  • Page 1 BDWI660-AUS 60 cm Fully integrated full height dishwasher...
  • Page 2 USER MANUAL FOR YOUR BAUMATIC BDWI660-AUS 60 cm Fully integrated full height dishwasher NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
  • Page 4: Table Of Contents

    Contents Environmental note Important safety information 5 – 7 Specifications 8 – 11 Product and aperture dimensions Product specifications 8 – 9 Electrical details Description of the appliance Control panel Using your dishwasher 11 - 26 Before first use Filling with dishwasher salt 11 –...
  • Page 5: Environmental Note

    This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the...
  • Page 6: Important Safety Information

    General Safety o Repairs to your appliance must only be carried out by a Baumatic engineer or one of its authorised service agents. Any attempt by an inexperienced person to repair the appliance, could result in injury or damage to your dishwasher.
  • Page 7 This appliance is only designed to wash normal domestic washloads. If you use your dishwasher in any other way or it is incorrectly used, then Baumatic accepts no liability for any damage that might be caused and any guarantee will be void.
  • Page 8 o Any packaging that is removed from the machine should be kept away from children. o All detergents should be kept out of children’s reach in a safe place. o Some water will remain inside the dishwasher when it has completed a wash cycle.
  • Page 9: Specifications

    Specifications Product dimensions Height: 815 – 865 mm Width: 598 mm Depth: 550 mm Aperture dimensions Height: 820 – 870 mm Width: 600 mm Depth: 580 mm (MIN) Product specifications o 14 Place settings o 6 programs: Normal Intensive Economy Glass Rapid 1 hour...
  • Page 10: Electrical Details

    o Electronic aqua stop o Delay start function o Residual drying o Half load option o Alternative wash function o Concealed heating element o Self-cleaning stainless steel micro-filter o Anti-leak device o Anti-flood device o Height adjustable upper basket o Collapsible plate racks o Adjustable feet Energy efficiency details Energy efficiency class:...
  • Page 11: Description Of The Appliance

    Description of the appliance Top spray arm Cutlery basket Upper basket Inner pipe Lower basket Salt container Detergent dispenser Cup shelf Lower spray arm Filter assembly Inlet pipe connector Drain pipe Adjuster...
  • Page 12: Control Panel

    Control panel LED display Alternative wash button Delay start button Program button ON/OFF button Using your dishwasher Before first use o Install the appliance as per the installation instructions contained within this booklet. o Fill the water softener with 1 litre of tap water and then fill with specialist dishwasher salt.
  • Page 13 IMPORTANT: It is only necessary to do this when you fill the container with salt for the first time. o Pour salt into the water softener, using the funnel that is supplied with the appliance. You should add approximately 1.5 kg of salt into the water softener.
  • Page 14: Setting The Water Softener Level

    Setting the water softener level It is possible to regulate the amount of salt that the water softener will release during a wash cycle. The water softener should be set to a level that is appropriate for the hardness of your water (please refer to the table below).
  • Page 15: Filling With Rinse Aid

    Filling with rinse aid The rinse aid is released during the final rinse and it helps to prevent water from forming droplets on your dishes. These droplets will lead to spots and streaks being left on items after the wash program has completed. o Your dishwasher is designed to utilise liquid rinse aid.
  • Page 16: Setting The Rinse Aid Level

    Setting the rinse aid level The amount of rinse aid that the dishwasher requires also depends on the hardness of your water. You should experiment with the rinse aid setting, until you find a level that gives the best results. o On the first wash cycle, we would recommend that the rinse aid level is set to number 4.
  • Page 17 o Open the lid that closes over the detergent dispenser by pushing the release button. The lid will spring open. Place the detergent inside of the dispenser. o The section marked A in the diagram is for the main wash cycle detergent.
  • Page 18: Concentrated Detergent

    Concentrated detergent o The use of the NORMAL program with concentrated detergents reduces pollution and is good for your dishes. o This wash program is specifically suited to the dirt-dissolving properties of the enzymes of concentrated detergent. For this reason, the NORMAL program, in which concentrated detergent is used, can achieve the same results achieved in the INTENSIVE program.
  • Page 19: Adjusting The Upper Basket

    o Use the diagram above as a guide to the most appropriate way to load the upper basket. IMPORTANT: Care should be taken when placing long stemmed glassware, such as champagne glasses in the upper basket. If they are not positioned correctly, then there is a risk that they may topple over when the upper basket is pushed in or pulled out.
  • Page 20: Folding Back The Cup Shelves

    Folding back the cup shelves For easier stacking of pots and pans the cup shelf spikes can be folded down as shown in the diagram below. IMPORTANT: Care should be taken to make sure that the spray arms can move freely when items have been loaded into the baskets.
  • Page 21: Folding Spikes Of Lower Basket

    Medium serving bowl Small serving bowl Dessert dishes Dinner plates Soup plates Oval platter Folding spikes of lower basket o The bottom rack has prongs that can be folded downwards, to allow for easier loading of larger saucepans and serving bowls.
  • Page 22: The Cutlery Basket

    The cutlery basket Cutlery should be placed inside of the cutlery basket, separately from each other. You should take care to ensure that cutlery items do not touch as this may result in a poor wash performance. Soup spoons Forks Knives Teaspoons Dessert spoons...
  • Page 23 o Do not allow glasses to touch inside the dishwasher, otherwise damage may occur. o Small objects can be placed inside of the cutlery basket. The following items are NOT suitable for washing inside a dishwasher:- o Cutlery with a handle of mother-of-pearl, wood, horn or china. o Plastic items that are not resistant to heat.
  • Page 24: Program Table

    Program table o The ECONOMY program is suitable for cleaning a typical load of dirty dishes and is the most efficient program in terms of its combined energy and water consumption. Program Cycle Program Description Detergent Program Energy Water Rinse information of cycle pre/main...
  • Page 25: Setting A Wash Program

    not need (45°C) drying. * The wash program times that are quoted are intended as a guide only. Please note that factors external to the machine, e.g. the temperature of your water supply, your water pressure etc. can affect the time it takes for the wash program to complete. ** Economy is the testing program for EN 50242, with a 14 setting capacity, the top basket in the upper position and the rinse aid setting at 6.
  • Page 26: Adding More Dishes

    o After a few seconds, you will hear the appliance begin to fill with water and the wash program will have started. Changing the wash program IMPORTANT: This should only be attempted when the cycle has only just started, otherwise the detergent may have already been released or you could have hot water escaping.
  • Page 27: Delay Start Function

    Delay start function o Check whether the appliance needs rinse aid or salt adding to it. o Pull out the top and bottom baskets, then load them in accordance with the loading instructions. o Push the top and bottom baskets fully back into position. o Add detergent o Turn the appliance on by using the ON/OFF button (5).
  • Page 28: Saving Energy Using Your Dishwasher

    o Then press the alternative wash button (2) repeatedly to select either the top or bottom basket. The relevant icon will light on the LED display to show your choice. Upper basket Lower basket o When the correct icon is lit, release all buttons and in a few seconds the wash program will start.
  • Page 29: Cleaning And Maintenance

    as well. Modern detergents also work just as well at lower temperatures. Cleaning and maintenance IMPORTANT: The appliance should be disconnected from your mains supply before commencing any cleaning process. The filter system Your appliance is fitted with three levels of filtering; these are located in the base of the dishwasher for ease of access.
  • Page 30: Cleaning The Filters

    Cleaning the filters For best performance and results, the entire filter assembly should be thoroughly cleaned regularly (ideally after each wash cycle). 1. Turn the coarse filter anti-clockwise and then lift it upwards. Rinse out this section under a tap to remove any food debris that remains in it.
  • Page 31: Cleaning The Spray Arms

    Cleaning the spray arms The spray arms should be cleaned regularly, to prevent hard water deposits from clogging the spray arm jets and bearings. o To remove the upper spray arm, hold the nut and rotate the arm clockwise to remove it. o To remove the lower spray arm, gently pull it upwards.
  • Page 32: Cleaning The Door

    Cleaning the door o To clean the edge around the outside of the door, you should use a soft, damp cloth only. o To prevent water from penetrating the door lock or electrical components, DO NOT use a spray cleaner of any kind. o DO NOT use any abrasive cleaner or scouring pads on the inner or outer surfaces, as they may cause damage to them.
  • Page 33 IMPORTANT: If any other error codes appear, you should not attempt to clear it yourself and contact the Baumatic Customer Care Department. IF THE FAULT CODE REAPPEARS AFTER FOLLOWING THE ABOVE ADVICE AND CLEARING THE FAULT CODE.
  • Page 34: General Troubleshooting

    General troubleshooting PROBLEM POSSIBLE WHAT TO DO CAUSES Dishwasher Fuse blown or the circuit Replace the fuse or reset the doesn’t start. breaker acted. circuit breaker. Remove any other appliances sharing the same circuit with the dishwasher. Power supply is not Make sure the dishwasher is turned on.
  • Page 35 dishwashers for the risk of foaming or suds. There are rust The affected items are Avoid washing these items in stains on the not corrosion resistant. the dishwasher and look for cutlery. dishwasher-safe replacements in the future. A RAPID program was Always run a RAPID program not run after dishwasher without any dishes in the...
  • Page 36 Detergent left Dishes are blocking the Re-load the dishes properly. in the detergent dispenser. dispenser. The dishes are Improper loading of Load the dishwasher as not drying. crockery. suggested in the relevant instructions. Too little rinse-aid was Increase the amount of rinse-aid used.
  • Page 37: Installation

    Installation IMPORTANT: THIS INSTALLATION MUST COMPLETED BY A SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION THE INSTALLATION GIVEN THIS INSTRUCTION MANUAL. SHOULD DISPOSE PACKAGING ENVIRONMENTALLY FRIENDLY MANNER. Aperture requirements...
  • Page 38: Installation Stages

    o The aperture that your dishwasher needs to be installed into should resemble the one shown in the drawings on the previous page. o There should be less than a 5 mm gap between the top of the dishwasher and the underneath of the worktop. The height of the aperture required will vary between 820 –...
  • Page 39 o Use the installation template supplied with the appliance to mark up and then drill out the necessary holes in the furniture door. o Attach the upper and lower hooks onto the furniture door. o Lift the furniture door towards the dishwasher door, ensuring that the upper and lower hooks locate into the slots on the outside of the dishwasher door.
  • Page 40: Adjusting The Tension Of The Door Spring

    Adjusting the tension of the door spring o The door of the dishwasher is attached to springs. These are set at the factory to ensure that they are at the proper tension, so that the door can open and close smoothly. o After the furniture door has been fitted, you will need to adjust the tension of the door spring.
  • Page 41: Connecting To The Mains Water Supply

    Connecting to the mains water supply IMPORTANT: Do not connect the appliance to your mains water supply using an old or an existing water inlet hose. The inlet hose supplied with the dishwasher is the ONLY one that should be used. o The inlet hose will be located inside the cabinet of the dishwasher.
  • Page 42: Connecting To The Power Supply

    o Secure the drain hose, so that it cannot move whilst the dishwasher is in use. o Place the end of the drain hose on your drain pipe. Push it a short way down into your drain pipe. The drain pipe must have a minimum diameter of 40 mm.
  • Page 43: Applying The Condensation Strip

    Applying the condensation strip o The condensation strip must be fitted to the underside of the worktop to protect it against the ingress of moisture. The strip will deflect steam that rises from your appliance, away from the underneath of the worktop. o The condensation strip will be located inside of your dishwasher.
  • Page 44: Levelling The Appliance

    o Carefully slide the dishwasher back into position, underneath the worktop. Levelling the appliance o IMPORTANT: Your dishwasher must be level for it to operate properly. o Make sure that the dishwasher is supported whilst it is being levelled, otherwise it may tip over. o Rotate the adjustable feet to level the appliance accordingly.
  • Page 45: Securing The Dishwasher

    Securing the dishwasher The dishwasher must be secured to the worktop, this can be done in one of two ways:- o Standard worktop- Secure dishwasher underside of the worktop by using two wood screws (A). o You should screw through the holes in the brackets at the top of the dishwasher cabinet.
  • Page 46: Before First Use

    Before first use You should check the following before using the appliance for the first time:- o That the dishwasher is level and fixed in position. o That the water tap is fully open. o That there are no leaks at either end of the drain or inlet hoses. o That the inlet and outlet hose are fully tightened.
  • Page 47: Contact Details

    Service Telephone 1800 444 357 Website www.thinkappliances.com Applico Ltd. P.O. 92900 Onehunga, Auckland, New Zealand 1061 Website www.applico.nz United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Sales Telephone (0118) 933 6900 Website: www.baumatic.co.uk...
