Security Mode Event Buttons - HAI SECURITY SYSTEM Owner's Manual

Press the 0 (OFF) key to select when the unit turns off or press the 1 (ON) key to select when the unit turns on (this program is
executed whenever the unit is turned off or on).
Press the 2 (SWITCH) key to select only when the top-rocker or bottom-rocker is pressed at a UPB, RadioRA, or ALC Switch
(locally at the Switch) or when a button is pressed on a keypad.
SWITCH:
0=OFF 1=ON 2-11=SW1-SW10
Press "0" to select only when the bottom-rocker (off) is pressed on the Switch. Press "1" to select only when the top-rocker (on)
is pressed on the Switch. Press "2-9" (see the Corresponding Switch Table) to select when that button is pressed on a keypad.
Press the ' # ' key to enter your selection.
Switch OmniLT UPB 6-Button Keypad
1 2
2 3
3 4
4 5
5 6
6 7
7 8
8 9
9 10
10 11

Security Mode Event Buttons

Pressing the 2 (SEC) key allows you to select the event button that will be activated when a security mode changes:
0=OFF
3=AWAY
After the security mode is selected, an additional menu appears which allows you to further specify the button. For example, you
would like to activate a button when you arm the system into the 3 (AWAY) mode:
WHEN AWAY:
1=DELAY 2=CODE
Any of these may be selected alone or in combination. As each item is specified, the menu is redisplayed with the updated event
button description. Press the ' # ' key when done.
- Selecting 1 (DLY) allows the user to specify whether the event button is activated at the start or end of the exit delay:
WHEN ACTIVATED?
1=START EXIT
Corresponding Switch Table
UPB 8-Button Keypad
On Button
Off Button
A
B
C
D
1=DAY 2=NIGHT
4=VACATION
2=END EXIT
RadioRA Master Control
1 or E
2 or F
3 or G
4 or H
5 or I
6 or J
7 or K
8 or L
51
ALC 4-Button
1
2
3
4
5
6
7
8
9
10
1
2
3
4
