- Page 1 LEG PRESS ADAPTER KIT FOR CM3 GYM SYSTEM WARNING: Read and follow all directions for each step to insure proper assembly of this product. USER’S GUIDE CLASS H Version: CM3-LP5A-103 PART # 7997101 Revision: 09/26/05 REV. A...
-
Page 2: Safety Statement
DO NOT DO NOT DO NOT NOTE: In a continual effort to improve our products, specifications are subject to change © 2005 Life Fitness, a division of Brunswick Corporation. All rights reserved. ParaBody is a trademark of Brunswick Corporation www.parabody.com... -
Page 3: Tools Required
IMPORTANT NOTES Please note: * Thank you for purchasing the ParaBody CM3-LP5A-101 LEG PRESS ADAPTER KIT. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. -
Page 4: Parts List
STEP SPACER 1-11/16’ LG ACUDB2E03811000B 3/8” LOCKNUT ACUA02-0055 CABLE L CLIP NOTE: The LEG PRESS ATTACHMENT (LP5) must be assembled before connecting it to the PARABODY CM3 GYM SYSTEM DISCARD! WEIGHT STACK CABLE FIGURE 1 STEP 1: • Remove the WEIGHT STACK CABLE as shown in FIGURE 1. Discard the cable. -
Page 5: Figure
FIGURE 2 3/8 X 1-3/4” 9 STEP 2: • Screw the long threaded end of the new WEIGHT STACK CABLE (3) into the end of the WEIGHT PLATE SHAFT. See FIGURE 2. • Route the WEIGHT STACK CABLE (3) around the pulley in the BOOM PLATES as shown in FIGURE 2. (NOTE: Make sure the cable runs in the grooves of the pulleys.) •... -
Page 6: Step
FIGURE 3 STEP 3: • Screw the threaded end of LEG PRESS CABLE (4) to the PULLEY BRACKET (2) as shown in FIGURE 3. -
Page 7: Step
FIGURE 4 STEP 4: • If not already installed, slide one 2” SQ. COVER CAP (6) over the FRONT LEG (1) as shown in FIGURE 4. 3/8” LOCKNUT 3/8 X 3-3/4” BOLT FIGURE 5 STEP 5: • Remove the 3/8 X 3-3/4” BOLT and 3/8” LOCK NUT from the BASE PLATE as shown in FIGURE 5. Discard the 3/8 X 3-3/4” BOLT. -
Page 8: Lock Nut
STEP 6: • SECURELY assemble the LEG PRESS ADAPTOR (1) to the CM3 Gym System using two 3/8 X 4” BOLTS (11), five 3/8” WASHERS (7), one previously removed 3/8” LOCK NUT and one 3/8” LOCK NUT (8) as shown in FIGURE 6. - Page 9 10 3/8 X 2-3/4” FIGURE 8 STEP 8: • SECURELY attach the LP5 LEG PRESS to the LEG PRESS ADAPTOR (1) using two 3/8” X 2-3/4” BOLTS (10), two 3/8” WASHERS (7), and two 3/8” LOCK NUTS (8). See FIGURE 8. FIGURE 9 SEAT FRAME BRACKET...
- Page 10 SEAT FRAME BRACKET 3/8” L0CK NUT 3/8 X 4-3/4” FIGURE 10 STEP 10: • SECURELY attach the BRACKET (from LP5 LEG PRESS) to the SEAT FRAME using two 3/8” X 4-3/4” BOLTS (12), two 3/8” WASHERS (7), and two 3/8” LOCK NUTS (8). See FIGURE 10. FIGURE 11 3/8 X 1-3/4”...
-
Page 11: Table Of Contents
FIGURE 12 SEAT FRAME 3/8” LOCK NUT 3/8 X 4-3/4” 12 STEP 12: • Carefully route the LEG PRESS CABLE (4) around one 3-1/2” PULLEY (5) and SECURELY assemble the 3-1/2” PULLEY (5) to the SEAT FRAME using one 3/8 X 4-3/4” BOLT (12), two STEP SPACERS 1-19/32 (14), and one 3/8” LOCK NUT (8) as shown in FIGURE 12. -
Page 12: Figure
FIGURE 14 SEAT FRAME 3/8” LOCK NUT 3/8 X 4-3/4” 12 STEP 14: • SECURELY assemble the swivel end of the LEG PRESS CABLE (4) to the SEAT FRAME using one 3/8 X 4-3/4” BOLT (12), two STEP SPACERS 1-11/16”(15) and one 3/8”LOCK NUT (8). (NOTE: SECURELY tighten, then back nut off 1/4 turn) CABLE ROUTING DIAGRAM... -
Page 13: Assembly Instructions
HEAD PLATE from lifting up. • If further CABLE ADJUSTMENT is needed, reference the CM3 GYM SYSTEM assembly instructions. THIS CONCLUDES THE ASSEMBLY OF THE CM3-LP5A-103 LEG PRESS ADAPTER KIT...
