ParaBody 220 User Manual

ParaBody 220 User Manual

Parabody gym system user's guide
Hide thumbs Also See for 220:

Advertisement

Table of Contents

220 GYM SYSTEM
CLASS H
PART # 7017301
REV. G
USER'S GUIDE
1
WARNING:
Read and follow all directions
for each step to insure proper
Assembly of this product.
Version: 220101
Revision: 09/13/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 220 and is the answer not in the manual?

Questions and answers

Related Manuals for ParaBody 220

Summary of Contents for ParaBody 220

  • Page 1 220 GYM SYSTEM USER’S GUIDE CLASS H PART # 7017301 REV. G WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 220101 Revision: 09/13/01...
  • Page 2 7. Inspect cables and their connections before using machine. Pay particular attention to the cable ends. DO NOT attempt to fix. Notify your authorized ParaBody dealer before use and have repairs made by an authorized service technician. 8. Make sure all spring loaded pull pins are fully engaged in the adjustment position and fully tighten thumbscrew before use.

  • Page 3: Tools Required For Assembly

    Please note: * Thank you for purchasing the ParaBody 220 Gym System. Please read these instructions thoroughly and keep them for future reference. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.
  • Page 4 1’ 2’ 1’ 2’ 3’ 4’ 5’ 6’ 7’ 1 Square = 1’ X 1’ Minimum Required Usable Space Length Width Height Dimensions Including Leg Press (optional) Length Width 4’ 3’ 5’ = 82 inches (208.5 cm) 6’ 10” = 71 inches (180.5 cm) 5’11” = 83 inches (211 cm) 6’...

  • Page 5: Parts List

    PART # DESCRIPTION 7005008 FRAME 7005708 BASE 6994608 BASE PLATE 7005308 BOOM PLATE LEFT 7005208 BOOM PLATE RIGHT 7005408 PRESS HANDLE RIGHT 7005508 PRESS HANDLE LEFT 6999708 PRESS ARM 7005108 PRIMARY PIVOT 7005808 SEAT ADJUST 7005608 LEG PEDESTAL 6940808 PULLEY PLATE 6994721 SEAT PAD 6549301...
  • Page 6 FIGURE 1 STEP 1: • LOOSELY assemble two BASE PLATES (3) to the FRAME (1) and BASE (2) using four 3/8 X 3-3/4” BOLTS (30) and four 3/8” LOCK NUTS (34). See FIGURE 1. • Insert two 3/8 x 9/16” FLANGE SPACERS (41) into the upper holes in the FRAME (1) as shown in figure 1 •...
  • Page 7 FIGURE 2 STEP 2: • Insert two WEIGHT PLATE BUSHINGS (23) into each of the fifteen WEIGHT PLATES (22) as shown in FIGURE 2. FIGURE 3 STEP 3: • Slide the WEIGHT PLATE SHAFT (18) thru the hole in the HEAD PLATE (19), and lock in place using one E-RING (60) as shown in FIGURE 3.
  • Page 8 STEP 4: • Insert two GUIDE RODS (16) into the BASE (2) as shown on FIGURE 4. (NOTE: If the 220 SHROUD OPTION was purchased, place the GUIDE RODS (16) through the BOTTOM SHROUD BRACKET (FOUND IN THE SHROUD KIT BOX) into the BASE (2), as shown in FIGURE 4.
  • Page 9 STEP 6: • Insert two 1/2” FLANGE BEARINGS (40) into the LEFT PRESS HANDLE (7) as shown in FIGURE 6 • Using hammer tap one 5/16 X 2” ROLL PIN (47) thru LEFT PRESS HANDLE (7) until it is flush with other side of HANDLE as shown in FIGURE 6 •...
  • Page 10 3/8 X 3” FIGURE 8 STEP 8: • Place PRESS ARM (8) into PRIMARY PIVOT (9) and securely tighten using two 3/8 X 3” BOLTS (29), four 3/8” FLAT WASHERS (36) two 3/8” LOCK NUTS (34) • Insert and tighten two 3/8” LOCKING SPRING PINS (49) into PRESS HANDLES (6), (7). •...
  • Page 11 1/2 X 8” FIGURE 9 STEP 9 • SECURELY TIGHTEN ALL FRAME CONNECTION BEFORE PROCEEDING TO NEXT STEP • SECURELY TIGHTEN top of both SHAFT COLLARS (48) flush to bottom of both BOOM PLATES (4),(5) • Assemble the PRIMARY PIVOT (9) of the PRESS ARM ASSEMBLY to the top of the FRAME (1) using 1/2 X 8” BOLT (33), two 1/2”...
  • Page 12 FIGURE 10 STEP 10: • Apply WEIGHT STACK LABELS (61) to WEIGHTS (22) and HEAD PLATE (19) as shown in FIGURE 10. Begin with number one at the HEAD PLATE (19) with larger numbers in consecutive order towards bottom of weight stack. •...
  • Page 13 STEP 11: • Insert two 1/2” FLANGE BEARINGS (40) into LEG PEDESTAL (11) as shown. • Assemble the LEG PEDESTAL (11) to the FRAME (1) using one 1/2 X 4” BOLT (32), two RH WASHERS (56) and one 1/2” LOW HT LOCK NUT (35) •...
  • Page 14 ILLUSTRATION A • ILLUSTRATION “A” used as cable routing reference for steps 13-16 NOTE: IF YOU PURCHASED A LEG PRESS, PLEASE REFER TO THE CABLE ROUTING INSTRUCTIONS INCLUDED WITH THE LEG PRESS KIT...
  • Page 15 3/8 X 8” FIGURE 13 STEP 13: • Refer to cable ILLUSTRATION “A” on page 11 for cable routing while installing pulleys. • Assemble two 3-1/2” PULLEYS (24) into FRAME (1) using two 3/8 X 3-3/4” BOLTS (30), four 3/8 X 1-1/16” FLANGE SPACERS (42) and two 3/8”...
  • Page 16 3/8 X 3-3/4” 3/8 X 8” FIGURE 14 STEP 14: • Refer to cable ILLUSTRATION “A” on page 11 for cable routing while installing pulleys. • Assemble one 3-1/2” PULLEY (24) into the PRIMARY PIVOT (9) lower hole using one 3/8 X 8” BOLT (31), two 3/8”...
  • Page 17 DO NOT OVERTIGHTEN FIGURE 15 STEP 15 • Slip ring of WEIGHT SELECTOR PIN (51) down WEIGHT STACK SHAFT (18) and insert pin into one of the weights • Screw end of LAT CABLE (20) into top of PLATE SHAFT (18) and securely tighten JAM NUT as shown in FIGURE 15 •...
  • Page 18 3/8 x 3” 29 3/8 x 3-3/4” FIGURE 16 STEP 16: • Refer to cable ILLUSTRATION “A” on page 11 for cable routing while installing pulleys. • [CABLE MUST BE POSITIONED BETWEEN PULLEY AND LOWER BOLT ASSEMBLY ON LEG PEDESTAL (11) AND FRAME (1)] •...
  • Page 19 3/8 X 1 -3/4” 3/8 X 3-3/4” FIGURE 17 STEP 17: • Refer to cable ILLUSTRATION “A” on page 11 for cable routing while installing pulleys. • Assemble one 3-1/2” PULLEY (24) between BASE PLATES (3) using one 3/8 X 3-3/4” BOLT (30), two 3/8 X 1” SPACERS (43), one 3/8”...
  • Page 20 FIGURE 18 STEP 18: • Attach two 4 X 7” ROLLER PADS (15) to the LEG PEDESTAL (11) using one 3/4 X 17” TUBE (14) and two 3/4” STARLOCK COLLARS (54) as shown in FIGURE 18. • Attach two 4 X 7” ROLLER PADS (15) to the SEAT ADJUST (10) using one 3/4 X 1” TUBE (14), two PLASTIC WASHERS (39) and two 3/4”...
  • Page 21 • Attach the ANKLE STRAP (25) to the 12 LINK CHAIN (26) using one SNAP LINK (57) as shown in FIGURE 19 Thank you for purchasing the ParaBody 220 Gym System. If unsure of proper use of equipment, call your local ParaBody distributor or call the ParaBody customer service department at (800) 328-9714...
  • Page 22 Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your ParaBody customer service representative at (800) 328-9714. * Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.

  • Page 23: Limited Warranty

    ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 24 Life Fitness Asia Pacific Limited Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 www.parabody.com Life Fitness (UK) Ltd. Queen Adelaide Ely, Cambs CB7 4UB United Kingdom Phone CSS: (01353) 665507 Fax CSS: (01353) 666719 Life Fitness Benelux N.V.
