User Manual
2 Port USB VGA Cable KVM Switch with
Audio
SV215MICUSBA
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 01/30/2012
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SV215MICUSBA
Summary of Contents for StarTech.com SV215MICUSBA
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 01/30/2012...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Hardware Guide ..................2 Installation ....................3 Operation ....................4 Hotkey Configuration ................4 Hotkey Summary Table .................5 Scan Interval Table ................5 Keyboard Emulation Mapping .............6 Specifications ..................7 Troubleshooting ..................8 Technical Support ..................9 Warranty Information ................9 Instruction Manual... -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com SV215MICUSBA 2 Port VGA + USB Cable KVM Switch with Audio. Supporting superior video quality with resolutions up to 2048x1536, this KVM on-a-cable switch is an ideal solution to access and control two desktop computers. -
Page 5: Hardware Guide
* The cable connecting the Master unit to Host 1 is 24”, while the cable connecting the Console unit to Host 2 is 47”. To link the SV215MICUSBA to the console display unit, use a Male-Male VGA cable to connect the blue Console connector to the VGA port on the display device being used. -
Page 6: Installation
Note: This step is optional.Plug the USB, video, and speaker connectors of the attached KVM cables into their respective ports on the computers you are installing. 3. Turn on the power to the computers. Please Note: The SV215MICUSBA’s Power On default is to link to the first computer you turn on. -
Page 7: Operation
Operation There are two ways to select the host computer you wish to broadcast to the console: the Remote Selector, and Hotkey Mode. If you wish to use the Remote Selector to switch between host computers, simply connect it to the Remote Selector Input (shown on pg.3). -
Page 8: Hotkey Summary Table
Hotkey Summary Table Once Hotkey mode has been invoked, key in one of the following values (keys) to perform the corresponding function: Hotkey Sequence Action Toggles the KVM and Audio focus between the two ports. [Scroll Lock] [Scroll Lock] [Enter] Note: If the KVM and Audio focus are on different ports, only the KVM focus switches. -
Page 9: Keyboard Emulation Mapping
Keyboard Emulation Mapping To initialize Mac keyboard mapping, please execute the following hotkey sequence: [scroll],[scroll], [F2], [Enter] [ctrl] [ctrl] [F2] [Enter] Once this has been done, the following keyboard mapping will apply: PC Keyboard Mac Keyboard PC Keyboard Mac Keyboard [Shift] Shift [Enter]... -
Page 10: Specifications
Specifications Function Specification Computer Connection Port Selection Hotkey, Pushbutton Keyboard 1 x USB Type A Female (Purple) Video 1 x HDB-15 Male (Blue) Console Mouse 1 x USB Type A Female (Black) Ports Speaker 1 x Mini Stereo Jack Female (Green) Microphone 1 x Mini Stereo Jack Female (Pink) Connectors... -
Page 11: Troubleshooting
Troubleshooting Symptom Possible Cause Action Unplug the keyboard/mouse from the Keyboard/Mouse Console Keyboard Port, then plug it need to be reset. back in. Keyboard and/ Hotkey sequence Resend the Hotkey command - press or Mouse Not has been input and release each key in the sequence Responding incorrectly. -
Page 12: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 13 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
