life (pp.75, 86) LAMP 1 REPLACE indicator Lights orange when the projection lamp 1 reaches its end of life (pp.75, 86 ) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Connects the remote control cable (not supplied) to this jack when using as a wired remote control. Number buttons Use these buttons when setting the remote control codes (p.16) or when entering the PIN code numbers (pp. 24, 60, 64). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
(16.4’/ 5 m). Connect the remote control and the projector with the remote control cable (sold separately). Connected with the remote control cable, the remote control does not emit wireless signal. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
To ensure safe operation, observe the following precautions: • Do not bend, drop, or expose the remote control to moisture or heat. • For cleaning, use a soft dry cloth. Do not apply benzene, thinner, spray, or any other chemical materials. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Fit the lens mount cover, align the matchmark on the lens mount cover with the left edge of the label on the cabinet, and then turn the lens mount cover clockwise until it clicks. (See Fig.3) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Keystone from the menu (see pages 31, 45, 52). Do not rotate the adjustable feet when you see the red line on the adjustable feet. The ADJUSTABLE adjustable feet may fall off. FEET L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
When contacting the sales dealer, tell the Option Control Number (Op.cont.No.) in the menu that is located on the bottom of the information menu. (See page 29) Plug As an example, this figure shows how to install a Dual-SDI Board. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Cable Cable cable cable DIGITAL HDMI ANALOG H/HV SERIAL PORT IN (DVI-D) Terminals of the projector Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Cable Cable cable DIGITAL VIDEO/Y, Pb/Cb, Pr/Cr S-VIDEO ANALOG HDMI VIDEO (DVI-D) Terminals of the projector Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
The cable tie is reusable and can be loosened and tightened as many times as needed. To loosen the cable tie Cable tie 2. Loosen the cable tie in the arrow direction. 1. Pull the tab in the arrow direction. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Projector side AC Outlet side For the U.S.A. and Canada For Continental Europe Ground To POWER CORD CONNECTOR on your To the AC Outlet. To the AC Outlet. projector. (120 V AC) (200–240 V AC) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
• The "1234" is set as the initial PIN code at the If you entered an incorrect PIN code, “PIN code” and the factory number will turn red for a moment. Enter the correct ✳✳✳✳ PIN code all over again. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
• The projector cannot be turned on during the cooling period high temperature and needs to be cooled. with the POWER indicator turned off. You can turn it on again after the POWER indicator becomes green again. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Press the MENU button to exit the on-screen menu. On-screen menu Point 8 currently The selected item is SELECT button set item is highlighted in orange. marked. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Lamp 1, Lamp 2, Language, Filter counter, Power management, Key lock, PIN code lock, Shutter management, Remote control, SERIAL NO., and Option control No. (p.29). i Network See the user’s manual of “Network Set-up and Operation” . o Guide The key operation is displayed. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
• The projector will shut down automatically when the set time on shutter management has passed. (p.65) The Information menu can also be selected from the menu. • The Power management function does not work when the shutter is closed. (p.62) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Note: ✔ • The H-sync freq. and V-sync freq. values shown in the menu list may be different from the actual values. • SERIAL NO. is used to service the projector. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 33
Press and hold the PIP button for more than 3 seconds to display the setting dialog box of Picture in Picture. See pages 55-56 for details of Picture in picture Picture function. Main picture L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
SELECT button SELECT button Press the SELECT button Press the Point 8 Keystone button Reduce the bottom left corner Reduce the bottom right part with the Point corner part with the Point buttons. buttons. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
RGB (Scart) y,Pb/Cb,Pr/Cr INPUT 1/2/3/4 buttons RGB(PC digital) Video S-video RGB(AV HDCP) HDMI ✔ Note: •“Input 3” and/or “Input 4” are selectable only when interface board(s) are connected to either or both of the slots. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Blue, Red, Horiz. Sync, and Vert. Sync.)] from the computer to G, B, R, H/HV, and V jacks: When your computer is connected to the INPUT 2 (5 BNC INPUT JACKS) terminal, select RGB. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Cr jacks, Y,Pb/Cb,Pr/Cr takes precedence of RGB. • Y,Pb/Cb,Pr/Cr input can accept the component signal and the analog RGB signal. When analog RGB signal is not recognized in Y,Pb/Cb,Pr/Cr input source, set to RGB input manually. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Systems in this dialog box PC Systems provided in this projector is chosen. can be selected. SVGA 1 The projector chooses a proper system provided in the projector and displays it. *Mode 1 and SVGA 1 are examples. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
System Menu (p.35), or when the signal is coming from the HDMI/DVI-D terminal. • Depending on the condition of signals and the type and length of cables, the signals may not be properly viewed. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Display area H Use the Point 7 8 buttons to adjust the horizontal area displayed by this projector. Display area V Use the Point 7 8 buttons to adjusts the vertical area displayed by this projector. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 41
575p, 720p, 1035i , 1080i or 1080p is selected in the PC System Menu (p.35). • When input computer signal to the projector, PC adjust function will become available. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Normal picture level preset on the projector. Real Picture level with improved halftone for graphics. Dynamic For viewing pictures in a bright room. Image 1–10 User preset picture adjustment in the Image adjust Menu. (pp.40-42) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Return to the COLOR MANAGEMENT POINTER. (If you press the MENU button on the side control or the remote control , it returns to the COLOR MANAGEMENT POINTER and you will need to reselect and readjust the color.) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 44
Point button to deepen green tone (from 0 to 63). White balance (Blue) Press the Point button to lighten blue tone; press the Point button to deepen blue tone (from 0 to 63). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 45
A confirmation box appears and then select Yes. Stored data can be called up by selecting an Image (1-10) in the Image Mode Selection on page 39. A confirmation box appears and then select Yes. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Use the Point ed7 8 buttons to pan the image. When adjusted, the arrows will turn red. When reached to the correction limits, the arrows will disappear. Custom Provides the last stored aspect screen image. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 47
Screen Size Adjustment Menu or select an input selected. source from the Input Source Selection Menu (see pages 32- • Digital zoom – cannot be operated when Custom is 34) again or adjust the screen size with the D.ZOOM button. selected. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 48
4:3 ..4:3 aspect ratio Reset This function returns all adjusted values to the factory default settings. Press the SELECT button at Reset to display a confirmation box. To reset, press the SELECT button at Yes. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
If the projector cannot reproduce proper video image, select a specific component video signal format from among 480i, 575i, 480p, 575p, 720p, 1035i, 1080i, and 1080p. Note: ✔ The AV System Menu cannot be selected when selecting RGB (Scart). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Normal picture level preset on the projector. Cinema Picture level adjusted with fine tone. Dynamic For viewing pictures in a bright room. Image 1–10 User preset picture adjustment in the Image adjust Menu. (p.50) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Point button to deepen green tone (from 0 to 63). White balance (Blue) Press the Point button to lighten blue tone; press the Point button to deepen blue tone (from 0 to 63). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 52
Point button to increase the sharpness of the image (from 0 to 31). Gamma Use the Point buttons to adjust the gamma value to obtain a better balance of contrast (from 0 to 15). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 53
• Progressive cannot be selected when 480p, 575p, 720p, or 1080p is selected (p.46). • Noise reduction cannot be selected with the computer input and when the video signal format is 1080p. (p.46). A confirmation box appears and then select Yes. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
SELECT button at Reset to display • Natural wide cannot be selected when 720p, 1035i, a confirmation box. To reset, press the 1080i or 1080p is selected on AV System Menu (p.46). SELECT button at Yes. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 55
Press the SELECT button at Reset to display a • When the 4:3 function is selected, Natural wide is not confirmation box. To reset, press the SELECT button at “Yes. ” available in the AV screen (p.51). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
• In Picture in/by Picture mode, warning frame (red) displayed when using the unavailable combination of Input buttons on the remote control or inputting unacceptable signals. • White Arrows in panning mode (p.43) • Corner patterns (p31) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 57
The fan noise becomes louder in Eco 2 The fan noise becomes louder in Eco 2 than in Eco 1. than in Eco 1. Select the suitable mode Select the suitable mode for the used environment. for the used environment. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 58
P by P , the left picture is main picture, and the right one is sub picture.) Picture in Picture Shows the selected mode (Off/User 1-5) and its status (Stored /Free/ Adj.). User 1 and User 2 have stored default values. See page 30 for details. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 59
Move the highlight to one of the mode (User1 - 5) which you want to delete and press the SELECT button. Then the confirmation box appears. To delete, select Yes. Back Returns to the Picture in Picture menu. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 60
(X,Y) of Red, Green, Blue, and White can be adjusted respectively. The adjustable range is from 0.000 to 1.000. Auto test pattern ..Select On to display a suitable pattern when setting items. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 61
Store : Select Store and press the SELECT button. Then the Confirmation box appears. To store adjusted data, select Yes. Test pattern: Displays the “Test pattern” menu. Back: Cancels the “Advanced color matching” menu display. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 62
Default and Off. • Capture function is not available when the Picture in Picture function is set to User1-5. • When changing a PIN code, the new PIN code numbers don't appear as asteriskmarks. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 63
Point edbuttons to enter the correct code. The New Logo PIN code input dialog box appears. Set a new Logo PIN code, confirmation box appears, choose Yes to set the new Logo PIN code. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 64
See “Remote Control Receivers and Operating Range” on page 15 for details. Both ..Activates both the front and back receiver. Front ..Activates only the front receiver. Back ..Activates only the back receiver. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 65
• Be sure to turn off the projector properly (see “Turning Off the Projector” on page 25). If the projector is turned off in the incorrect sequence, the "Direct on" function does not work properly. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 66
PIN code. The "1234" is set as the initial PIN code at the factory. If you want to change the PIN code lock setting, Press the SELECT button and the PIN code dialog box appears. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 67
WHEN yOU HAVE CHANGED THE PIN CODE, WRITE DOWN THE NEW PIN CODE IN COLUMN OF THE PIN CODE NO. MEMO ON PAGE 94, AND KEEP IT SECURELy. IF yOU FORGET yOUR PIN CODE, THE PROjECTOR CAN NO LONGER BE STARTED. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 68
POWER indicator turns green lighting and the SHUTTER indicator keeps blinking. Should the ON / STAND-BY button be pressed in this condition, the projection lamp will be turned on and the SHUTTER indicator turns off. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 69
Press the Point ed buttons to select Off, CC1, CC2, CC3 or CC4. If the Closed caption is not clear, you can change the text from Color to White. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 70
• Fig.1, Fig. 2, Fig. 3 and Fig. 4 will not appear when the replace the filter, use the filter control function (p.61). Display function is set to Off (p.53) or during “Freeze” (p.30). L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 71
Various test pattern are available for use when setting up the projector. Factory default This function returns all setting values except for User logo, PIN code lock, Logo PIN code lock, Filter counter and Network setting to the factory default settings. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Adjust the position, focus and zoom of each image if necessary, and then overlap the shaded areas by using the lens shift function. When the shaded areas are overlapped with each other correctly, the red lines turn yellow. Green frame Yellow lines L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
(Red, Green, and Blue). 9. Readjust the Target values. 10. Highlight “Store” appearing at the lower part of the Advanced color matching window and press the SELECT button to store the values. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
•The used part of the filter can be seen on the edge of the Filter the projector is turned off automatically to prevent the damage of cartridge after scrolling the filter, but there is no problem for the optical components. use of the projector. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
ORDER REPLACEMENT FILTER CARTRIDGE Replacement filter cartridge can be ordered through your dealer. When ordering, give the following information to the dealer. Model No. of your projector L2K1000 Replacement Filter Cartridge Service Parts Code: 003-002003-01 L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Select Yes to continue. Another confirmation dialog box appears, select Yes to reset the Scroll counter. Scroll counter Reset? appears. Select Yes, then another confirmation box appears. Select Yes again to reset the Scroll counter. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
When either of the 2 lamps is out, the projector operates with 1 lamp. The Lamp Mode can be switched to 2 lamps or 1 lamp manually. Refer to the SETTING section on pages 54, 55 2 LAMPS MODE 1 LAMP MODE When Lamp 1 is burnt out. When Lamp 2 is burnt out. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
NOTES ON LAMP REPLACEMENT Figure shows case of replacing LAMP 1. To maintain quality of picture (better balance of color and brightness in entire screen), we recommend replacing both 2 lamps at a time. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Inappropriate attempts to service the unit by anyone, especially those who are not appropriately trained to do so, may result in an accident or injury caused by pieces of broken glass. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
In addition, there is a risk that the internal parts may be damaged not only by the flammable air spray but also by the cold air. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
CAUTION DO NOT LEAVE THE PROJECTOR WITH THE LAMP indicator lights on AC POWER CORD CONNECTED UNDER AN and other indicators blink. ABNORMAL CONDITION. IT MAY RESULT IN FIRE OR ELECTRIC SHOCK. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
– Select correct input source once again through menu operation (See pages 32-34). – Make sure the temperature is not out of Operating Temperature (41˚F–104˚F [5˚C– 40˚C]). – Make sure that the shutter is open. (See pages 28, 65) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 83
– Capture function is not available when the Picture in Picture function is set to one of work. User1 - 5. Some menus cannot be – Each of the Video Input and Computer Input has a limit on selectable menus. selected. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 84
If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Specify the model number and explain about the problem. We will advise you how to obtain service. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Yes / No Corner pattern Red/White/Blue/Off Store Image 1 - Image 10 Store Store/Reset On/Off Ceiling On/Off Rear Full/16:9/16:10/4:3 Screen aspect ✔ Note: Yes/No Reset •The Menu display varies depending on the input signal. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 86
Scale V H & V On/Off 720p Position H 575p Position V 480p Common Reset 575i 480i Standard Keystone Corner correction Corner pattern Red/White/Blue/Off Store Store/Reset On/Off Ceiling On/Off Rear Full/16:9/16:10/4:3 Screen aspect Yes/No Reset L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 87
R/G/B/C/M/Y/W Back On/Off Auto test pattern Menu off Test pattern Factory default Store Reset Back Normal HDMI setup Enhanced Logo select Off/Default/User Logo Capture Yes/No Logo PIN code lock On/Off Logo PIN code change L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
(approx. 1 second ON, 2 seconds OFF) 1 second OFF) • • • dim • • •blinking fast • • • Differs according to conditions. ✽ (approx. 0.5 seconds ON, • • • off 0.5 seconds OFF) L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 89
Reset the Filter counter and Scroll counter after replacing the filter cartridge (p.73). LAMP REPLACE 1 and 2 When the LAMP 1 REPLACE indicator and the LAMP 2 REPLACE indicator light orange, replace the projection lamps with new ones promptly. See page 75. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 90
The shutter is out of control. (The projector is in the ✽ cooling mode.) The shutter is out of control. (The projector is in the stand-by mode.) In that case, contact the service ✽ ✽ center immediately. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
1152x900 61.200 65.200 SXGA 12 1152x900 71.400 75.600 SXGA 13 1280x1024 i 50.000 86.000 ✔ Note: Alphabet letter "i" placed beside some of the resolutions represents interlace signal. • “True” cannot be selected. ✽ L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 92
Be sure to follow this procedure, otherwise an image may not be projected on the screen. If an image is not projected correctly, restart your PC. • Do not disconnect the cable while the projector is running. If the cable has been disconnected and then reconnected, an image may not be correctly projected. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
RGB 3 S-Video VIDEO 5 INPUT 2 AUX 2 INPUT 3 AUX 3 INPUT 3 INPUT 4 INPUT 4 AUX 4 PJLink is a registered trademark of JBMIA and pending trademark in some countries. L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety standards against risk of fire, casualty, and electrical hazards. The CE Mark is a Directive conformity mark of the European Community (EC). Licensed under USP5,717 ,422 USP6,816,141 L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Main/Sub picture. <Display resolution is lowered when;> • Inputting PC analog signals: More than 165 MHz <Images are not displayed and X mark appears when;> • Inputting PC digital signals: More than 165MHz L2K1000 User Manual 020-000393-01 Rev.1 (04-2011)
Page 100
Americas Canada Chile Christie Digital Systems USA, Inc. Christie Digital Systems Canada, Inc. Representative Office 10550 Camden Drive 809 Wellington St. N. Christie Digital Systems USA, Inc. Cypress CA 90630 Kitchener, Ontario N2G 4Y7 Av. Pedro Fontova 7619 of 60...
Page 102
Corporate offi ces Worldwide offi ces USA – Cypress United Kingdom Eastern Europe Singapore Japan ph: 714-236-8610 ph: +44 118 977 8000 ph: +36 (0) 1 47 48 100 ph: +65 6877-8737 ph: 81-3-3599-7481 Canada – Kitchener France Middle East Beijing South Korea ph: 519-744-8005...
