2. Identify the Left Upright (75), which is marked
"Left." Have a second person hold the Left
Upright near the Base (80).
See the inset drawing. Tie the wire tie in the
Left Upright (75) securely around the end of the
Upright Wire (70). Then, insert the Upright Wire
into the lower end of the Left Upright as you pull
the other end of the wire tie through the Left
Upright.
3. Hold the Left Upright (75) against the Base (80).
Be careful not to pinch the wires. Partially
tighten three 3/8" x 3 1/2" Screws (4) with three
3/8" Star Washers (5) into the Left Upright and
the Base; do not fully tighten the Screws yet.
Attach the Right Upright (not shown) in the
same way. Note: There are no wires on the right
side.
2
75
70
Wire Tie
3
8
70
75
Wire
Tie
80
75
5
5
Wires
80
4
