1
1. General
The KP-D20BP-S3 is a single CCD type color camera utilizing digital signal
processing in addition to digital control of the various correction and
adjustment functions to enable high quality images.
The high density CCD comprises 470,000 picture elements PAL and provides
clear pictures even under low illumination, in addition to high sensitivity and
resolution.
Important functions, including auto iris and auto white balance, allow use in
a wide range of CCTV systems for image processing, surveillance and other
applications.
2. Principal features
(1) Very small, light weight,Various functions
44 (W) x 44 (H) x 49 (D) mm , 130g
Y/C output standard equipment
RS-232C standard equipment
(2) High sensitivity and resolution
The high density interline type CCD sensor with on-chip microlenses
enables low-light pickup down to 0.3 lux (F 1.2 lens, AGC maximum) and
horizontal resolution of 470 TV lines.
(3)
Digital signal processor (DSP)
Digital processing includes 2 H enhancer and contour correction to deliver
clear pictures and high signal to noise ratio (S/N).
parameters can also be adjusted with the aid of on-screen menus, thus
enabling optimum adjustments to match the application.
(4) Electronic shutter
The electronic shutter can be set in 10 steps from standard (off setting) 1/50
second to 1/30000 second.
1/180000 second. Even with a fixed iris lens, the shutter speed responds to
the amount of light to keep the signal output at optimum level.
(5)
Backlight compensation
Backlight compensation can operate with either a video signal or control
voltage input type auto-iris lens. The sensing area can also be selected
according to usage conditions.
• E • E
DWN
• E • E
DSGN
• E • E
CHKD
• E • E
APPD
1
2
Auto electronic shutter (AES) operates to
Tokyo Japan
2
3
4
Picture control
8 7 1 6 6 1 6
3
‚ `
‚ a
‚ b
‚ c
‚ d
‚ e
