- Page 1 Omni LTe Control & Security System Includes the SIA CP-01 Control Panel Standard Features for False Alarm Reduction Owner's Manual...
-
Page 3: Warnings And Cautions
WARNINGS AND CAUTIONS • Read and understand all instructions. Follow all warnings and instructions marked on the product. • Do not use this product near water - e.g., near a tub, wash basin, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. -
Page 4: Table Of Contents
Trouble Beeps ................................5 Confirmation Beep ..............................5 Cancel ..................................5 Time Out ................................... 5 Omni LTe Maintenance ..............................5 SECURITY SYSTEM OPERATION ....................6 Disarming the Security System and Silencing Alarms ....................6 Arming the Security System ............................6 Using Shortcut Keys .............................. - Page 5 CONTROL ............................. 15 Control Commands ..............................15 About UPB .................................. 16 HLC Format ................................16 About Rooms ................................16 About Scene Switches ............................16 Scene Switch LED Indicators ..........................17 About House Status Switches ..........................17 About Vizia RF Z-Wave .............................. 17 Vizia RF Z-Wave Format ............................
- Page 6 How the Omni LTe Voice Dialer Works ........................44 What the Omni LTe Voice Dialer Does ........................44 What the Omni LTe Voice Dialer Does ........................45 What You Hear - If Your Omni LTe Calls You ......................45 Entering the Code ..............................45 PC Access ............................. 46 Built-In Ethernet Port ..............................
- Page 7 Edit Programs When ..............................54 Times Programs ..............................54 Button and Event Programs ............................55 Control Unit / Switch Press Event Buttons ......................55 Security Mode Event Buttons ..........................56 Zone Event Buttons ..............................57 All On/Off Event Buttons ............................57 UPB Link Event Buttons .............................
- Page 8 Set up Miscellaneous ..............................69 Controller IP Address .............................. 69 Controller Port Number ............................69 Encryption Key ................................ 69 Latitude, Longitude, and Time Zone ........................70 Daylight Savings ..............................71 Time Clocks ................................71 High Security Mode ..............................72 Announce Alarms ..............................72 Enable Freeze Alarm ..............................
- Page 9 LEVITON Access Control ............................93 Validating LEVITON Access Control Cards and Key Tags ..................93 Logging of the User assigned to the Access Control Card or Key Tag ..............94 Activating an Electric or Magnetic Lock ......................... 94 Arming or Disarming of the Security System ......................94 Activating Automation Programs ..........................
-
Page 10: Introduction
INTRODUCTION Thank you for purchasing your new Omni LTe automation system. You are about to enjoy a new feeling of security, comfort, convenience, and control. Omni LTe coordinates lighting, heating and air, security, scenes, messages, and audio based on your lifestyle and schedule. -
Page 11: Overall Description
Console Operation The console is designed with everything that is necessary for you to program and operate your Omni LTe control and security system. Because we feel that it is very important for you to feel comfortable with the operation of your Omni LTe, we recommend that you start by becoming familiar with your console. -
Page 12: Normal Top-Level Display
4:00 PM SYSTEM OK If one of the doors, windows, motion, or other detector connected to the Omni LTe is open, or has detected motion, the bottom line of the display will say, "ZONE NAME NOT RDY". For example, the display will show, "FRONT DOOR NOT RDY". -
Page 13: Display Menus
Display Menus The system has been designed to be easy to operate. Whenever you press a key on the console, the top line of the display will indicate what you are doing. To the right of that is your selection or current setting. The bottom line will show a menu of your next options. -
Page 14: Error Beeps
Trouble Beeps The Omni LTe constantly checks the entire system for proper operation. If trouble is found, the trouble is displayed on the bottom line and the console will beep at the rate of two beeps per second to alert you to the trouble. This feature can be turned off if desired - See Set Up Arming, Beep On Trouble. -
Page 15: Security System Operation
SECURITY SYSTEM OPERATION Disarming the Security System and Silencing Alarms Before going any further, you should know how to disarm your security system in the event that the alarm sounds. Turning the system OFF disarms the burglar alarm, resets emergency alarms, and silences all sirens and sounders. Press the OFF key. -
Page 16: Using Shortcut Keys
The programmed Exit Delay is __________ seconds. Quick Arm For extra convenience, the Omni LTe can be armed by simply pressing the DAY, NIGHT, or AWAY button twice, eliminating the need to enter the code. To quick arm the system in the Away mode, from the top-level display, press:... -
Page 17: What Happens When You Arm The Security System
What Happens When You Arm the Security System To arm the system into one of the 6 security modes, from the security menu, choose the security mode and press the appropriate key (1 - 6), and then enter your user code number on the console keypad or use one of the Shortcut Keys as described. -
Page 18: Bypassing Zones
In order to prevent the alarm from sounding unexpectedly if a window or door is open when the system is armed, the Omni LTe will automatically bypass the zone if it is opened when the system is armed. Note that there is an exit delay before the system is armed in any mode. The bypass will only take place if the zone is not ready (i.e. -
Page 19: What To Do When You Come Home
If enabled, the system waits the Dial Out Delay (15-45 seconds), and then if programmed, the in-house • phones are seized (disconnected) and the Omni LTe begins to dial out. There is a communicator delay (Dial Out Delay) of 30 seconds in this control panel. It can be removed, or it can be increased up to 45 seconds, at your option by consulting with your installer. -
Page 20: Fire Alarm Activated
Fire Alarm Activated When the fire alarm is activated by the smoke/fire detector(s), the alarm responds exactly as described under Burglar Alarm Activated, except: The console display reads, " FIRE ALARM! - ZONE NAME TRIPPED ". • The sounder will activate in a 3 pulse temporal pattern to distinguish the fire alarm from the burglar alarm. •... -
Page 21: Police Emergency
Police Emergency When the 1 key and the 3 key is pressed simultaneously, the Police Emergency alarm is activated. This alarm operates exactly the same as described for Burglar Alarm Activated except: The console display indicates: " BURGLARY! - POLICE EMERG TRIPPED ". •... -
Page 22: Trouble Indications
Codes There are 16 user codes that you may assign to users of the system. All Omni LTe codes are 4 digits in length. A code can be any number from 0001 to 9999. Each user should be assigned a security code with an authority level and times and days in which the code will be valid. -
Page 23: Manager Code
The Battery reading should be over 200 - See Status \ Test. Pick up an inside phone and press the # key. When the menu is spoken, press 8, Then 3. The Omni LTe should say "ADDRESS IS: "and play your name and address. If it does, the telephone dialer, telephone access and telephone control systems are all working correctly. -
Page 24: Control
Control Commands The control features of the Omni LTe make it easy and convenient to control almost any light or appliance from the console or over the telephone. You may also have your heating and air conditioning (HVAC) under control of the system, which will allow you to save energy dollars by setting the temperature appropriately when you are home, asleep, or away. -
Page 25: About Upb
Each “House Code” that is configured to use the HLC format consists of 2 rooms with up to 8 HLC devices in each room. Omni LTe supports up to 4 rooms of HLC lighting. Omni LTe can control up to 32 HLC devices. -
Page 26: Scene Switch Led Indicators
D), the LED indicator behind the respective scene letter is illuminated and all others are turned off. When “Status Tracking” is enabled (this is the default setting), Omni LTe keeps track of the exact status of each unit even when a lighting scene is initiated by the Scene Switch. Scene Switch s also keep track of when individual switches in a room are turned on and off. -
Page 27: About X-10
Units 2-8). Using a console, touchscreen, or other interface to Omni LTe, the room can be turned off (all loads in the group are turned off), turned on (all loads in the group are turned on), or set to one of 4 lighting scenes (A-D). -
Page 28: Unit Numbers
Unit Numbers Omni LTe systems have 88 total Unit Numbers. They consist of HLC, UPB, Vizia RF, and X-10 module unit numbers, hardwire voltage output unit numbers, and internal flag unit numbers as follows: Omni LTe Module / Output Unit Numbers... -
Page 29: Configuring Lighting Scenes In An Hlc Room
• Timed commands may be from 1-99 seconds, 1-99 minutes or 1-18 hours. Press # (STA) to see the exact status of a UPB device. When the ' # ' key is pressed, Omni LTe sends a “Status Request” message to the selected device for its current state. The exact state is then displayed. -
Page 30: Controlling Vizia Rf Z-Wave
The only exception is for additional Wall Controllers. If you have assigned a Node ID to a Unit, but do not name it, the Omni LTe will interpret that as a Wall Controller, so Vizia RF messages from that Wall Controller will not be ignored. -
Page 31: Controlling X-10 Units
At this point, one of the menu choices may be entered or the ' * ' or ' # ' key may be pressed to redisplay the menu. Note: If a signal is received, Omni LTe will automatically update the status of the unit. -
Page 32: Internal Flags
Note: UPB devices are not affected by the Omni LTe “All On” or “All Off” command. To achieve this functionality, we suggest the following: UPB: Program a Link into each device that will respond to an Omni LTe “All On” and “All Off” command program. For example: In each UPB switch that will respond to “All Off”... -
Page 33: All Lights On
LTe controller or to a pushbutton on a 6-Button or 8-Button Keypad. Omni LTe can “set” each of the 250 possible Links. The “Link Set” command is used to set up lighting scenes for a lighting group. To set a “lighting scene” using Omni LTe, adjust all of the UPB Wall Switches with the pre-configured Link to the desired lighting levels. -
Page 34: Buttons
Buttons A powerful feature of the Omni LTe is the ability to program Buttons. A Button (also known as macro) is a number on the keypad that is programmed to execute a series of commands when it is pressed. Buttons are used to program functions that are specific to your home and lifestyle. -
Page 35: Omnistat Communicating Thermostats
Omnistat Communicating Thermostats The following control actions are allowed for Omnistat Communicating Thermostats: Set heating setpoints • Set cooling setpoints • Set system mode (Off / Heat / Cool / Auto) • Set fan (On / Auto) • Turn hold On and Off •... -
Page 36: Programmable Energy Saver Modules (Pesms)
The PESM is used when you are have any thermostat, other than an Omnistat Thermostat, and would like to control your heating and cooling system with the Omni LTe system. The PESM is a temperature sensor and control relay in a small enclosure that mounts near your central heating, ventilation, and air conditioning (HVAC) system thermostat. - Page 37 The PESM provides an energy saver function. When the energy saver is on, the HVAC system is set back, meaning that the temperature is allowed to rise or fall to an energy saving level. When the energy saver is off, your thermostat operates normally.
-
Page 38: Freeze Alarms
For temperature sensors: Upstairs 2=LOW 3=HIGH #=STAT To set a temperature setpoint, press 2 (HEAT) or 3 (COOL). For Celsius temperatures, press the ' # ' key prior to entering the temperature to make the number negative. The Celsius temperature may also be specified in 0.5 degree steps if three numeric digits are entered. The third digit adds a .5 to the first two digits if it is any- thing other than zero. -
Page 39: Indoor And Outdoor Temperature
Temperature Control of Appliances You can control appliances (such as a ceiling fan) using Advanced Control Programming (ACP) of the Omni LTe. For example, the ceiling fan can be programmed to come on if the temperature goes above the High temperature. -
Page 40: Status
Note: Only LEVITON manufactured UPB™ devices (collectively referred to as HLC devices) can be configured using an Omni LTe controller. Other UPB™ devices may be used, but cannot be configured using the Omni LTe controller; they must be configured using a PC running the UPB™ UPStart configuration software. -
Page 41: Configuring Hlc Devices
When configuring HLC devices using an Omni console or OmniTouch touchscreen, each device (unit number) must first be assigned a name in the Omni LTe controller. It is recommended that you first configure your Omni LTe controller (naming all of the HLC units) using the LEVITON PC Access Software, and then download the information to the Omni LTe controller. -
Page 42: Setup Mode For Hlc Devices
Note: The HLC 8-Button House Controller will automatically exit Setup mode after 5 minutes. To manually exit Setup mode, press and hold the “1” and “8” pushbuttons simultaneously for at least 3 seconds. Note: When Omni LTe finishes configuring the device, it will automatically exit Setup mode and return to normal operation. - Page 43 4 = TEST (SYSTEM DIAGNOSTIC TEST) The diagnostic test performed by the Omni LTe allows you to check the status of the battery, telephone, bell circuit, auxiliary fuse, and security zone loop readings. The display is updated 3 times per second, although the actual readings are taken 10 times per second.
-
Page 44: Event Log
5 = TEMP (TEMPERATURE) The Temperature Status menu allows you to view and scroll through the status of each Thermostat, PESM, and Temperature Sensor. To enter the Temperature menu, from the Status menu, press the 5 key on the console keypad. The system will display: TSTAT 1 TEMP:80... -
Page 45: Messages
For trouble restorations, the event log will show the zone name or specific trouble condition and "TRBL RST": 11:57 AM BATTERY TRBL RST The system records each remote access. A remote phone access is when someone calls into the system from an outside phone line. -
Page 46: Clear Message
Clear Message The 3 (CLEAR) key allows you to clear the selected text message, or all text messages from the console's display. TRASH NIGHT ENTER MESSAGE 0=ALL ↓ You may enter the message number followed by the ' # ' key to clear that message, or simply press the down arrow key to scroll through a list of messages. - Page 47 If one is found, the Program Command (macro) corresponding to the matching message is activated. When receiving an ASCII message that is over 15 characters, Omni LTe only processes the last 15 characters of the message. Pro-Link determines that a message has been received when: One or more characters have been received followed by 100 ms of silence •...
-
Page 48: Telephone Control
Each time you pick up your telephone at home, the Omni LTe will also pick up the line and listen for a # (pound) key. If Omni LTe does not hear the # key within 5 seconds, it hangs up and does not listen in again until the next time you pick up your phone. -
Page 49: Phone Access Denied - Remote Lockout
If it does not hear any numbers from your phone in 10 to 15 seconds after it stops talking, the Omni LTe will hang up. If you are on a remote phone and the Omni LTe hangs up, you must call the Omni LTe again. If you are on an in-house phone, hang up, wait a few seconds, then pick up and press the # key. -
Page 50: Control
When bypassing and restoring a zone, if voice descriptions have been programmed, after a three-second delay, the system will begin reading from the list of zones. If the ' # ' key is pressed, Omni LTe will read the next three descriptions (if programmed). -
Page 51: Status
Press 7 from the MAIN MENU to get to the EVENT menu. The Omni LTe will read the 3 latest events. Press the ' 7 ' key for Omni LTe to read 3 more events, or ' * ' to cancel. -
Page 52: Phone
Press 9 from the MAIN MENU. The Omni LTe will say, "GOOD-BYE" and hang up. From an in-house phone, the dial tone will return. From a remote phone, you will hear a click as the Omni LTe hangs up. It is recommended that you press 9 to terminate a remote call. If you don't, the Omni LTe will hang up anyway after about 15 seconds. -
Page 53: Emergency Dial-Out
In UL Listed Installations, the Voice Dialer is supplementary to the Digital Dialer described above. The voice dial-out feature of the Omni LTe is a sophisticated system that can notify you at the office, on vacation, on a pocket pager, or notify your neighbor, a relative, and in some cases, local authorities. -
Page 54: What The Omni Lte Voice Dialer Does
"SECURITY MODE IS OFF - SYSTEM OK" as described in Telephone Control. If a reportable event (an alarm, cancel, etc.) occurs while you are talking to your Omni LTe, it will hang up on you to communicate the event to the central station. -
Page 55: Pc Access
Omni LTe is capable of communicating with a personal computer (PC). The PC can be local (in-house) or remote. The PC must be equipped with a modem or serial port and running PC Access software. The Omni LTe has a built-in modem and can be accessed over the telephone or over a direct serial connection (RS-232/RS-485 through either a built-in or optional serial interface module). -
Page 56: Local Network
(the router/switch) in the local network. This allows you to locate and connect to the Omni LTe controller without having a computer on the local network powered up and running. -
Page 57: Local / Wide Area Network
To connect to an Omni LTe controller from the Internet using HAI PC Access, under Configure >> Network enter the public IP address: To connect to an Omni LTe controller on a local network using HAI PC (i.e. 134.42.112.8) Access, under Configure >> Network enter the controller’s IP address:... -
Page 58: Setup
Set Up Codes Omni LTe has 16 user codes that you may assign to users of the system. All Omni LTe security codes are 4 digits in length (0001 to 9999) and must be unique. The controller will not allow the duplication of any user code including the Duress Code. -
Page 59: Access Times
Duress Code instead of your normal code. The system will disarm normally. No sirens will sound, no lights will flash, but the Omni LTe will perform a silent dial out and say that this is a silent alarm. To stop a silent dial out, turn your security system off by pressing OFF, then your code. -
Page 60: Advanced Control Programming (Acp)
You are only asked this question when you set the time. Once the time is set, Omni LTe will automatically adjust the "time of day" each time daylight savings time begins and ends. Finally, you are prompted to enter the current date:... -
Page 61: Show Programs
2 = Show Programs The 2 (SHOW) key is used to review, edit, and delete existing programs. From the Set Up Program menu, press the 2 (SHOW) key. The display prompts you to specify which program to be reviewed. 1=CTRL 2=SEC 3=BTTN 4=ALL... -
Page 62: Delete All Programs
When 2 conditions are part of a single program, the conditions are not displayed on the console. Instead, "&MULTI" is displayed to let you know that this program line contains 2 conditions. To view or edit the program, you must use the PC Access Software. -
Page 63: Edit Programs When
Edit Programs When Selecting the 1 (WHEN) key, from the Edit Program menu, allows the time or button/event that activates the program to be changed. The display shows: EDIT WHEN 1=TIMED 2=BUTTON Times Programs Selecting 1 (TIMED) sets the program to be activated at a specific time of day. You are prompted to enter the time and date or days of week. -
Page 64: Button And Event Programs
Button and Event Programs Selecting 2 (BUTTON), from the "Edit When" menu, sets up a program to be activated when a macro button is executed or an event occurs. The user is prompted to specify the button/event that activates the program: BUTTON: ENTER BUTTON #=MENU... -
Page 65: Security Mode Event Buttons
Corresponding Switch Table Switch Omni LTe UPB 6-Button Keypad UPB 8-Button Keypad On Button 1 or E Off Button 2 or F 3 or G 4 or H 5 or I 6 or J 7 or K 8 or L... -
Page 66: Zone Event Buttons
Zone Event Buttons Pressing the 3 (ZONE) key allows you to select the event button for a zone activation event. You are first prompted to enter the desired zone number: ZONE: ENTER ZONE ↓ The zone number should be entered followed by the ' # ' key, or the arrow keys may be used to scroll through a list of zones. -
Page 67: X-10 Event Buttons
Pressing the 6 (X-10) key allows you to specify an event button activation upon receipt of an X-10 command from a source external to Omni LTe. The Omni LTe can also respond to scene changes initiated at Compose keypads and dimmers. -
Page 68: Message Event Buttons (Pro-Link)
Message Event Buttons (Pro-Link) Pressing the 8 (MSG) key allows you to select an event button from a list of the 64 text messages. You are first prompted to select the message: MESSAGE: ENTER MESSAGE ↓ The message may be entered by entering the message number followed by the ' # ' key or by using the arrow keys to scroll through the list of messages. -
Page 69: Unit Toggle Command
WHEN LINK 1 ON: Porch Light STATUS When “Link 1 On” is received on the UPB network, Omni LTe sends a status request message to the UPB Wall Switch (named Porch Light) to acquire its current status. This “Status Request” program is particularly beneficial to keep the current state of UPB devices that are altered by a “lighting scene”... -
Page 70: Timed Level Command
Timed Level Command Using LEVITON PC Access Software, you can create programs to set the light level for a specified time. For example, when the Front Door opens and it is dark outside, you can have the Foyer Light illuminate at 50% for 5 minutes with a single program line. -
Page 71: Program Energy Cost
This feature will allow you to raise or lower the temperature from its current (comfortable) setting when you change the security mode (e.g. you leave the house) and have it return to that temperature when you return home. WHEN AWAY: DOWNSTAIRS RAISE COOL SETPOINT 5 WHEN OFF: DOWNSTAIRS LOWER COOL SETPOINT 5 Program Energy Cost Select the 6 (ENERGY) key to command the energy cost rate. -
Page 72: Enable Or Disable Beeper Programmatically
Enable or Disable Beeper Programmatically Using LEVITON PC Access Software, you can create programs to either enable or disable the console or touchscreen beeper; individually or all devices. When the beeper is disabled, no audible beeps are emitted from the device, except for alarm conditions. -
Page 73: Program Zone Conditions
Next, select whether the system is considered in the specified mode during the exit delay: INCLUDE EXIT DELAY? 0=NO 1=YES Program Zone Conditions Select the 3 (ZONE) key to specify that the program should only execute if a specified security zone is either Secure or Not Ready. -
Page 74: Set Up Dial
Set Up Dial The Set Up Dial menu is used to configure all of the telephone related items for the Omni LTe. To enter the Set Up Dial menu, from the Setup menu, press the 4 (DIAL) key. Use the arrows to scroll through the items. For each item, the top line displays a description of the item and its current setting. -
Page 75: Rings Before Answer
DIAL OUT 1 OFF Dial Out Number 1 has two times associated with it, an On time and an Off time. The Omni LTe will only call this number if the time and days are between the Dial Out 1 On and Dial Out 1 Off times and dates. -
Page 76: Dial Out Numbers 2-8
For example, if your normal work hours are 8 to 5 Monday through Friday, then set Dial Out 1 On to 8:00 AM MTWTF and Dial Out 1 OFF to 5:00 PM MTWTF. With these settings, the system will call Dial Out Number 1 only if the alarm is activated on weekdays between the hours of 8:00 AM to 5:00 PM. -
Page 77: Exit Time Restart
Exit Time Restart When Exit Time Restart is set to Yes, the Exit Delay will restart if the same exit zone is violated twice within the original exit delay. For example, after arming the system if you open the front door to leave, close the front door behind you, and then reenter through the front door while the exit delay is still in effect, the exit delay will be restarted. -
Page 78: All On For Alarm
Beep On Trouble If the Omni LTe detects any troubles with itself or one of the zones connected to it, it will display a message on the screen and beep the console twice per second, continuously (i.e. beep beep...beep beep...). You can silence this sound by pressing the ' * ' key. -
Page 79: Latitude, Longitude, And Time Zone
Prime Meridian, and time zone. These items should be set to the proper values for the location where the Omni LTe is installed. The latitude and longitude for a particular location may be obtained from an almanac or map of the area. -
Page 80: Daylight Savings
Daylight Savings The Omni LTe automatically calculates the day of daylight savings time each year. It also adjusts the "time of day" each time daylight savings time begins and ends. To enable the system to properly calculate daylight savings time, a start month, start weekend, end month, and end weekend is set-up at the factory. -
Page 81: High Security Mode
High Security Mode In High Security Mode, the Master or Manager code is always required to do the following functions: Any Control functions • Any Temperature Control • View the Event Log • Access the system from a local phone •... -
Page 82: House Codes 1 And 2 Format
House Code (even though it doesn’t explicitly send an All Off or All On command to those units). If the “House Code All Off” or “House Code All On” setup item is set to “No”, Omni LTe will not change the status of units on that House Code. - Page 83 Page 74...
-
Page 84: Set Up Names
Set Up Voice The Omni LTe can be set up to speak descriptive names such as "FRONT DOOR" for control zones, units, buttons, codes, temperatures, and messages. These names will be spoken over the telephone along with the item number that is normally spoken. -
Page 85: Set Up Address
To record your address, Press 9, then enter the Master code. This is the address that the system says when it dials out in an emergency. Your voice will be recorded on computer chips in the Omni LTe controller and saved to be played back in the emergency message when the system dials out for an alarm. -
Page 86: Audio Control
The names that are displayed on the OmniTouch touchscreen interface for Audio Source and Audio Zone must be configured in the Omni LTe controller. A name must be given to each Audio Source and Audio Zone to make it available in the respective list box when changing the Audio Source or Audio Zone. -
Page 87: Programming Audio Commands
Play/Pause Example Programming of Audio Commands You can create programs in your Omni LTe to customize your music experience. For example, you can create programs to play your favorite music when you return home and disarm your system. When the security system is disarmed by Bob, execute the “Bob Is Home” macro: WHEN Bob OFF: RUN Bob Is Home When the “Bob Is Home”... -
Page 88: Underwriter's Laboratories Requirements
UNDERWRITER'S LABORATORIES REQUIREMENTS For a complete list of requirements and restrictions when installing the Omni LTe panel in a UL Listed system, refer to the Underwriter's Laboratories Requirements section of the Omni LTe Installation Manual (20I00-70). When used in UL Listed Installations, the following items apply: The “High Security Mode”... -
Page 89: Federal Communication Commission Notice
FEDERAL COMMUNICATION COMMISSION NOTICE: This equipment complies with Part 68 of FCC Rules. On the door, inside of the Omni LTe enclosure, is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment. -
Page 90: Canadian Industry Canada Notice
IF YOU HAVE TROUBLE WITH YOUR PHONES ...and you suspect that your Omni LTe is causing the trouble, disconnect the Controller from the phone lines by removing the PHONE LINE cable from BOTH THE PROCESSOR BOARD AND THE RJ31X JACK INSIDE THE CONTROLLER ENCLOSURE. -
Page 91: Appendix A - Dial Out Planner
APPENDIX A - DIAL OUT PLANNER Use the following dial-out planner to help you set-up the voice dial-out numbers: Omni LTe Voice Dial-Out Planner DIAL OUT NUMBER 1: __________________________________ DIAL OUT 1 ON: TIME: _______________ DAYS: _______________ DIAL OUT 1 OFF:... -
Page 92: Instructions To Called Party
Dear ___________________________________________________________________ I have programmed my Omni LTe automation and security system to call you if my alarm is activated. If it is activated, it will call and say: "Emergency... Emergency... The (burglar or fire) alarm has been activated at the... -
Page 93: Appendix B - Text Description Character Codes
APPENDIX B - TEXT DESCRIPTION CHARACTER CODES CODE CHAR CODE CHAR CODE CHAR CODE CHAR SPACE " < & > ¥ × ¯ à ß Page 84... -
Page 94: Appendix C - Voice Description Codes
APPENDIX C - VOICE DESCRIPTION CODES CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION (ADDRESS MSG) BOARD CURTAIN (BEEP) BOAT DAMPER (MEMO MESSAGE) BOILER DANGER (PAUSE) BOTTOM DATE (SHORT PAUSE) BOUDOIR A. M. BOY'S DEAD ABOVE BREAK DECEMBER AC POWER BREAKFAST DECK ACCESS BRIGHTER DECREASE... - Page 95 CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION EXTERIOR HARBOR LOCK FACTORY HAVE LOFT FAILURE HEAT FALL HELLO LOWER FAMILY HELP MACHINE HIGH MAID'S FATHER’S HIGHER MAIL FAULT HOBBY MAIN FEBRUARY HOLD MANAGEMENT FENCE HOLIDAY MANAGER FIFTEEN HOME MARCH FIFTY MASTER FILE HOURS FILTER HOUSE...
- Page 96 CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION RESIDENCE STEPS RESTORE STOCK RESTRICTED STORAGE ONLINE RIGHT STORE ONLY RISE STUDIO OPEN ROMANTIC STUDY OPTION ROOF SUITE ROOM SUMMER OTHER SUMP SAFE OUTDOOR SAFETY SUNDAY OUTLET SATELLITE SWITCH OUTSIDE SATURDAY SYSTEM OK OVER SAUNA TABLE OVERFLOW...
- Page 97 CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION VACATION WALK WINDOW VALVE WALKWAY WINE VANITY WAREHOUSE WING VAULT WARNING WINTER WATER WOOD VIDEO WEDNESDAY WORK VISITOR WELCOME TO OMNI YARD VOLUME WELCOME WAITING WEST ZONE Page 88...
-
Page 98: Appendix C - Advanced Features
Omni LTe has 10 User Settings which may be used. Once configured by your installer, you can name and assign values to each of the preconfigured User Settings. To assign names to User Settings, under Setup | Names select 9 (USET). -
Page 99: Enhanced Programming
Enhanced Programming consists of several new features and structures that allow you to take full advantage of the powerful programming capabilities of your Omni LTe controller. Enhanced Programming includes: Program block that may have multiple triggers, multiple conditions, and multiple actions •... -
Page 100: Enhanced Conditions
The current real-time status for heating, cooling, humidifying, and dehumidifying can also be used in automation programming logic. Omnistat2 Features There are several features on Omnistat2 thermostats that are supported by the Omni LTe controller. These features include: Fan Cycle Mode ... -
Page 101: Fan Cycle Mode
Fan Cycle Mode In Fan Cycle mode on an Omnistat2 thermostat, the fan is cycled on and off in 20 minute cycles to circulate the air. The fan control may be switched between auto, on, and cycle by selecting 4 (FAN) from the temperature menu of the selected Omnistat2 thermostat: Upstairs FAN 0=AUTO 1=ON 2=CYCLE... -
Page 102: Occupancy Status
Time and Date The Omni LTe now sends the current time of day and the date to the Omnistat2. As long as the time and date is correct on the Omni LTe, there is no need to set the time or date on the Omnistat2. -
Page 103: Logging Of The User Assigned To The Access Control Card Or Key Tag
User Setup Each Access Control Card and Key Tag used is assigned to a code in the Omni LTe controller. The Access Control Card or Key Tag is governed by the validation times/days set for the code (i.e. the Access Control Card or Key Tag is only valid when the code is valid). -
Page 104: Enrolling Access Control Cards Or Key Tags
Each Access Control Card and Key Tag can be: Enrolled • Deleted • Enabled and disabled • Assigned to specific Access Control Readers • Configured to log activity • Configured for arming and disarming privileges • Access Control Cards and Key Tags can easily be enrolled and configured using an Omni console or PC Access software. -
Page 105: Enabling And Disabling Access Control Cards Or Key Tags
Enabling and Disabling Access Control Cards or Key Tags When an Access Control Card or Key Tag is enrolled into the system, by default it is enabled. This means that the Access Control Card or Key Tag may be used if it is valid for the current time of day and day of week. The Access Control Card or Key Tag may be temporarily disabled so that it cannot be used at any Access Control Reader. -
Page 106: Configuring Access Control Cards Or Key Tags For Arming And Disarming
Configuring Access Control Cards or Key Tags for Arming and Disarming Each Access Control Card or Key Tag may be configured to allow the user to arm or disarm the security system at Access Control Readers that are configured for arming and disarming. CARD 1 ARM/DISARM: 0=NO 1=YES... - Page 110 FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
