HAI OMNI II Owner's Manual

HAI OMNI II Owner's Manual

Omni ii control & security system
Hide thumbs Also See for OMNI II:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
.
HOME AUTOMATION, INC
Control & Security System
Owner's Manual
Document Number 20R00-1 Rev A
February, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNI II and is the answer not in the manual?

Questions and answers

Jackie Mattson
March 3, 2025

We purchased a home with this system already installed. We know absolutely nothing about it. Is there someone that can help us with this?

User image 67c5deac9fe38
0

Subscribe to Our Youtube Channel

Related Manuals for HAI OMNI II

Summary of Contents for HAI OMNI II

  • Page 1 HOME AUTOMATION, INC Control & Security System Owner's Manual Document Number 20R00-1 Rev A February, 2002...
  • Page 2 Copyright © 2001-2002 Home Automation, Inc. All Rights Reserved...

  • Page 3: Table Of Contents

    Error Beeps ....................................4 Trouble Beeps.....................................4 Confirmation Beep..................................5 Cancel ......................................5 Time Out.....................................5 Areas ........................................5 Omni II Maintenance ..................................5 SECURITY SYSTEM OPERATION ......................6 Disarming the Security System and Silencing Alarms ........................6 Arming the Security System ................................6 Using Shortcut Keys ..................................7 Quick Arm .......................................8 Bypassing Zones ....................................8...
  • Page 4 All On / Off....................................20 All Lights On ....................................21 All Off.......................................21 Leviton Scene Control ...................................21 Scene......................................21 Buttons ......................................22 Temperature Control ..................................23 HAI RC-Series Thermostats ................................23 Programmable Energy Saver Modules (PESMs) ...........................25 Freeze Alarms ...................................26 Outdoor Temperature................................27 Temperature Control of Appliances............................27 Temperature Alarms ..................................27 Status......................................27 Event Log.......................................29...
  • Page 5 Voice Dialer....................................38 How the Omni II Voice Dialer Works ............................38 What the Omni II Voice Dialer Does............................39 What You Hear - If Your Omni II Calls You ...........................39 Entering the Code ..................................39 SETUP................................40 Configuration and Advanced Control Programming (ACP) ......................40 Set Up Codes ....................................40...
  • Page 6 Set Up Dial.....................................54 Telephone Access ..................................54 Rings Before Answer ................................54 Dial Type ....................................54 My Phone Number ..................................54 Dial Out Number 1..................................55 Dial Out Numbers 2-8................................55 Dial Order ....................................55 Set Up Arming ....................................56 Entry Delay ....................................56 Audible Exit Delay..................................56 Entry/Exit Chime ..................................56 Perimeter Chime ..................................56 Enable Quick Arm ..................................57 Enable Auto Bypass..................................57...

  • Page 7: Introduction

    INTRODUCTION Thank you for purchasing your new Omni II automation system. You are about to enjoy a new feeling of security, comfort, convenience, and control. Omni II coordinates lighting, heating and air, security, scenes, and messages based on your lifestyle and schedule.

  • Page 8: Overall Description

    The console is designed with everything that is necessary for you to program and operate your Omni II control and security system. Because we feel that it is very important for you to feel comfortable with the operation of your Omni II, we recommend that you start by becoming familiar with your console.

  • Page 9: Normal Top-Level Display

    4:00 PM SYSTEM OK If one of the doors, windows, motion, or other detector connected to the Omni II is open, or has detected motion, the bottom line of the display will say, "ZONE NAME NOT RDY". For example, the display will show, "FRONT DOOR NOT RDY".

  • Page 10: Main Menu

    Trouble Beeps The Omni II constantly checks the entire system for proper operation. If trouble is found, the trouble is displayed on the bottom line and the console will beep at the rate of two beeps per second to alert you to the trouble. This feature can be turned off if desired - See Set Up Arming, Beep On Trouble.

  • Page 11: Confirmation Beep

    The console in each area acts as if it were controlling its own Omni II system. Each area is assigned, by your installer, a group of zones, control units, macro buttons, messages, and thermostats. These items can only be controlled where they have been assigned.

  • Page 12: Security System Operation

    SECURITY SYSTEM OPERATION Disarming the Security System and Silencing Alarms Before going any further, you should know how to disarm your security system in the event that the alarm sounds. Turning the system OFF disarms the burglar alarm, resets the fire and emergency alarms, and silences all sirens and sounders. Press the OFF key.

  • Page 13: Using Shortcut Keys

    2 = NIGHT The NIGHT mode is used when you are asleep and everyone in your household is at home. In the Night mode, your doors, windows, and non-sleeping area (i.e. downstairs) motion detectors are armed. In the Night mode, there is no entry delay. The alarm system sounder will be activated immediately if any door, window, or non-sleeping area (motion detector) is tripped.

  • Page 14: Quick Arm

    If a fire zone is bypassed, the console will continue to beep until that zone is restored - See Restoring Zones. Auto-Bypass In order to prevent the alarm from sounding unexpectedly if a window or door is open when the system is armed, the Omni II will automatically bypass the zone if it is opened when the system is armed.

  • Page 15: Goto

    The system waits the Dial Out Delay (0 - 60 seconds), then if programmed, the in-house phones are seized (disconnected) and the Omni II begins to dial out. If you are having your system monitored by a central station, the central station will be sent a code representing the type of alarm (burglary) and zone involved.

  • Page 16: Fire Alarm Activated

    For more information on the digital and voice dialer - See Digital Dialer and Voice Dialer. • The system continues to sound all alarms and flash the flashing light for 1-30 minutes after the alarm is activated. • After a 1-30 minute period, the sounder is turned off, and the alarm system resets itself. The console beeper stays on. If a zone is tripped after a reset, the sounder will again be activated, and the dialer will again dial out.

  • Page 17: Police Emergency

    Police Emergency When the 1 key and the 3 keys are pressed simultaneously, the Police Emergency alarm is activated. This alarm operates exactly the same as described for Burglar Alarm Activated except: • The console display indicates: "BURGLARY! - POLICE EMERG TRIPPED". •...

  • Page 18: Trouble Indications

    Codes There are 16 user codes that you may assign to users of the system. All Omni II codes are 4 digits in length. A code can be any number from 0001 to 9999. Each user should be assigned a security code with an authority level, areas that can be accessed (if area arming is used), and times and days in which the code will be valid.

  • Page 19: Manager Code

    If you have a code that is only valid in Area 1, you will not be able to disarm or arm Area 2. If you are in Area 1 and wish to disarm the security system in Area 2, Omni II will allow you to disarm Area 2 from the console in Area 1 if you have a Master code or a code that is valid for both areas.

  • Page 20: Goto Area

    If the ' 0 ' (ALL) key had been selected, the display will show: DISARM ALL AREAS ENTER CODE: #=AREA As the four-digit code is entered, "X" characters are echoed after the "ENTER CODE:" prompt. If the Master code or a valid code is entered, the console will beep one time and Area 2 will be disarmed. Even if Auto Bypass is enabled, the system will not arm another area if any zones in that area are not ready.

  • Page 21: Testing Your System

    The Battery reading should be over 200 - See Status \ Test. Pick up an inside phone and press the # key. When the menu is spoken, press 8, Then 3. The Omni II should say "ADDRESS IS: "and play your name and address. If it does, the telephone dialer, telephone access and telephone control systems are all working correctly.

  • Page 22: Control

    Control Commands The control features of the Omni II make it easy and convenient to control almost any light or appliance from the console or over the telephone. You may also have your heating and air conditioning (HVAC) under control of the system, which will allow you to save energy dollars by setting the temperature appropriately when you are home, asleep, or away.

  • Page 23: House Codes

    House Codes All of your X-10 modules, controlled by your Omni II, must be set to a House Code. A House Code can have 16 unit numbers. The House Code is set on each module using a dial. House codes are letters A through P.

  • Page 24: Controlling Units

    The control menu is used when controlling lights and appliances. To enter the control menu, from the top-level display or from the main menu, press the 1 (CTRL) key on the console keypad. Omni II will automatically display the first named item in that list.

  • Page 25: Ramp Command

    The console will beep and the lighting level will be adjusted. The top line of the console display will read: Entry Lights LVL 65 Ramp Command When ALC Switch Modules are being used, it is possible to ramp the lighting level of an ALC Dimmer Switch to a new level at a selectable ramp rate.

  • Page 26: Status Of A Unit

    Controlling Outputs The Omni II has eight outputs that can be used to switch relays. Outputs 1-8 are controlled as Unit Numbers 65-72, respectively. If the Interior Horn is configured as a "General Purpose" output, Unit Number 73 is used to control the output. If the Exterior Horn is configured as a "General Purpose"...

  • Page 27: All Lights On

    Leviton Scene Control Omni II supports Leviton Scene Control (a feature found in certain Leviton Switches). There are 64 Scenes that can be set and executed. The Leviton Switches are divided into "lighting groups" of four units each. Each of these lighting groups can be set to four different Scenes.

  • Page 28: Buttons

    Buttons A powerful feature of the Omni II is the ability to program Buttons. A Button (also known as macro) is a number on the keypad that is programmed to execute a series of commands when it is pressed. Buttons are used to program functions that are specific to your home and lifestyle.

  • Page 29: Temperature Control

    Press the ' # ' key when the desired temperature zone is shown. Press the ' 0 ' key to select all HAI Thermostats. This is a simple way to broadcast the new Heat or Cool setting or change the system mode, fan mode, or hold mode of all HAI thermostats in your system.
  • Page 30 Upstairs ↑ 4=FAN 5=HOLD #=STAT To change the system mode on a thermostat, press 1 (MODE). A menu presenting options appropriate for that type of thermostat is then displayed. For heat/cool thermostats with auto changeover: Upstairs MODE ↓ 0=OFF 1=HEAT 2=COOL Upstairs MODE ↑...

  • Page 31: Programmable Energy Saver Modules (Pesms)

    (HVAC) system thermostat. The PESM allows the Omni II to read the temperature of the area that the HVAC system controls. When you are away or asleep, the PESM can be set to allow the temperature to drift higher or lower to reduce the operating time, hence saving energy dollars.

  • Page 32: Freeze Alarms

    After the ' # ' key is pressed, a menu appropriate for the type of temperature zone is shown. For Programmable Energy Saver Modules: Upstairs ↓ 0=OFF 1=ON 2=HEAT Upstairs ↑ 3=COOL 4=TIME #=STAT For temperature sensors: Upstairs 2=LOW 3=HIGH #=STAT To set a temperature setpoint, press 2 (HEAT) or 3 (COOL).

  • Page 33: Outdoor Temperature

    You can control appliances connected to X-10 and ALC modules (such as a ceiling fan) using Advanced Control Programming (ACP) of the Omni II. For example, the ceiling fan can be programmed to come on if the temperature goes above the High temperature.
  • Page 34 4 = TEST (SYSTEM DIAGNOSTIC TEST) The diagnostic test performed by the Omni II allows you to check the status of the battery, telephone, bell circuit, auxiliary fuse, and security zone loop readings. The display is updated 3 times per second, although the actual readings are taken 10 times per second.

  • Page 35: Event Log

    The next series of displays shows the current analog reading for each security zone input. The displays show the readings for zones 1-48. 1=147 2=148 3=147 6=147 ↕ 4=146 5=146 THROUGH 43=148 44=147 45=147 ↑ 46=145 47=149 48=146 Normal readings for zones are between 137 - 157 when secure. If Zones 1-4 are configured as Fire or Gas zone, normal readings are between 26 - 43 when secure.

  • Page 36: Show Events

    REM ACCESS An event is logged after three unsuccessful attempts are made to log into the system from a remote phone, the Omni II will lock out remote telephone access for 1 hour to discourage any further attempts to access the system - See Telephone Control.

  • Page 37: Log Message

    Say Message Note: To Say a message, the HAI Two-Way Audio Module (with a speaker) must be installed. The 4 (SAY) key allows the controller to say the selected voice message over a speaker. This voice message can be an audible reminder of special events and occasions.
  • Page 38 64 messages for a matching message. If one is found, the Program Command (macro) corresponding to the matching message is activated. When receiving an ASCII message that is over 15 characters, Omni II only processes the last 15 characters of the message. Pro-Link determines that a message has been received when: •...

  • Page 39: Telephone Control

    In-House Phones Each time you pick up your telephone at home, the Omni II will also pick up the line and listen for a # (pound) key. If Omni II does not hear the # key within 5 seconds, it hangs up and does not listen in again until the next time you pick up your phone. If the Omni II hears any key other than the # key while it is listening in, it disconnects itself immediately.

  • Page 40: Phone Access Denied - Remote Lockout

    If you press a key that is not on the current menu, you will hear 3 beeps and the menu will be repeated. So that the Omni II does not tie up your phone, there is a 10 to 15 second time-out that starts after the Omni II stops talking. If it does not hear any numbers from your phone in 10 to 15 seconds after it stops talking, the Omni II will hang up.

  • Page 41: Control

    When bypassing and restoring a zone, if voice descriptions have been programmed, after a three-second delay, the system will begin reading from the list of zones. If the ' # ' key is pressed, Omni II will read the next three descriptions (if programmed).

  • Page 42: Status

    Press 7 from the MAIN MENU to get to the EVENT menu. The Omni II will read the 3 latest events. Press the ' 7 ' key for Omni II to read 3 more events, or ' * ' to cancel.

  • Page 43: Phone

    The Omni II will say, "GOOD-BYE" and hang up. From an in-house phone, the dial tone will return. From a remote phone, you will hear a click as the Omni II hangs up. It is recommended that you press 9 to terminate a remote call. If you don't, the Omni II will hang up anyway after about 15 seconds.

  • Page 44: Pc Access

    In UL Listed Installations, the Voice Dialer is supplementary to the Digital Dialer described above. The voice dial-out feature of the Omni II is a sophisticated system that can notify you at the office, on vacation, on a pocket pager, or notify your neighbor, a relative, and in some cases, local authorities.

  • Page 45: What The Omni Ii Voice Dialer Does

    What the Omni II Voice Dialer Does When an alarm is activated, the Omni II will wait the Dial Out Delay. If your system is monitored by a central station, it will be notified first. Then the voice dialer will dial out to the numbers as described above.

  • Page 46: Setup

    Set Up Codes Omni II has 16 user codes that you may assign to users of the system. All Omni II security codes are 4 digits in length (0001 to 9999). Each user should be assigned a security code with an authority level, areas that can be accessed (if area arming is being used), and times in which the code will be valid.

  • Page 47: Duress Code

    This item is used to correctly calculate the times for sunrise and sunset. You are only asked this question when you set the time. Once the time is set, Omni II will automatically adjust the "time of day" each time daylight savings time begins and ends.

  • Page 48: Advanced Control Programming (Acp)

    You can also specify 2 conditions in each program, so that they only run under certain circumstances. Every line of programming in the Omni II controller consists of three pieces. Each line must have at least an event (when) and a result (command).
  • Page 49 Menu 1 - Programs for a particular control unit number Menu 2 - All Security related programs Menu 3 - Programs for a particular macro button Menu 4 - Programs for All On/Off functions Menu 5 - Programs for a particular Temperature zone Menu # - Displays every program Selecting the 1 (CTRL) or 5 (TEMP) key will prompt you to specify the desired unit or temperature zone.

  • Page 50: Delete All Programs

    The arrow keys are used to scroll through the programs. Pressing the ' # ' key while a particular program is displayed will allow that program to be edited or deleted. The display shows: SHOW PROGRAM 1=EDIT 2=DELETE Press the 1 (EDIT) key to edit the selected program. The Edit Program menu is displayed which allows the various parts of the program to be changed - See Edit Program.

  • Page 51: Edit Programs When

    Edit Programs When Selecting the 1 (WHEN) key, from the Edit Program menu, allows the time or button/event that activates the program to be changed. The display shows: EDIT WHEN 1=TIMED 2=BUTTON Times Programs Selecting 1 (TIMED) sets the program to be activated at a specific time of day. You are prompted to enter the time and date or days of week.
  • Page 52 Selecting 2 (BUTTON), from the "Edit When" menu, sets up a program to be activated when a macro button is executed or an event occurs. The user is prompted to specify the button/event that activates the program: BUTTON: ↓ ENTER BUTTON #=MENU A specific macro button may be activated by entering the button number followed by the ' # ' key, or by using the arrow keys to scroll through a list of buttons.
  • Page 53 After the security mode is selected, an additional menu appears which allows you to further specify the event button. For example, you would like to activate an event button when you arm the system into the 3 (AWAY) mode: WHEN AWAY: 1=DELAY 2=CODE 3=AREA Any of these may be selected alone or in combination.
  • Page 54 Pressing the 6 (X-10) key allows you to specify an event button activation upon receipt of an X-10 command from a source external to Omni II. The Omni II can also respond to scene changes initiated at Compose keypads and dimmers. When a scene change is initiated, Omni II can activate an event button program.
  • Page 55 After specifying the X-10 House Code and X-10 Unit Code, select 0 for Off, 1 for On, or 2 for Scene. "Off" events will be activated whenever the selected device is turned off. "On" events will be activated whenever the selected device is turned on.

  • Page 56: Edit Program Command

    Edit Program Command Selecting 2 (CMD), from the Edit Program menu, allows the commanded action for the program to be specified. The following menu is displayed: 1=CONTROL 2=SECURITY ↓ 3=BUTTON 4=ALL 5=TEMP 6=ENERGY ↑ 8=MESSAGE After the command is specified, the display returns to the Edit Program menu: Program Control Commands Press the 1 (CONTROL) key to command lights and appliances.

  • Page 57: Program Button Commands

    Press the ' # ' key first to specify all areas. Program Temperature Commands Select the 5 (TEMP) key to control HAI Communicating Thermostats, energy saver modules, and temperature sensors. Specify the desired command - See Temperature.

  • Page 58: Edit Program Condition

    Edit Program Condition Selecting the 3 (&COND) key, from the Edit Program menu, allows the condition for the program to be specified. The condition is optional in all program lines. This condition must be true when the program time or event occurs for the program to executed. Note: Two (2) conditions can be specified in each program line;...

  • Page 59: Program Time Clock Conditions

    The zone will be displayed and you will be prompted for the state of the zone: IF Front Door: 0=SECURE 1=NOT RDY Program Time Clock Conditions Select the 9 (TIME) key to specify that the program should only execute if a specified Time Clock is either On or Off. The display prompts you for the Time Clock number: ENTER TIME CLOCK: Enter the Time Clock number followed by the ' # ' key.

  • Page 60: Set Up Dial

    Set Up Dial The Set Up Dial menu is used to configure all of the telephone related items for the Omni II. To enter the Set Up Dial menu, from the Setup menu, press the 4 (DIAL) key. Use the arrows to scroll through the items. For each item, the top line displays a description of the item and its current setting.

  • Page 61: Dial Out Number 1

    DIAL OUT 1 OFF Dial Out Number 1 has two times associated with it, an On and Off time. The Omni II will only call this number if the time and days are between the Dial Out 1 On and Dial Out 1 Off times and dates.

  • Page 62: Set Up Arming

    Set Up Arming To configure different arming and disarming options, from the Setup menu, press the 5 (ARM) key. Entry Delay The Entry Delay is the time, in seconds, that you have to turn off the alarm after entering your home. The Entry Delay only applies to the entry/exit zone (i.e.

  • Page 63: Enable Quick Arm

    Beep On Trouble If the Omni II detects any troubles with itself or one of the zones connected to it, it will display a message on the screen and beep the console twice per second, continuously (i.e. beep beep...beep beep...). You can silence this sound by pressing the ' * ' key.

  • Page 64: Enable Freeze Alarm

    Enable Freeze Alarm If there are one or more Thermostat or PESM in a system, they can also be used to detect a freeze condition - See Freeze Alarm. The default for Enabled Freeze Alarm is No. Flash For Alarm You may enter one unit number that will flash on and off continuously when the alarm is activated.

  • Page 65: House Codes 2-4 X-10 All Off

    To turn HC 1 All On feature On, press 1 then ' # '. To turn HC 1 All On feature Off, press the 0 key, then ' # '. The default setting for HC 1 X-10 All On is Yes. House Codes 2-4 X-10 All Off This feature allows you to choose if House Codes 2-4 will respond to the X-10 All Off commands.

  • Page 66: Latitude, Longitude, And Time Zone

    Prime Meridian, and time zone. These items should be set to the proper values for the location where the Omni II is installed. The latitude and longitude for a particular location may be obtained from an almanac or map of the area. These values should be entered to the nearest degree.

  • Page 67: Set Up Names

    DST START WEEKEND: #=CHNG ↕ FIRST SUNDAY DST END MONTH: ↕ 1-12 0=DISABLE DST END WEEKEND: ↑ LAST SUNDAY #=CHNG Set the value for DST Start and End Months to "0" if Daylight Savings Time does not apply to your region, or to disable this automatic time update feature.

  • Page 68: Set Up Voice

    Pick up an inside phone and press the ' # ' key on the telephone within 5 seconds of picking up the phone. The Omni II will respond with a menu. Press 8 on the telephone keypad, then 8. The unit will say "ADDRESS IS:" then the Omni II will play back the message stored in the Address memory if one has been entered by your installer.

  • Page 69: Underwriter's Laboratories Requirements

    UNDERWRITER'S LABORATORIES REQUIREMENTS For a complete list of requirements and restrictions when installing the Omni II panel in a UL Listed system, refer to the Underwriter's Laboratories Requirements section of the Installation Manual (10I00-3). When used in UL Listed Installations, the following items apply: The "High Security Mode"...

  • Page 70: Federal Communication Commission Notice

    FEDERAL COMMUNICATION COMMISSION NOTICE: This equipment complies with Part 68 of FCC Rules. On the door, inside of the Omni II enclosure, is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment. If requested, provide this information to your telephone company.

  • Page 71: Canadian Industry Canada Notice

    IF YOU HAVE TROUBLE WITH YOUR PHONES ...and you suspect that your Omni II is causing the trouble, disconnect the Controller from the phone lines by removing the PHONE LINE cable from BOTH THE PROCESSOR BOARD AND THE RJ31X JACK INSIDE THE CONTROLLER ENCLOSURE.

  • Page 72: Appendix A - Dial Out Planner

    APPENDIX A - DIAL OUT PLANNER Use the following dial-out planner to help you set-up the voice dial-out numbers: Omni II Voice Dial-Out Planner DIAL OUT NUMBER 1: __________________________________ AREA: _____________ DIAL OUT 1 ON: TIME: _______________ DAYS: _______________ DIAL OUT 1 OFF:...

  • Page 73: Instructions To Called Party

    Dear ___________________________________________________________________ I have programmed my Omni II Home Automation system to call you if my alarm is activated. If it is activated, it will call and say: "Emergency... Emergency... The (burglar or fire) alarm has been activated at the following address:...

  • Page 74: Appendix B - Text Description Character Codes

    APPENDIX B - TEXT DESCRIPTION CHARACTER CODES CODE CHAR CODE CHAR CODE CHAR CODE CHAR SPACE " < & > ¥ × ¯ à ß Page 68...

  • Page 75: Appendix C - Voice Description Codes

    APPENDIX C - VOICE DESCRIPTION CODES CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION (ADDRESS MSG) DETECTOR HALL (BEEP) DIMMER HEAT (PAUSE) DINING HIGH (SHORT PAUSE) DOCK HOLD A. M. DOOR HOURS AC POWER DOWN HUNDRED ACCESS DRAWER INFRARED ADDRESS DRIVEWAY INSIDE ALARM DURESS INSTANT...
  • Page 76 CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION PATIO SENSOR THEN SETTING THERMOSTAT PERIMETER SEVEN THIRD PHONE SEVENTEEN THIRTEEN PLAY SEVENTY THIRTY PLEASE CHOOSE SHOP THREE POINT SIDE TIME POLICE SILENT TIMED POOL PORCH SIXTEEN TRAP POUND SIXTY TRIPPED PRESS SMOKE TROUBLE PUMP SOUTH TWELVE...
  • Page 78 NOTE TO INSTALLER Following installation, this manual shall be left for the homeowner's use. HAI • New Orleans, LA • U S A...
