Operating Instructions – Dishwasher Baumatic BDW45.1

Quick Start

1. Load dishes

2. Add detergent

3. Press the

button

4. Select a wash programme

5. Select ECO (optional)

6. Check nothing is obstructing the spray arm.

7. Start – close the drawer and press the

button.

Finish – The appliance will beep six times to indicate the end of the wash programme. At the end of the wash

programme the drying fan will continue to run for a set time. The fan assists with drying

Control Panel

Note: Your dishwasher's control panel is on the top lip of the door. If your appliance is being installed under a

worktop, you will need to open the door to see the control panel.

1. Programme indicator light: when you select the washing programme, the corresponding light will display.

2. Programme key: press to select washing programme. Multiple presses select different programmes.

3. Salt and rinse aid warning light: Comes on when the softener or dispenser needs to be refilled.

4. Delay start time: displays the delay start time. Also displays the water temperature and ERROR codes.

5. Delay key: press to set the delay start time. One press sets the wash cycle forward by 1 hour (up to 24 hours into

the future).

6. Power on light: comes on when Power ON/OFF button is pressed down.

7. ON/OFF button: turns the power supply on and off.

Detergent

To open the detergent dispenser door, use the catch on its lower side.

Note:

Always check the wash cycle table for dosage advice. Never overfill the dispenser.

Need help?

Do you have a question about the BDW45.1 and is the answer not in the manual?

Page 1 Operating Instructions – Dishwasher Baumatic BDW45.1 Quick Start 1. Load dishes 2. Add detergent 3. Press the button 4. Select a wash programme 5. Select ECO (optional) 6. Check nothing is obstructing the spray arm. 7. Start – close the drawer and press the button.
Page 2 Do no overdose to prevent the formation of deposits (the water softening feature already takes care of this!). Loading the dishwasher Before loading! Remove all scraps of food. Empty drinks and liquids from cups. Soften burnt-on-food in pans by soaking. Do NOT put these items in your dishwasher: Saucepans with wooden handles.
Page 3 The upper rack has side flaps. There are 4 (2 on each side). These can be adjusted into 2 positions - high and low. To move the flaps between these positions, find the large hinges clasping each flap to the upper rack. There are two of these at either end of each flap.
Page 4 3. Dessert spoons 7. Gravy ladle 4. Teaspoons 8. Serving fork Starting a wash cycle Programme indicator light Programme key • Make sure that the dishwasher’s plug has • Press the “on/off” button and the “on/off” been pushed all the way into the wall light will come on.
Page 5 Approximate timing of washing cycles Intensive Normal Economy Rinse Glass Rapid Soap (strong) 127 mins. 117 mins. 102 mins. 50 mins. 70 mins. 45 mins. 7 mins. Wash cycle table...
