Ikegami LCM-810 Specifications

Ikegami LCM-810 Specifications

Cost-effective high resolution, security surveillance 8 inch tft color lcd monitor
Hide thumbs
1
2

Advertisement

Quick Links

Download this manual
Cost-Effective High Resolution, Security Surveillance
8 inch TFT Color LCD Monitor
LCM-810
Features
High Resolution
Composite A/B-NTSC/PAL(BNC), S-Video(Y/C) and
Analog PC(D-Sub)
Contrast Ratio 500:1
Brightness 250cd/m2
Loop-through Composite Video and Audio
Color Temperature Normal/Warm/Cool
Optional Dual Rackmount Adaptor
Power AC 100V ~ 240V
All Safety Standards (FCC, CE, RoHS)

Advertisement

loading
Need help?

Need help?

Do you have a question about the LCM-810 and is the answer not in the manual?

Questions and answers

Related Manuals for Ikegami LCM-810

Summary of Contents for Ikegami LCM-810

  • Page 1 Cost-Effective High Resolution, Security Surveillance 8 inch TFT Color LCD Monitor LCM-810 Features High Resolution Composite A/B-NTSC/PAL(BNC), S-Video(Y/C) and Analog PC(D-Sub) Contrast Ratio 500:1 Brightness 250cd/m2 Loop-through Composite Video and Audio Color Temperature Normal/Warm/Cool Optional Dual Rackmount Adaptor Power AC 100V ~ 240V...

  • Page 2: Specifications

    LCM-810 High Resolution Security Surveillance Color LCD Monitor Specifications Item Description Screen size 8 inch LCD Panel Viewable size 162mm(H) x 121.5mm(V) Dot pitch 0.2025mm x 0.2025mm Display color 16.7M colors Resolution 800 x 600 Contrast ratio 500 : 1 (Typical)
