www.proform.com
USER'S MANUAL
Model No. PFTL60911.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer
Care.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFTL60911.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-Form PFTL60911.0

Summary of Contents for Pro-Form PFTL60911.0

  • Page 1 USER’S MANUAL Model No. PFTL60911.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 DANGER: 20. Never leave the treadmill unattended while Always unplug the power it is running. Always remove the key, unplug cord immediately after use, before clean- the power cord, and press the power switch ing the treadmill, and before performing the into the off position when the treadmill is not maintenance and adjustment procedures in use.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM 590 T manual. To help us assist you, note the product model ® treadmill. The PROFORM 590 T treadmill provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • To hire a service technician to assemble this prod- • To identify small parts, see page 6. uct in your home, call 1-800-445-2480. • Assembly requires the following tools: • Assembly requires two persons. the included hex keys • Place all parts in a cleared area and remove the one adjustable wrench packing materials.
  • Page 8 2. Identify the Left Upright (75), which is marked “Left.” Have a second person hold the Left Upright near the Base (80). See the inset drawing. Tie the wire tie in the Left Upright (75) securely around the end of the Upright Wire (70).
  • Page 9 4. Identify the Left Handrail (71), which is marked “Left.” Remove the tie from the 5/16" Cage Nut (33). If necessary, press the Cage Nut back into place. Hold the Left Handrail (71) near the Left Upright (75). Insert the Upright Wire (70) through the bracket on the bottom of the Left Handrail.
  • Page 10 6. With the help of a second person, hold the con- sole assembly near the Left Upright (75). Console Assembly Connect the Upright Wire (70) to the console wire. See the inset drawing. The connectors should slide together easily and snap into place.
  • Page 11 8. Attach the console assembly to the Left and Right Handrail Tubes (10, 11) with four #8 x 3/4" Console Screws (6); start all four Screws, and then Assembly tighten them. Do not overtighten the Screws. 9. Identify the Left Tray (87) and the Right Tray (88).
  • Page 12 10. Fully tighten the six 3/8" x 3 1/2" Screws (4) (three on each side). 11. Raise the Frame (49) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (51) so that the large barrel and the latch knob are oriented as shown.

  • Page 13: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit.
  • Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s premium stereo sound The treadmill console offers an impressive array of system while you get in shape. features designed to make your workouts more effec- To turn on the power, see page 15.
  • Page 15 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
  • Page 16 4. Change the incline of the treadmill as desired. T he Speed tab will show a profile of the speed set- tings of the workout. To change the incline of the treadmill, press the Incline increase or decrease button or one of the The My Trail tab will show a track that represents numbered Quick Incline buttons.
  • Page 17 6. Measure your heart rate if desired. 7. When you are finished exercising, remove the key from the console. Before using the heart rate monitor, remove the sheets of plastic from the metal contacts, if neces- Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest sary.
  • Page 18 HOW TO USE A WEIGHT-LOSS WORKOUT Each workout is divided into one-minute segments. One speed setting and one incline setting are 1. Insert the key into the console. programmed for each segment. Note: The same speed setting and/or incline setting may be pro- See HOW TO TURN ON THE POWER on page 15.
  • Page 19 HOW TO USE AN IFIT LIVE WORKOUT When you select an iFit Live workout, the display will show the duration of the workout, the distance Note: To use an iFit Live workout, you must have an you will walk or run, and the approximate number of optional iFit Live module.
  • Page 20 6. Follow your progress with the displays. HOW TO USE THE STEREO SOUND SYSTEM See step 5 on page 16. To play music or audio books through the console’s stereo speakers, you must connect your MP3 player, The My Trail tab will show a map of the trail you are CD player, or other personal audio player to the con- walking or running or it will show a track and the sole through the audio jack.
  • Page 21 THE INFORMATION MODE 3. CONTRAST LVL: Press the Incline increase and decrease buttons to adjust the contrast level of the The console features an information mode that keeps display. track of treadmill information and allows you to person- If a module is connected, you may also select the alize console settings.

  • Page 22: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following b. Make sure that the power cord is plugged in. If the the simple steps below. Find the symptom that power cord is plugged in, unplug it, wait for five applies, and follow the steps listed. If further assis- minutes, and then plug it back in. tance is needed, see the front cover of this manual.
  • Page 24 SYMPTOM: The walking belt slows when walked on Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 22). Remove the three #8 x 3/4" Screws (6). Carefully slide the a. Use only a surge suppressor that meets all of the Motor Hood (57) off.
  • Page 25 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first re- when walked on move the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller screws a. If the walking belt is off-center, first remove the clockwise, 1/4 of a turn.

  • Page 26: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 27: Part List

    PART LIST Model No. PFTL60911.0 R1111B Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Storage Latch 3/8" x 2 1/2" Bolt Right Rear Foot 3/8" Nut Left Rear Foot 3/8" x 3 1/2" Screw Right Speaker Back 3/8"...

  • Page 28: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL60911.0 R1111B...
  • Page 29 EXPLODED DRAWING B Model No. PFTL60911.0 R1111B...
  • Page 30 EXPLODED DRAWING C Model No. PFTL60911.0 R1111B...
  • Page 31 EXPLODED DRAWING D Model No. PFTL60911.0 R1111B...

  • Page 32: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) LIMITED WARRANTY IMPORTANT: You must register this product within 30 days of the purchase date to avoid added fees for service needed under warranty.
