Ramp Command (ALC)

When ALC Switch Modules are being used, it is possible to ramp the lighting level of an ALC Dimmer Switch to a new level at a
selectable ramp rate. Only ALC Dimmer Switches respond to the Ramp command.
Press the 5 (RAMP) key to select the ramp command. The keypad will then prompt you for the desired ramp rate:
The rate specifies the time it takes the switch to go from full off to full on, or from full on to full off. Thus a level change from
full off to 50% on will take half the time specified.
Before any digits are entered, the ' # ' key may be used to switch between specifying the rate in minutes, seconds, and hours.
After you choose between minutes, seconds, and hours, enter the rate (2-99 seconds, 1-99 minutes, or 1-10 hours).
Next, enter a number (0-100) to indicate the final lighting level (intensity) desired.
The keypad will beep and the lighting level will be adjusted. The keypad display top line will read:

Controlling Compose Units

Press 0 (OFF) to turn the selected unit off.
Press 1 (ON) to turn the selected unit on.
Press 2 (DIM) to dim the selected unit (1-9 steps, each step is 10% from its current level).
Press 3 (BRT) to brighten the selected unit (1-9 steps, each step is 10% from its current level).
Press 4 (SCN) to set a group of lights to their predefined lighting levels.
Press 9 (TIM) to time the selected unit (On or Off). Timed commands may be from 1-99 seconds, 1-99 minutes or 1-18
hours.
Press # (STA) to view the current status of the unit.

Scene Command (Compose)

If Compose lighting switches are part of your installation, the Scene (SCN) command is used to set a group of lights to predefined
lighting levels. There is an Off command, an On command, and 12 lighting scenes for each group of Compose lighting switches.
Enter 0, followed by the ' # ' key, to turn the lights that are part of the selected group off. Enter 1, followed by the ' # ' key, to set
the lights that are part of the selected group to predefined lighting levels.
To set the lights in the selected group to a predefined scene, enter the Scene number 2-13 (which corresponds to Scene A-L,
respectively), followed by the ' # ' key. All lights that are part of the selected group are set to the predefined lighting levels for the
selected Scene.

Timed Commands

ENTER RATE:
MINUTES (1-99) #=H/M/S
LIGHTING LEVEL:
0-100%:
Entry Lights 40% AT 1H
Entry Lights
0=OFF 1=ON 2=DIM 3=BRT
Entry Lights
4=SCN 9=TIM
SCENE:
0=OFF 1=ON 2-13=A-L
↓
↑
#=STA
