BDW47
DISHWASHER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BDW47 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baumatic BDW47

Summary of Contents for Baumatic BDW47

  • Page 1 BDW47 DISHWASHER...
  • Page 2 BDW47...

  • Page 3: Table Of Contents

    Dea r Costumer, Ple ase read this User Information carefully and keep it to refer to a t a later date. Pass it on to any s ubsequent owner of the appliance. Control Pane l............3 Dishwasher Features..........3 This manual conta ins sections of Safety Instructions, Operating Instruct ions, Installation Instructions and Troubleshooting Tips etc.
  • Page 4 Under c ertain conditions, Hydrogen gas may be pr oduced in a hot-water system that has not been used for two weeks or mor e. HYDROGEN GAS IS EX PLOSIVE.If the hot-water system has not been used for suc h a period, before using the dis hwasher turn on all hot-water faucets and let the wate r flow from each for several minutes.

  • Page 5: Control Pane L

    Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Dispose of the dishwasher packaging material correctly. All packaging materials can be recycled. Plastic parts are marked with the standard international abbreviations: for polyethylene, e.g.

  • Page 6: Rinse Aid

    To get the best performance from your dishwasher,read all operating instructions before using it for the first time. Auto 3in1 Del ay On/O ff Salt and R inse Aid W arn ing Light: To come on when ON/OFF Button: T o turn on/off th e po wer supp ly. the soften er or dispenser needs to be refil led.
  • Page 7 Be fore using your dishwasher for the first time: A. Set the water softener B. Pour 1／2 litre of water inside the salt container and then fill with dishwasher salt C. Fill the rinse aid dispenser D. Function of detergent The water softener must be set manually, using the water hardness dial.
  • Page 8 Alwa ys us e salt i nte nde d for use with dishwasher. The salt container is loca ted beneath t he lower rack and should be filled as follows: Atte ntion! Only us e salt specifically designed for use in dis hwashers! All other type s of salt not spe cifically designed for use in a dis hwasher, especially table salt, will damage the water s oftener.
  • Page 9 If there is no rinse-aid warning light in the control panel, you ca n judge the amount of rins e-aid by the color of the optical level indicator "D" located n ext to the cap. When the rinse-aid container is full, the whol e indicator wi ll be dark .As the rinse-aid di minish es, the size of the da rk dot decreases.

  • Page 10: Concentrated Detergent

    Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher. Most of commercial quality detergents are suitable for this purpose. Concentrated Detergent Based on their c hemical composition, dishwasher can be split in two basic types: conventional, alkaline detergents w ith causti c com pone nts low alkaline concentrate d detergents wi th na tural enzymes The u se of “normal”...

  • Page 11: Wate R Softener

    Fill in detergent Fill the detergent dispenser with detergent. The marking indicates the dosing levels , as illustrated on right: The place of main wash cycle detergent placed , “MIN”means approximately 20g of detergen. The place of pre-wash cycle detergent placed , approximately 5g of detergent Please observe the manufacturers dosing and storage recommendations as stated on the detergent packaging.
  • Page 12 Your dishwasher has a 3 in 1 program which needs not salt and rinse aid but a THREE IN ONE tablet. And this dishwasher comes with a 3 in 1 tablet container as an accessory. NOTE: Only 3 in 1 program uses 3 in 1 tablet. If using 3 in 1 tablet in other programs, the appliance will not get a best performance.

  • Page 13: Attention Before Or After Loading The Dishwasher Racks

    For best pe rformance of the dishwasher, fol low thes e loading guidelines. Features and appearance of racks and si lverware baskets may var y from your model. Attention before or after Loading the Dishwasher Racks Sc rape off any large amounts of leftover food. It is not neces sary to rinse the dishes under running water.

  • Page 14: Silverware Basket

    We recommend that you place large it ems which are most difficult to clean into the lo wer rack: pots, pans, lids, serving dishes and bowls, as sh own in the figure to t he right. It is pr eferable to place serving d ishes and lids o n the side of the racks in order to avoid blocking the rotation of the top spray arm.
  • Page 15 Silverware Basket Silverware sho uld be placed in the silverware basket wi th handles at the b ottom: If the rack has side baskets, th e spoon should be loaded individu ally into the appropriate slots, especi ally long utensi ls shou ld be placed in the horizo ntal position at the front of the up per rack.

  • Page 16: At The End Of The Wash Cycle

    shes and items of cutlery must not lie inside one another, or cover each othe r. avoid damage to glasses, they must not touch Load large items which are most difficult to clean into the lower rack he upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups Attention! Long bladed knives stored in an upright position are a potential hazard!
  • Page 17 Pre-wash 40 （ ℃） For all soiled loads, such as Autowash 50-60 （ ℃） pots,pans,casserole dishes 3in1 120~160 0.8~1.2 9~12 Rinse and dishes that have been Auto （or4/20g） Rinse 70 （ ℃） sitting with dried food on them Drying. for a while. Pre-wash 50 （...

  • Page 18: Wash Cycle Table

    Turning on the Appliance Starting a wash c ycle... 1. Draw out the lower and upper basket, load the dishes and push them back. It is commended that loading the lower basket firs t, than the uppe r one (see the section entitled “Loading the Dishwasher”).

  • Page 19: Filtering System

    A forgotten dish can be added any time before the detergent cup opens. Open the door a little to stop the washing. Add forgotten dishes. After the spray arms stop working, you can open the door Close the door, the dishwasher will work after ten seconds. completely.

  • Page 20: Cleaning The Spray Arms

    Cleaning the Spray Arms It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. Remove the upper spray arms To remove the upper spray arms, screw off the nut clockwise to take out the washer on top of the spray arm and remove the arm.
  • Page 21 8. 8.

  • Page 22: Please Carefully Read The Installation Instruction

    Please carefully read the installation instruction. ● Illustrations of cabinet dimensions and installation position of the dishwasher Preparations should be made before moving the dishwasher to the installation place. Choose a place near the sink to facilitate the installation of inlet and drain hoses (see figure 1).
  • Page 23 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by screws and bolts(See figure 4b) . Hop hook 【Figure4a】...

  • Page 24: Tension Adjustment Of The Door Spring

    Tension adjustment of the door spring ● The door springs are set at the factory to the proper tension for the outer door. If aesthetic wooden panel are installed, you will have to a djust the door spring tension. Rotate the adjusting screw to drive the adjustor to strain or relax the steel cable(see figure 5).

  • Page 25: Dishwasher Installation Steps

    Dishwasher installation steps ● Install the furniture door to the outer door of the dishwasher using the brackets provided. Refer to the template for positioning of the brackets. Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to tighten the left and right door springs.
  • Page 26 Dishwasher must be level for proper dish rack operation and wash performance. Place level on door and rack track inside the tub as shown to check that the dishwasher is level. level the dishwasher by adjusting the four leveling legs indi vidually. When level the dishwasher, pl s pay attention not to let the dishwasher tip over.
  • Page 27 In order to avoid that there is more water staying in the inl et hose, please close the hydrant after using.(For the models: no safety inlet hose.) The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused. Water pressure must be between 0,04 MPa and 1 MPa.

  • Page 28: Start Of Dishwasher

    Insert the drain hose into a drain pipe w ith a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid ben ding or crimping. Use the sp ecial plastic support that com es with the appliance. The top of the hose must be at a height betw een 40 and 100cm.The free end of the hose m ust not be immersed in water.

  • Page 29: Before Calling For Service

    Before Calling for Service Review the charts on the following pages may make you be free of calling for service. Replace fuse or reset circuit breaker. Remove any other Fuse blown, or the circuit breaker acted appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on...
  • Page 30 Combination of soft Use less detergent if you have soft water and select a water and too much shortest cycle to wash the glassware and to get them clean. detergent Tea or coffee stains using a solution of 1/2 cup of bleach and 3 cups warm water to remove the stains by hand.
  • Page 31 44 5 82 0 Height : 820mm(adjustable+10mm) Width : 445mm Depth : 560mm Voltage connected Load : see rating label Water pressure: 0.04-1.0MPa Hot water connection : max 60 ℃ Power supply: see rating label Capacity: 9 Place settings...
