Specifications

General
Rated current
0.9 A
Dimensions (mm)
141 x 23 x 166
(W x H x D)
Approx. 380 g
Weight
(Excluding AC adapter and
USB extension cable)
Operating temperature:
5 °C to 35 °C
Operating
environment
Storing temperature:
-20 °C to 60 °C
For DVD:
Laser power
661 nm, 0.4 mW
(wavelength,
For CD:
output)
785 nm, 0.6 mW
DVD-R
JVC, TDK, Verbatim, SONY
*1
DVD-R DL
JVC, Verbatim
*2
DVD-RW
JVC
Optimal performance of the burner may not be possible depending on the disc used. Using discs
of manufacturers for which compatibility has been confirmed is recommended.
Only 12 cm discs can be used with this burner.
*1 DVD-R DL discs can be used when the burner is connected to a high definition Everio camera or
a PC.
*2 Dual layer DVD-RW discs cannot be used.
Interface
Interface cable
Compatible discs for
writing
(8 cm discs cannot
be used)
Recording format
Recording time
20
Recommended discs
When connected to an Everio camera
USB 2.0
USB extension cable for Everio
Everio
: DVD-R, DVD-RW
High definition
: DVD-R, DVD-R DL, DVD-RW
Everio
Everio
: DVD video (video only)
High definition
: Data DVD (video, still image)
Everio
Everio
: Approx. 30 minutes (including time taken for finalization)
Approx. 90 minutes of video recorded in fine mode on a
4.7 GB disc. (Varies depending on conditions such as
number of titles.)
High definition
: For details, refer to the instruction manual of the Everio
Everio
camera.
AC adapter (AP-V3U)
AC110 V to 240 V
Power supply
50 Hz/60 Hz
Input capacity
0.26 A
Output
DC 5.2 V, 2 A
Operating
0 °C to 40 °C
temperature
Dimensions (mm)
49 x 28 x 79
(W x H x D)
(Excluding power cord)
Weight
Approx. 136 g
