Page 1: Installation Manual
HOME AUTOMATION, INC Control & Security System Installation Manual Document Number 20I00-1 Rev. 2.4 May, 2003... - Page 3 Home Automation, Inc. Installation Manual Document Number 20I00-1 Rev. 2.4 May, 2003 Copyright ! ! ! ! 1999-2003 Home Automation, Inc. All Rights Reserved...
-
Page 4: Table Of Contents
CONTENTS INTRODUCTION............................1 PLANNING .......................................1 INSTALLATION............................2 CONTROLLER HOOKUP ................................2 ABOUT SECURITY ZONES ................................4 BURGLAR ZONE HOOKUPS ..............................4 ABOUT FIRE ZONES ..................................6 TWO-WIRE SMOKE DETECTORS ............................6 FOUR-WIRE SMOKE DETECTORS ............................6 TELEPHONE CONNECTIONS ..............................9 LCD CONSOLE HOOKUP................................11 CONSOLE SETUP ..................................11 CONSOLE ADDRESS ................................11 SOUNDER....................................11 KEY CLICK .....................................11 KEY BACKLIGHT ..................................11... - Page 5 INSTALLER SETUP............................ 31 SETUP CONTROL ..................................31 X-10 HOUSE CODE ................................31 X-10 3-PHASE ..................................31 OUTPUT TYPES ..................................32 SETUP ZONES....................................33 WIRELESS RECEIVER ................................33 ZONE RESISTORS..................................33 ZONE RESPONSE TIME ................................34 ZONE TYPES ..................................34 LATCHING ZONE TYPES ..............................35 DESCRIPTION OF ZONE TYPES............................35 SETUP DIGITAL COMMUNICATOR ............................38 FIRST PHONE NUMBER, FIRST ACCOUNT NUMBER ....................38 COMMUNICATOR TYPE ..............................38 TWO-WAY AUDIO.................................38...
- Page 6 OMNI II SPECIFICATIONS ........................51 UNDERWRITER'S LABORATORIES (UL) INSTALLATION REQUIREMENTS ......52 24-HOUR STANDBY BATTERY CAPACITY..................53 SMOKE DETECTOR INSTALLATION GUIDELINES ................ 54 APPENDIX A – CONTACT ID REPORTING FORMAT............... 55 APPENDIX B - DIGITAL COMMUNICATOR CODE SHEET ............56 FIGURES FIGURE 1 - CONTROLLER HOOKUP............................3...
-
Page 7: Introduction
INTRODUCTION This installation guide is intended as an aid to installing the Omni II Control & Security System. The installer should also have thoroughly reviewed and understood the Omni II Owner's Manual, which has important information regarding final setup of the system. -
Page 8: Installation
INSTALLATION Go over your plan with your customer. Install the entire system. Refer to sections in this manual to see how to install various components. Follow the Power-Up and Checkout procedures. Explain the basics to the customer. Deliver all manuals and documentation. Follow up with your customer to keep them satisfied. -
Page 9: Figure 1 - Controller Hookup
1/4" SPACING BLACK WIRE TO - RED WIRE TO + YUASA NP7-12 BATTERY OR EQUIVALENT 12V 7AH THE BATTERY IS NON-POWER LIMITED. THE BATTERY LEADS MUST BE SEPERATED FROM ALL OTHER POWER LIMITED/CLASS II WIRING IN THE ENCLOSURE BY AT LEAST 1/4" COLD WATER PIPE POWER TRANSFORMER OR GROUND ROD... -
Page 10: About Security Zones
ABOUT SECURITY ZONES Each of the 48 security zone inputs on an Omni II system may be configured as a burglary zone, a fire zone, a temperature zone, or an auxiliary input. Zones 1-4, however, are the only inputs that can be used with 2-wire smoke detectors. Zones 9-16 are the only inputs that can be configured as a PESM. -
Page 11: Figure 2 - Overall Connections Diagram
ZONE ZONE ZONE SWITCH 12V JP11-14 JP11-14 (OUTPUT) (NO) SWITCH 12V (NO) (OUTPUT) WARNING (NC) OUTPUT 4-WIRE (NC) SMOKE TO PREVENT RISK INPUT FROM ELECTRIC SHOCK, 1K EOL 1K EOL 1K EOL ZONE (1-4) DE-ENERGIZE THIS UNIT AND DISCONNECT 2-WIRE ZONE (1-4) TELEPHONE LINES SMOKE... -
Page 12: About Fire Zones
ABOUT FIRE ZONES The Omni II system supports normally open (closed for alarm), two-wire or four-wire smoke detectors. Two-wire smoke detectors can only be connected to Zones 1-4. Four-wire smoke detectors can be connected to any zone. An external 1000-ohm end-of-line resistor must be used for all fire (and gas) zones. -
Page 13: Figure 3 - Two-Wire Fire Zone Connections
WHEN Z1-Z4 IS CONFIGURED AS A SUPERVISED FIRE OR GAS ZONE, THE CORRESPONDING ZONE JUMPERS J11-J14 MUST BE IN "SMK" POSISTION SYSTEM SENSOR MODEL 2100TS BOTTOM PLATE ZONE ZONE SYSTEM SENSOR MODEL 2100TS BOTTOM PLATE ZONE ZONE MODEL 1503A0011 1K OHM EOL RESISTOR FIGURE 3 - TWO-WIRE FIRE ZONE CONNECTIONS Page 7... -
Page 14: Figure 4 - Four-Wire Fire Zone Connections
WHEN Z1-Z4 IS CONFIGURED AS A SUPERVISED FIRE OR GAS ZONE, THE CORRESPONDING ZONE JUMPERS J11-J14 MUST BE IN "SMK" POSISTION GREEN YELLOW BLACK BLACK SYSTEM SENSOR MODEL 2112/24TR YELLOW BOTTOM GREEN PLATE SYSTEM SENSOR MODEL 2112/24TR BOTTOM PLATE ZONE YELLOW ZONE GREEN... -
Page 15: Telephone Connections
PHONE LED will come on. When the phone line rings, the PHONE LED will light. If the Omni II is accessed on an in house telephone, the Omni II will disconnect the phones from the phone company lines and supply its own talk voltage to the phones. -
Page 16: Figure 5 - Rj31X Jack Connections
BEND TAB UP IF NECESSARY TO ENSURE TIGHT FIT RED(-) GREEN(+) TELEPHONE NETWORK INTERFACE CUSTOMER ACCESS RED(-) GREEN(+) SURGE ARRESTOR SURGE ARRESTOR MUST BE GROUNDED! TO TELCO RJ11 INTERFACE AT TO ALL HOUSE HOUSE SURGE ARRESTOR TELEPHONES, PHONE PBX, AND JACK(S) COMPUTERS FIGURE 5 - RJ31X JACK CONNECTIONS... -
Page 17: Lcd Console Hookup
LCD CONSOLE HOOKUP 8 LCD Consoles (Models 11A00-1, 11A00-2, 11A00-9, and 15A00) MAXIMUM per system, subject to power availability. Use 4-conductor 22-gage wire, 1000 feet maximum length. Consoles can be homerun or daisy chained. This length shall be divided by the total number of consoles at the end of the run. For example, for 8 consoles, the maximum length reduces to 125 feet. -
Page 18: Language
LANGUAGE This option is to display the 'console setup' text on the LCD display in English, French, Italian, or Spanish. Select one of the languages, then press the # key. EXIT SETUP MODE To exit Setup Mode, press and hold the 4 and up arrow (!) keys simultaneously for about 1 second. The console will return to normal operation. -
Page 19: Figure 6 - Console Connections
FOR MODEL NUMBERS SEE NOTE 1 UNDER "LCD CONSOLE HOOKUP" CONSOLE FACE (SNAPS ON TO BOTTOM PLATE) BOTTOM PLATE CONSOLE PC BOARD (MOUNTED TO CONSOLE FACE) YELLOW GREEN BLACK CONNECT ENDS OF SUPPLIED CABLE TO CORRESPONDING SUPPLIED CABLE ENDS OF 4 - WIRE CABLE (PLUGS INTO J1) FROM CONTROLLER FIGURE 6 - CONSOLE CONNECTIONS... -
Page 20: Sounder Outputs
SOUNDER OUTPUTS The Horn Output provides 12VDC to power bells, piezo sirens, self-contained sirens, and siren drivers (do not connect speakers to the Horn Output). Sounders can draw up to 1 amp MAXIMUM, split between the Interior and Exterior Horn Outputs - (See Specifications for UL Ratings). -
Page 21: Figure 7 - Sounder Connections
FIGURE 7 - SOUNDER CONNECTIONS Page 15... -
Page 22: Controller Outputs
CONTROLLER OUTPUTS The Omni II provides 8 programmable hardwired voltage outputs and two horn voltage outputs. These outputs are programmable for the following output types: • General Purpose low voltage switching applications (12 VDC) - Units 65 - 72 •... -
Page 23: Communicator Outputs
This output can be used for radio communications or any other type of auxiliary communications to augment the built-in digital and voice dialers. Any communications device can be used with the Omni II, provided that it is powered by 12 VDC, has 12 VDC triggered inputs, and has 2 (or more) channels. -
Page 24: Figure 9 - Remote Keyswitch Connections
YELLOW GREEN GREEN BLACK MOMENTARY CONTACT KEYSWITCH FIGURE 9 - REMOTE KEYSWITCH CONNECTIONS Page 18... -
Page 25: Hai Thermostats
Run a 3 (or 4) conductor wire from Omni II to the thermostat location. All thermostats are connected in parallel to Zone 16 and Output 8. Connect the red COMM cable wire with the black COMM cable wire. Make the connections (as shown in Figure 10) using the supplied wire splices. -
Page 26: Programmable Energy Saver Modules
NOTE: Programmable Energy Saver Modules must be connected to zones 9-16 on the Omni II controller. Omni II can support up to 8 Programmable Energy Saver Modules (PESM). Each PESM requires one security zone input and one controller output. The zone input corresponds to the controller output (Zone 9 and Output 1 through Zone 16 and Output 8, respectively). -
Page 27: Temperature, Outdoor Temperature, And Humidity
When mounting outdoors, plan to mount under an overhang or to the underside of an eave, otherwise known as the soffet, to protect it from direct sunlight and rain. Run a 4-conductor wire from the Omni II controller to the selected location. -
Page 28: Figure 12 - Pesm Connections
BLACK YELLOW GREEN EXISTING LOW VOLTAGE THERMOSTAT RED LED ON - ENERGY SAVER IS OVERRIDING THERMOSTAT OFF - THERMOSTAT IS WORKING NORMALLY HEAT / AIR SYSTEM PROGRAMMABLE ENERGY SAVER MODULE FIGURE 12 - PESM CONNECTIONS Page 22... -
Page 29: Built-In Serial Port
BUILT-IN SERIAL PORT Omni II has a serial port (J1) built onto the controller (labeled SERIAL 1). The interface is a modular connector located in the upper left corner of the controller. It uses either the Omni-Link or Pro-Link Protocol for connections to the Internet via HAI Web-Link II, personal computers, and other optional interfaces like touchscreens, voice recognition, lighting controls, and home theater controls. -
Page 30: Figure 13 - Rs-232 Connections
4 POSITION MODULAR PHONE CABLE 7 RTS DB9-FEMALE BOTTOM VIEW - TAB UP - - YELLOW WIRE ON TOP - 8 CTS 3 TX YELLOW 2 RX GREEN 1 DCD BLACK 5 GND 4 DTR 6 DSR SIDE FIGURE 13 - RS-232 CONNECTIONS 4 POSITION MODULAR PHONE CABLE - TAB UP -... -
Page 31: System Power Up Procedure
Within one minute, the STATUS LED should begin blinking at a rate of 1 blink per second. This indicates that the Omni II processor and software are working. The PHONE LED should be OFF (if all telephones are on-hook and the RJ31X jack is properly connected. -
Page 32: Burglar Zone Check Out
NOTE: Be sure that the DIAL OUT DELAY is long enough so that you can cancel the alarm before the system dials out. HOME CONTROL CHECKOUT Confirm that the HOUSE CODE on the Omni II is set to the same HOUSE CODE set on all of the modules (See SETUP CONTROL). -
Page 33: Customer Checkout
HAI for repair. Phone line problems, or problems with the Omni II voice are usually the result of the RJ31X jack being improperly wired. Check RJ31X jack wiring and polarity carefully, as described in TELEPHONE CONNECTIONS. - Page 34 Unplug the power transformer. Disconnect the battery Disconnect the RJ31X modular cable at the jack!! If you only disconnect it at the Omni II controller only, the house phones won't work. Disconnect the X-10 cable. Disconnect the serial cable.
-
Page 35: Digital Communicator
DIGITAL COMMUNICATOR The Omni II digital communicator can use Contact ID, or Standard 4/2 or 3/1, (20 pps, 1800 Hz data, 2300 Hz handshake), or (10 pps, 1900 Hz data, 1400 Hz handshake), dual round compared format. Any central station with modern equipment can receive these formats. -
Page 36: 3/1 Format
OPENING AND CLOSING REPORTS The Omni II system can send opening and closing reports by user to the central station. When the system is disarmed by user code 1-16, the communicator can call the central station and report that the system was disarmed (opened) with the user code that was used. -
Page 37: Installer Setup
INSTALLER SETUP This section describes the items that the installer must setup as part of system installation. The Installer Setup mode is used to configure the general operation of the system, the Outputs, the Areas, the Zone Types, the Digital Communicator, and various other settings. -
Page 38: Output Types
OUTPUT TYPES An output type must be specified for each of the voltage outputs and for the interior and exterior horn outputs. The following output types are available: OUTPUT TYPE NUMBER DESCRIPTION GENERAL PURPOSE General Purpose Output OK TO ARM OK To Arm ARMED Armed... -
Page 39: Setup Zones
To configure the zone type for each security zone, from the Installer Setup menu, select the 2 (ZONE) key. WIRELESS RECEIVER A Wireless Receiver can be used to add 16 zones (33-48) to the Omni II. If used, you must enable the following item: WIRELESS RECEIVER: ↓... -
Page 40: Zone Response Time
To change a zone type, press the ' # ' key, then use the arrow keys to scroll through the list of zone types. Press the ' # ' key to select a new type The display shows: SELECT TYPE: ↕ PERIMETER ZONE RESPONSE TIME All zones, in the Omni II are set to a 300 millisecond fixed response time. ZONE TYPES ZONE TYPE NUMBER DESCRIPTION ENTRY/EXIT Entry/Exit... -
Page 41: Latching Zone Types
LATCHING ZONE TYPES When any device (other then FIRE or GAS) is connected to SWITCH 12V or a Switched Power Output, the zone must be configured as one of the LATCHING ZONE TYPES (latching perimeter, latching night interior, latching away interior, and latching tamper). - Page 42 DURESS EMERGENCY. If this zone is accidentally tripped, you will not know that the Omni II is making a silent dial out, and hence won't know to stop it. To stop a silent dial out once it has started, you must go to the console and press OFF then enter your code.
- Page 43 Zones that are not in use should be configured as AUXILIARY. KEYSWITCH INPUT This zone is used to arm AWAY and Disarm the Omni II security system using a toggle (to ground) keyswitch or keypad. PROGRAMMABLE ENERGY SAVER MODULE This zone type is for use with the Programmable Energy Saver Modules (PESM).
-
Page 44: Setup Digital Communicator
0-9999 COMMUNICATOR TYPE This item is used to select the transmitting parameters of the digital communicator. The Omni II can transmit in FAST 2300 Hz (20 PPS) mode, in SLOW 1400 Hz (10 PPS) 3/1 format, and in Contact ID. -
Page 45: Report Open/Close
REPORT OPEN/CLOSE The communicator can be setup to send an opening and a closing report by user code. Whenever the system is disarmed the communicator will send an opening report to the central station. When the system is armed, the communicator will send a closing report to the central station. -
Page 46: Setup Areas
SETUP AREAS To configure the system for multiple areas, from the Installer Setup menu, press the 4 (AREA) key. The number of areas must be specified. Also, consoles, zones, units, thermostats, and buttons must be assigned to areas. By default, the system is setup for one area. -
Page 47: Setup Areas: Zones
UNITS 71 AREAS: 0=CLR ↕ UNITS 72 AREAS: 0=CLR ↕ UNITS 73-80 AREAS: 0=CLR ↕ UNITS 81-88 AREAS: 0=CLR ↕ UNITS 89-96 AREAS: 0=CLR ↕ UNITS 97-104 AREAS: 0=CLR ↕ UNITS 105-112 AREAS: 0=CLR ↕ UNITS 113-120 AREAS: 0=CLR ↕ UNITS 121-128 AREAS: ↑... -
Page 48: Setup Areas: Consoles
BUTTONS 25-32 AREAS: 0=CLR ↕ BUTTONS 33-40 AREAS: 0=CLR ↕ BUTTONS 41-48 AREAS: 0=CLR ↕ BUTTONS 49-56 AREAS: 0=CLR ↕ BUTTONS 57-64 AREAS: ↑ 0=CLR SETUP AREAS: CONSOLES To assign consoles to areas, from the Setup Areas menu, press the 4 (CONS) key. Each console must be assigned to one and only one area. -
Page 49: Setup Temperatures
Messages can be setup so that they can be displayed in a specific area or in all areas. MESSAGES 1-8 AREAS: ↓ 0=CLR MESSAGES 9-16 AREAS: 0=CLR ↕ MESSAGES 17-24 AREAS: 0=CLR ↕ MESSAGES 25-32 AREAS: 0=CLR ↕ MESSAGES 33-40 AREAS: 0=CLR ↕... -
Page 50: Setup Miscellaneous
Remember this Installer code and do not disable. There is no way to reset or retrieve the code! If the code is forgotten or disabled, the Omni II controller must be sent back to the factory. Call for an RA#. -
Page 51: Call Back Phone Number
DIAL OUT DELAY The DIAL OUT DELAY is the number of seconds that the Omni II waits before making an emergency dial out, AFTER the alarm is "tripped" (activated by burglar or fire). This delay is set at the factory to 15 seconds. We recommend a minimum time of 15 seconds to preclude an accidental activation of the alarm from calling in a false alarm. -
Page 52: Supervise Int Sndr
This unit includes an alarm verification feature that will result in a delay of the system fire alarm signal from the initiating circuit. The total delay (Omni II controller plus detector delay) shall not exceed 60 seconds. No other initiating devices shall be connected to these circuits unless approved by the local authority having jurisdiction. -
Page 53: Date Display
CLOCK ADJUSTMENT If the clock on an Omni II is running faster or slower than the actual time, you can have the Omni II automatically compensate up to 29 seconds per day. The Omni II will add or subtract the selected amount of time daily. -
Page 54: Model And Software Version
MODEL AND SOFTWARE VERSION Next, the model number and software version for the system is displayed: HAI OMNI II ↕ S/W VERSION 2.0 RESET SYSTEM EEPROM Select the 1 (YES) key to reset the EEPROM. All programs, names, and setup items will be reset. All system RAM will also be initialized and the system will restart. -
Page 55: Setup Expansion
SERIAL 1 RATE "Serial 1 Rate" selects the baud rate used for the built-in serial interface (J1 Serial) on the Omni II controller. Select the baud rate for the built-in serial interface from the list. Use the arrow keys to select the baud rate then press the ' # ' key. -
Page 56: Serial 1 Function
SERIAL 2 RATE "Serial 2 Rate" selects the baud rate used when a Serial Interface Module is added to the Omni II system. If a Serial Interface Module is installed, select its baud rate then press the ' # ' key. -
Page 57: Omni Ii Specifications
OMNI II SPECIFICATIONS Size: Controller: 13 W x 13 H x 4.5 D Console: 4.6 W x 4.5 H x 1.2 D Weight: Controller: approx. 10 lb. Console: approx. 0.5 lb. Operating 32 - 122 degrees F (0 - 50 degrees C) -
Page 58: Underwriter's Laboratories (Ul) Installation Requirements
UNDERWRITER'S LABORATORIES (UL) INSTALLATION REQUIREMENTS The Omni II control units (20A00-1, -4, and -12) are suitable for Grade A household burglar and fire applications. Refer to UL1641 for installation requirements. Model 20A00-4 is also suitable for use in Commercial Burglar Alarm Applications, Grade B, C Central Station, Grade A Local, and Grade A Police Connect. -
Page 59: 24-Hour Standby Battery Capacity
24-HOUR STANDBY BATTERY CAPACITY Maximum current ratings for 24-hours: Aux 12 VDC, Switch 12 VDC, Console, and Outputs 1-8: 250 mA Interior Horn and Exterior Horn: 350 mA 3M, P/N 952 SNAP CONNECTOR OVER WIRE 12" 12" BLACK BLACK WIRE TO - RED WIRE TO + BATTERY BATTERY... -
Page 60: Smoke Detector Installation Guidelines
SMOKE DETECTOR INSTALLATION GUIDELINES Ceiling mounted smoke detectors should be located in the center of the room or hall, or not less than 4 inches from any wall. When the detector is mounted on a wall, the top of the detector should be 4 to 12 inches from the ceiling. Do not install smoke detectors where normal ambient temperatures are above 100 deg. -
Page 61: Appendix A - Contact Id Reporting Format
APPENDIX A – CONTACT ID REPORTING FORMAT ZONE TYPE TRIP TROUBLE DESCRIPTION Entry/exit (also Double & Quad) Entry/exit burglary Perimeter (also Latching) Perimeter burglary Night Interior (also Latching) Interior burglary Away Interior (also Latching) Interior burglary Panic Panic alarm Police Emergency Panic alarm Silent Duress Silent panic... -
Page 62: Appendix B - Digital Communicator Code Sheet
__________________________________________________ Phone #: __________________________________________________ Relationship: __________________________________________________ 3. Name: __________________________________________________ Phone #: __________________________________________________ Relationship: __________________________________________________ Subscriber Equipment: Home Automation, Inc. - Omni II Notes: __________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ First Phone #: ____________________________________________ First Account #: ____________________________________________ Second (Backup) Phone #: __________________________________... - Page 63 CODE ZONE DESCRIPTION ACTION TO TAKE TEST CODE _________________________ __________________________________ ZONE 1: _________________________ __________________________________ ZONE 2: _________________________ __________________________________ ZONE 3: _________________________ __________________________________ ZONE 4: _________________________ __________________________________ ZONE 5: _________________________ __________________________________ ZONE 6: _________________________ __________________________________ ZONE 7: _________________________ __________________________________ ZONE 8: _________________________ __________________________________ ZONE 9:...
- Page 64 CODE ZONE DESCRIPTION ACTION TO TAKE ZONE 28: _________________________ __________________________________ ZONE 29: _________________________ __________________________________ ZONE 30: _________________________ __________________________________ ZONE 31: _________________________ __________________________________ ZONE 32: _________________________ __________________________________ ZONE 33: _________________________ __________________________________ ZONE 34: _________________________ __________________________________ ZONE 35: _________________________ __________________________________ ZONE 36: _________________________ __________________________________ ZONE 37:...
- Page 65 CODE ZONE DESCRIPTION ACTION TO TAKE CANCEL CODE _________________________ __________________________________ OTHER OPEN _________________________ __________________________________ USER 1 OPEN _________________________ __________________________________ USER 2 OPEN _________________________ __________________________________ USER 3 OPEN _________________________ __________________________________ USER 4 OPEN _________________________ __________________________________ USER 5 OPEN _________________________ __________________________________ USER 6 OPEN _________________________ __________________________________ USER 7 OPEN...
- Page 66 CODE ZONE DESCRIPTION ACTION TO TAKE USER 10 CLOSE _________________________ __________________________________ USER 11 CLOSE _________________________ __________________________________ USER 12 CLOSE _________________________ __________________________________ USER 13 CLOSE _________________________ __________________________________ USER 14 CLOSE _________________________ __________________________________ USER 15 CLOSE _________________________ __________________________________ USER 16 CLOSE _________________________ __________________________________ Page 60...
- Page 68 HAI • New Orleans, LA • U S A...
